SENADA SABER Owner's Manual

Hide thumbs Also See for SABER:

Advertisement

Quick Links

SABER
&
HERALD
OWNER' S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the SABER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SENADA SABER

Summary of Contents for SENADA SABER

  • Page 1 SABER & HERALD OWNER’ S MANUAL...
  • Page 2 Welcome Thank you for purchasing SABER/HERALD from Senada Bikes. Please read carefully and understand this manual fully before assembling and riding your bike. If you have questions after reading this manual, please contact us by email. We are here to help!
  • Page 3 Keep this manual, along with any other documents that were included with your bike, for future reference, however all content in this manual is subject to change or withdrawal without notice. Senada Bikes makes every effort to ensure the accuracy of its documentation and assumes no responsibility or liability if any errors or inaccuracies appear within.

  • Page 4: Table Of Contents

    Table of Contents General Info Assembly Instructions Battery Charging Operation Maintenance Warnings and Safety Warranty...

  • Page 5: General Info

    NOTICE: A critical aspect of assembling your bike by Senada Bikes is securing the front wheel and checking the tightness of the rear wheel axle nuts. These mechanisms may become loose or unsecured during shipment or over time. The torque and security of all wheel mounting hardware should be inspected upon arrival and on a regular basis.
  • Page 6 The throttle should provide smooth acceleration when gradually applied. If the throttle, brake lever cutoff switches, pedal assistance, or lighting are functioning abnormally, intermittently, or not working, please discontinue using your ebike immediately and contact the Senada Bikes Product Support team for assistance.
  • Page 7 Loose, worn, or damaged handlebar grips should be replaced before you ride and can be purchased from Senada Bikes. The seat and seatpost should be properly aligned, fitted to the user, and the seatpost quick release should be properly tightened, fully closed, and secured before riding.
  • Page 8 Fully Assembled We have many other colors in these two series, the following pictures are for reference only.

  • Page 9: Assembly Instructions

    Unpack the bike. Open the bike box and remove the small box inside. With the help of another person capable Step 1: of safely lifting a heavy object, remove SABER/HERALD from the bike box. Carefully remove the packaging material protecting the bike frame and components. Open the small box and carefully set out all contents.
  • Page 10 Step 2: Install handlebar on the stem A. Place the handlebar on the stem correctly. Trace the front brake cable directly up from the front brake caliper to the left handlebar and ensure the cables and wires are not twisted. B.
  • Page 11 Step 3: Install the front wheel.
  • Page 12 Remove the screw from front wheel Put front wheel in right position...
  • Page 13 Install the skewer into the front wheel axle Fully seat the skewer in the fork dropouts thread the thumb nut onto the (and the brake rotor in the caliper) skewer a couple turns. and turn the thumbnut, as shown Using the Wrench(15mm) to tight the thumb nut.As below picture.
  • Page 14 When properly installed, the front wheel should be fully seated and centered in the dropouts of the front fork, the brake rotor should be in between the brake pads in the brake caliper Ensure the front wheel is properly secured before moving on to the next step.
  • Page 15 Step 4: Lock the handlebar stem by tightening the screws as shown below Please make sure that the front wheel is aligned to the handlebar before tightening)
  • Page 16 Step 5: Install Front Fender and Headlight. Remove headlight screw and slide the fender under the fork, above the tire. Position the mounting point to be in the back of the fork by the screw hole, layering the headlight first, then the fender mounting point (as shown below).
  • Page 17 Then unscrew the 2 screws and bolts on both sides right below the fork (see image below), and screw the fender mounting arms in.
  • Page 18 Install the pedals. Locate the pedal with a smooth pedal Step 6: axle exterior and an engraved “R”, which indicates it is the ri g ht p edal (as shown below). The right pedal goes on the crank on the right side of the bike (which has the drive train g ears and is the same as a rider’s right side when riding).
  • Page 19 The left pedal (2) is reverse-threaded and tightens counterclockwise. The pedal has an engraved “L” into the end of the axle (pictured below), indicating it is the left pedal. Carefully thread the pedal onto the left crank by hand slowly by tightening counterclockwise.
  • Page 20 Torque each pedal to 35 Nm. Use the pedal wrench provided to avoid damage caused by wider wrenches. Right pedal tightens clockwise. Left pedal tightens counterclockwise.
  • Page 21 Step 7: Inflate the tires. Check that the tire beads and tires are evenly seated on the rims. Use a pump with a Schrader valve and pressure gauge to inflate each tire to the recommended pressure indicated on the tire sidewall, 20 PSI (1.38 Bar). Do not overinflate or underinflate tires.
  • Page 22 Step 8: Set the desired seat height. Open the quick release lever by hinging it open fully. Ensure the seatpost clamp opening is aligned with the notch at the front of the seat tube. Adjust the seatpost up or down to a comfortable height, while ensuring the seatpost is inserted into the frame past the minimum insertion point.
  • Page 23 NOTICE: If you have any questions regarding the assembly of your bike, contact Senada Bikes. If you are not able to ensure all the assembly steps are performed properly, please consult a certified, reputable local bike mechanic for assistance in addition to contacting Senada Bikes for help.
  • Page 24 Adjusting the Seat Position and Angle To change the angle and horizontal position of the seat: 1) Use a 6 mm Allen wrench to loosen the seat adjustment bolt on the clamp positioned immediately underneath the seat, above the rear wheel. Do not remove the boltfully. 2) Move the seat backward or forward and tilt to adjust the angle.
  • Page 25 NOTICE: If you have any questions regarding the proper fit of your bike please consult a certified, reputable local bike mechanic for assistance fitting the bike to a rider or contact Senada Bikes.

