Cordless Concrete Vibrator
Operator's Manual
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.
REV 1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Super Handy GUT139
Summary of Contents for Super Handy GUT139
- Page 1 Cordless Concrete Vibrator Operator's Manual WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Save these instructions in a safe place and on hand so that they can be read when required. Keep these instructions to assist in future servicing.
- Page 2 1. GENERAL POWER TOOL SAFETY WARNINGS Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
- Page 3 g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. 4) Power Tool Use and Care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
- Page 4 6) Be careful not to allow water, wet concrete or the like to get into the tool. Do not let the tool fall into wet concrete. 7) Insert the vibrating head carefully between iron/steel frames or reinforcing rods not to come in contact with them.
- Page 5 4. TECHNICAL SPECIFICATIONS SKU# GUT139 Motor 48V DC Brushless Motor Vibration Speed 13,000 VPM (Vibrations per Minute) Vibrator Head Dimension 1-1/4" (32mm) Vibrator Head Length 11" (280mm) Flexible Shaft Assembly Length 4.9ft. (1.5m) Battery 48V DC, 2.0Ah Charger 100-240V~, 50/60Hz Net Weight (With Battery) 10.4lbs (4.7kg)
- Page 6 1) Take the tool and flexible hose out of Fig. 1 box. 2) Screw the flexible shaft inside hose to the spindle thread. (See Fig.1) 3) Screw the collar of flexible hose to the Fig. 2 gearbox housing. (See Fig.2) 4) Insert the battery to the housing of tool.
- Page 7 3) Turn the motor on by gently squeezing Fig. 4 the switch trigger (See Fig.4). The vibrator head will start vibrating once switch on. DO NOT hit the vibrator head to solid ground. There are two holding positions of trigger. You can hold tool as comfort as Switch you can.
- Page 8 8. MAINTENANCE Before performing any inspection, maintenance or cleaning procedures, MAKE SURE the Trigger is OFF, and the battery is removed. 1) BEFORE EACH USE, inspect the general condition of the Concrete Vibrator. Check for any loose screws, misalignment or binding of moving parts, cracked or broken parts, and any other condition that may affect its safe operation.
