Super Handy GUO117 Operator's Manual

Tamping rammer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Tamping Rammer
Operator's Manual
WARNING:
Carefully review and understand all INSTRUCTIONS prior to operating this device. Failure to follow
the safety rules and other basic safety precautions may result in serious personal injury. Keep these
instructions in a safe place and accessible so that they can be reviewed as required. Keep these
instructions to assist in future servicing needs.
REV 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GUO117 and is the answer not in the manual?

Questions and answers

Related Manuals for Super Handy GUO117

Summary of Contents for Super Handy GUO117

  • Page 1 Tamping Rammer Operator's Manual WARNING: Carefully review and understand all INSTRUCTIONS prior to operating this device. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Keep these instructions in a safe place and accessible so that they can be reviewed as required. Keep these instructions to assist in future servicing needs.

  • Page 2: Safety And Warning

    SAFETY AND WARNING 1. Symbols Index This manual contains DANGER, WARNING, CAUTION, and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. Indicates a potentially hazardous condition/situation. Failure to follow designated procedures, will result in death or serious injury.
  • Page 3 ● ALWAYS be sure the operator is familiar with proper safety precautions and operation techniques before using rammer. ● ALWAYS wear protective clothing when operating rammer. Wear goggles or safety glasses, hearing protection, and safety shoes. ● ALWAYS keep hands, feet, and loose clothing away from the moving parts of rammer. ●...

  • Page 4: Technical Specifications

    TECHNICAL SPECIFICATIONS SKU# GUO117 Engine Power 209cc (7HP) Engine Speed 3600rpm Impact Force 3500Lbs Compaction Depth 26" (660mm) Stroke Height 1.6-2.6" (40-66mm) Plate Size 13x11" (330x280mm) 42ft./min (13m/min) Travel Speed Assembled Dimension 18"x28.3"x42" (460x720x1060mm) Net Weight 137Lbs (62.3Kgs) MAIN COMPONENTS...
  • Page 5 ASSEMBLY 1. Out of Package The tamping rammer comes partially assembled and is shipped in carefully packed carton. After all the parts have been taken out of the carton, you should have below components (Fig.01). Fig. 01 M10x20 bolt x4 Handle-bar kit Ø10 Spring washer x4 Wheels kit...

  • Page 6: Operation

    3. Assemble Wheel Kit 1) Tamper rammer can be towed for a short distance by the wheels. 2) Raise up the rammer by raising the operation handle, and put the wheel kit (2) into the hook on the base plate. Put down the rammer (Fig.03). 3) Tilt the rammer to make the wheel supporting on the ground.
  • Page 7 2. Before Starting ● This machine is oil bath lubrication system. MUST fill the oil in the gear system before first starting. ● For lubrication, use automobile engine oil of SJ or SAE 10W-30, or better grade. ● Open the plug at top of gear box. Fill the oil from it (Fig.05). ●...
  • Page 8 ● If it is difficult to start the engine by repeatedly pulling the starter rope, remove ignition plug and check the sparking performance. If the plug is wet due to excessive fuel intake or soiled, replace the coil or clean sufficiently. With the ignition plug removed, pull the recoil starter handle 2-3 times to discharge excessive gas.

  • Page 9: Maintenance And Storage

    MAINTENANCE AND STORAGE 1. Maintenance Daily before After first Every week Every month starting 5 hours or 25 hours or 100 hour √ Check fuel level √ Check oil level of machine √ Check fuel line and fittings for cracks or leaks √...
  • Page 10 3. Storage The rammer should be stored on level ground, a er the engine and machine have cooled down. Be sure to secure the rammer as necessary to avoid it from falling. If the rammer has to be laid down, tighten fuel tank cap and engine oil plug securely and wait until the engine and machine are cooled down.

  • Page 11: Troubleshooting

    TROUBLE SHOOTING Issues Possible root cause Solution Engine rotates but Operating speed of throttle Set throttle lever to correct amplitude not uniform lever is incorrectly set? position. or does not strike. Oil in excess? Drain excess oil. Bring to correct level. Clutch slips? Replace or adjust clutch.