  • Page 26: Battery Charging

    Always charge your battery in temperatures between 50 °F – 77 °F (10 °C – 25 °C) and ensure the battery and charger are not damaged before initiating charge. If you notice anything unusual while charging, please discontinue charging and use of the bike and contact Senada Bikes Product Support for help.
  • Page 27 Battery Charging Information Check the charger, charger cables, and battery for damage before beginning each charge. Always charge in a safe area that is cool*, dry, indoors, away from direct sunlight, dirt, or debris, in a clear area away from potential to trip on the charging cords, or for damage to occur to the bike, battery, or charging equipment while parked and/or charging.
  • Page 28 Use caution to avoid damage to battery connector terminals, which are exposed when the battery is unlocked and removed from the frame of the bike. In the case of damage to the terminals or battery mounts, please discontinue use and contact Senada Bikes Product Support immediately. When Installing the Battery onto the Bike Ensure the battery is off before sliding the battery onto the frame mount receptacle.
  • Page 29 Do not charge the battery with any chargers other than the one originally supplied from Senada Bikes or a charger designed for use with your specific bike purchased directly from Senada Bikes.
  • Page 30 Long-Term Battery Storage If storing your bike from Senada Bikes for longer than two weeks at a time, follow the instructions below to maintain the health and longevity of your battery. Charge (or discharge) the battery to approximately 75% charged.

  • Page 31: Operation

    Contact Senada Bikes if you have any questions about assembly or operation.
  • Page 32 Handlebar Features Location on Handlebar Component LCD Display Remote LCD Display Shifter On/off switch for the throttle Throttle...
  • Page 33 LCD Display Information The table and image below show the various features and information displayed on the LCD display. Location Information on Display Battery Charge Indicator Distance (Odometer, Trip Odometer) Distance Unit (kilometers (Km), miles (Mile)) Speed Unit (kilometers per hour (Km/h), miles per hour (MPH)) Operation Mode Watt Meter, Error Code Indicator...
  • Page 34 LCD Dis p la y O p erations Operation Directions Turn on bike Press and hold M button until power engages Turn on headlight, taillight, Press and hold up arrow until light illuminates Decrease pedal assist (PAS) level Press and release down arrow Toggle odometer, trip odometer Press and release MODE (2) While dismounted, press and continue to hold down arrow...
  • Page 35 Start-Up Procedure After the bike has been properly assembled if all components are secured correctly, and you have read this entire manual, you may turn the bike on and select a power level following the steps outlined below: Test the battery lock security.Ensure the key port is aligned in the “lock” position. Ensure proper handlebar and seat adjustment of the bike to the rider.For details see the “adjusting the seatheight”...
  • Page 36 6.Begin riding carefully. With the proper safety gear and rider knowledge, Press the red button and you may now operate your bike from Senada Bikes. On a flat surface, in a low gear (1 or 2), most riders should be able to begin pedaling the bike with pedal assist level 0 or 1.
  • Page 37 Battery Charge Level Indicator The LCD display on the handlebars of your bike from Senada Bikes features a battery charge level indicator (like a fuel gauge on a car). This indicator calculates battery life based on the battery power output (instantaneous voltage reading) and can fluctuate while riding if power demand and/or output changes.
  • Page 38 Driving Range The range of your bike from Senada Bikes is the distance the bike will travel on a single full charge of the onboard battery. The range values in this manual are estimates based on expected usage characteristics of bikes by Senada Bikes. Some of the factors that affect range include changes in elevation, speed, payload, acceleration, number of starts and stops, ambient air temperatures, tire pressure, and terrain.

