- Page 1 OSPREY OWNER’ S MANUAL...
- Page 2 Welcome Thank you for purchasing OSPREY from Senada Bikes. Please read carefully and understand this manual fully before assembling and riding your bike. If you have questions after reading this manual, please contact us by email.
-
Page 3: Table Of Contents
Table of Contents Attentions ..............3 General Info ..............6 Productfunctiondiagram ............10 Product parameters ............14 Manual control instrument ..........16 Displayinterface............20 Button introduction ............22... -
Page 4: Attentions
Attentions Battery and Charging: Charge at 0℃～45℃ 32-113℉）, discharge at -20℃ 〜60 （ ℃ （68-140℉), keep the battery dry. Do not put the battery in acidic or alkaline liquid. Avoid rain and keep away from fire, heat and high temperature environment. It is strictly forbidden to connect the positive and negative poles of the battery reversely. - Page 5 forbidden to connect the charger to the AC power supply for a long time without charging. During the charging process, if the indicator light is abnormal, there is a peculiar smell, or the charger casing is overheated, stop charging immediately, and repair or replace the charger.
- Page 6 please be careful not to hit it vigorously and keep the rotating shaft lubricated. It is not allowed to ride with more than the maximum load of the body (the maximum load is 100 KG，220lbs) After use, the bike can not be parked in the building hall, evacuation stairs, safety exits, and must be parked correctly in accordance .
-
Page 7: General Info
NOTICE: A critical aspect of assembling your bike by Senada Bikes is securing the front wheel and checking the tightness of the rear wheel axle nuts. Thes... - Page 8 mechanisms may become loose or unsecured during shipment or over time. The torque and security of all wheel mounting hardware should be inspected upon arrival and on a regular basis. Both wheels need to be properly secured before operating your bike. Mandatory Equipment and Use Locations Before all rides, ensure you have all required and recommended safety equipment and are following all laws pertaining to using an electric bike in your region.
- Page 9 If your wheels become untrue or spokes loosen, which can happen with normal use, we recommend that a certified,reputable bike mechanic performs all wheel tuning and truing operations on your bike from Senada Bikes. Do not attempt to...
- Page 10 true wheels or tighten spokes unless you have adequate knowledge, tools, and experience. Ensure the tires and inner tubes are in good working condition without any visual damage and have the correct amount of air pressure. Always replace tires and inner tubes with punctures, cuts, or damage before you ride. increase tire and component wear, and make riding your bike unsafe.
- Page 11 Senada Bikes. The seat and saddle tube should be properly aligned, fitted to the user, and the saddle tube quick release should be properly tightened, fully closed, and secured before riding.
-
Page 12: Productfunctiondiagram
Product function diagra... - Page 13 Function introduction: Figure 1 Figure 2 Figure 3 Charging Figure 1 : Unscrew the plastic cover on the battery ( ), connect the charger to start charging, when the battery is full and the indicator light of the charger changes from red to green, it means it is fully charged...
- Page 14 Power on: Figure 2 Figure3 press an Refer to ,witch on battery; refer to 。 hold to turn on/off the power Power display turned on, the dashboard lights up to display : After the power is the power. The power is displayed in 5 grids, corresponding to high, medium and low power.
-
Page 15: Product Parameters
Product parameters Parameter Standard Version Body Material Aluminum Alloy Color Grey and Lake Water Green Outlook 1715mm*687mm*1170mm Unfolding Size &Dimension Folding size Spoke wheel Hub Form 20 inches Wheel Size 1460mm*330mm*780mm Packing Size 41/32.2kg Gross weight /Net weight 100kg(220lbs) Maximum Load ≦40km/h(24.8mph)in US Maximum Speed Range... - Page 16 Battery Rated Voltage Motor Rated Power 500W Motor Form Assist mode,pure electric mode Electrical Motor Type 20 inches / Brushless rear wheel Specifications drive hub motor Motor Rated No-Load 26MPH Speed Charger Output 54.6V3.0A Charger Input 100-240V,50/60Hz，2.5A Under voltage Protection 39V±0.5 Value Over current Protection...
-
Page 17: Manual Control Instrument
valve is AV Front Fork Suspension front fork 7 Speeds transmission Remarks: The factors, including battery power capacity, load, tire pressure, road conditions, chain and lubrication between wheel and axle, etc.will affect the maximum speed; the cruising distance indicated in this manual file is the test result from the riding test conducted uninterruptedly with load of 100kg(220lbs), at the speed of 12-24mile/h for US, and on the flat and hardened road surface, from full charge to full power consumption. - Page 18 1. Display function ● Battery level indicator ● Assist level adjustment and indicator ● Speed indicator (including real-time speed, maximum speed (MAXS) and average speed (AVG)) ● Error code indicator ● Cruise control indicator...
- Page 19 ● Distance indicator (including ODO and trip distance (Trip)) ● Walk boost mode control and indicator ● Headlight control and indicator 2．Control set function Power switch control, headlight switch control, 3.1mph push assist setting (WALK mode), 3 gear speed setting,1st speed 12.4mph, 2nd speed 18.6mph,3rd gear speed 24.8mph.Speed display...
- Page 20 c o n t e n t s o a y s c r e e n t e r oo t a y w A ll u l l d i...
-
Page 21: Displayinterface
Display interface After the display is turned on, the display will show the real-time speed and the trip distance by default. By pressing the button , the information displayed will be switched between the trip distance , ODO, maximum speed and average speed . - Page 22 Status display area Instrument Status Code Meaning： Status Code State Meaning E001 Controller Failure E002 Communication Failure E003 Hall Fault E004 Handlebar Failur E005 Brake Lever Failure E006 Motor Phase Loss...
-
Page 23: Button Introduction
Button introduction The specific combination of buttons is as follows Use Introduction button operation is divided into short press and long press. Specific operation explanation. I、Switch LC 1.In the off state, press and hold the button to turn it on；... - Page 24 2.In the power-on state, press and hold the button to turn it off。 II、Change the assist gear In power-on state 1. Short press the button to turn it on, assist gear will be + 1. 2. Short press the button to turn it on, assist gear will be -1.
- Page 25 Set/release 5 Km/h (3.1mile/h)boost, cruise control, switch headlights III、 When the bike is stationary, press and hold th button to enter the 5 KM/h (3.1mile/h) boost cruise mode. Press any brake to exit this mode. When the bike maintains a fixed speed for 5 seconds, it will enter cruise control mode, and pressing the brake or accelerator will cancel cruise control.
- Page 26 Note: 1. Due to the upgrade of the company's products, the display content of the product you get may be different from the manual, but it will not affect your normal use. Everything is subject to the real object, and the company reserves the right of final interpretation.
- Page 27 meter. When cleaning, wipe with a soft cloth dampened with water. Do not wipe with any cleaning agent. 4. Do not dispose of the instrument or any other E-bike accessories as resident waste. Please comply with local laws and regulations and dispose of or recycle E-bike accessories in an environmentally friendly manner...