  • Page 39: Maintenance

    Basic Bike Care To ensure safe riding conditions you must properly maintain your bike from Senada Bikes. Follow these basic guidelines and see a certified, reputable bike mechanic at regular intervals to ensure your bike is safe for use and fun to ride. See the Pre-Ride Safety Checklist and Recommended Service Intervals sections in this manual for more detailed information.
  • Page 40 Pre-Ride Safety Checklist Notice: Before every ride, and after every 25-45 miles (40-72 km), we advise following the pre-ride safety checklist. Safety Check Basic Steps 1. Brakes Ensure front and rear brakes work properly. Check brake pads for wear and ensure they are not over worn. Ensure brake pads are correctly positioned in relation to the rims.
  • Page 41 8. Frame, Fork, Check that the frame and fork are not bent or broken. If either frame or fork are bent or broken, they should be replaced. and Seat Check that the seat is adjusted properly, and seatpost quick release lever is securely tightened. Ensure hub motor is spinning smoothly and motor bearings are in good working order.
  • Page 42 Even tires equipped with built-in flat-preventative tire liners, like those that come with bikes by Senada Bikes, can and do get flats from punctures, pinches, impact, and other causes. When tire wear becomes evident or a flat tire is discovered, you must replace the tires and/or tubes before operating the bike or injury to operators and/or damage to your bike could occur.
  • Page 43 Error Detection Your bike from Senada Bikes is equipped with an error detection system integrated into the display and controller. In the case of an electronic control system fault an error code should display. If your bike has an error code displayed at...

  • Page 44: Warnings And Safety

    Be careful at intersections and when preparing to pass other vehicles or othercyclists. ● Familiarize yourself with all the features and operations of the bike by Senada Bikes. Practice and become proficient at shifting gears, applying the brakes, using the power assist system, and using the throttle in a controlled setting before riding in riskier conditions.
  • Page 45 Safety Notes The following safety notes provide additional information on the safe operation of your bike from Senada Bikes and should be closely reviewed. Failure to review these notes can lead to serious injury or death. ● All users must read and understand this manual before riding their bike from Senada Bikes. Additional manuals for components used on the bike may also be provided and should be read before installing or using those components.
  • Page 46 Wet Weather It is recommended to not ride in wet weather if avoidable. Ride in wet weather only if necessary. This electric bike is not meant for use in puddles, heavy rain, or streams. Never immerse or submerge this product in water or liquid as the electrical system may be damaged.
  • Page 47 ● Any aftermarket changes to your bike from Senada Bikes not expressly approved by Senada Bikes could void the warranty and create an unsafe riding experience.
  • Page 48 SABER and HERALD are designed for use by persons 18 years old and older. Riders must have the physical condition, reaction time, and metal capability to ride safely and manage traffic, road conditions, and sudden situations, as well as respect the laws governing electric bike use where they ride, regardless of age.

  • Page 49: Warranty

    Limited Warranty Warranty Info Every bike by Senada Bikes is covered under a manufacturer's one-year all-inclusive warranty for the original owner against all manufacturing defects. Senada Bikes warrants this product, including all individual components against defects in material or workmanship as follows:...
  • Page 50 Senada Bikes will not be liable and/or responsible for any damage, failure, or loss caused by any unauthorized service or use of unauthorized parts.
  • Page 51 We are here to help! If you have questions, please: Contact us directly by email at contact@senadabikes.com...

This manual is also suitable for:

Herald
