USER MANUAL FOR SPA
PEAKLIFE
/
/
/
/
CONTROL SYSTEMS
KEYPADS
ACCESSORIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PEAKLIFE and is the answer not in the manual?

Questions and answers

Related Manuals for Wellis PEAKLIFE

Summary of Contents for Wellis PEAKLIFE

  • Page 1 USER MANUAL FOR SPA PEAKLIFE CONTROL SYSTEMS KEYPADS ACCESSORIES...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction Safety instructions Basic Functions Connection diagram Everest Life Kilimanjaro Life Atlas Life Makalu Life Teide Life Initial installation Maintenance Spa chemical treatment In line quickstart guide Jet Directions Everest Life Kilimanjaro Life Atlas Life Makalu Life Teide Life User interface Smart Touch...

  • Page 4: Introduction

    INTRODUC TION Congratulations on your new product! Outside work and family the enjoyment of quality life and calm moments plays an important role in the life of a 21st century man. An evening bath in the spa or tub alone or in company can give you the opportunity to lose track of time and your body and soul can relax.

  • Page 5: Safety Instructions

    SAFET Y INSTRUC TIONS When the spa is not in use, cover the spa with the cover to FOR YOUR SAFETY PLEASE ALWAYS PERFORM THE prevent ultraviolet radiation causing damage to the product. FOLLOWING PRECAUTIONS. IF YOU DO NOT FOL- LOW THE WARNINGS AND INSTRUCTIONS, ITEMS Do not allow your child to climb on the thermo cover when it MAY GET DAMAGED, YOU MAY GET INJURED,...
  • Page 6 SAFET Y INSTRUC TIONS Parts under electrical power – except those operating with voltage not exceeding 12V - must be inaccessible for persons in the spa. The grounded device must be connected to a fixed socket with fixed wiring. Electrical parts – except remote controllers –...

  • Page 7: Basic Functions

    BASIC FUNC TIONS Keypads: The keypads make it possible to control and set up the spa. Available basic functions: pump(s), light and temperature control. (For more information see the details later) Valves Diverter: Some spa are equipped with water diverter(s) that allows you to direct the waterflow to various sections of the spa. The valve has three basic positions By turning the lever all the way to the left position will divert the water section A of the spa.

  • Page 8: Connection Diagram

    CONNEC TION DIAGRAM EVEREST LIFE...

  • Page 9: Kilimanjaro Life

    CONNEC TION DIAGRAM KILIMANJARO LIFE...

  • Page 10: Atlas Life

    CONNEC TION DIAGRAM ATLAS LIFE...

  • Page 11: Makalu Life

    CONNEC TION DIAGRAM MAKALU LIFE...

  • Page 12: Teide Life

    CONNEC TION DIAGRAM TEIDE LIFE...

  • Page 13: Initial Installation

    INITIAL INSTALLATION Electrical preparations: A clearly labeled emergency switch shall be provided as part of the installation. The switch shall be readily accessible to the occupants and shall be installed at least 5 feet (1.52 m) away, adjacent to, and within sight of, the unit. Before installation the hot tub, the ellectrical system has to be prepared, as detailed in the below table.
  • Page 14 INITIAL INSTALLATION SITE PREPARATION To find out the weight of your hot tub, its contents and occupants please refer to the hot tub specification chart. This weight must not exceed the structure’s rated capacity per square meter, otherwise serious structural damages could When choosing a site for the hot tub take into account that result.
  • Page 15 INITIAL INSTALLATION Filling process Next fill the hot tub with water to the sign indicated on its sidewall. Remove the hot tub cover. First remove the cover staves, then remove the side covers by unscrewing the bottom Filling must be done through the filter housing. Improper screws.
  • Page 16 There are multiple choice of using a hardness tester. Please run water through the filter into a separate vessel until Testers sold by Wellis are showing the hardness level on a it becomes perfectly clear. This step allows the filter to rinse colour scale.

  • Page 17: Maintenance

    1. You´ll need a hose a wet and dry vacuum cleaner and a it in the winter. If you are not using your spa during the winter bottle of wellis crystal spa cleaner fluid. months and want to put it out of service properly, call one of 2.

  • Page 18: Spa Chemical Treatment

    4. Clean the filter with Wellis Crystal Filter cleaner. 5. Rinse out the spa with clean water. 6. Fill your spa and place the clean filter back. 7. Resume your normal water treatment schedule with Wellis Crystal All in one Water treatment. ALKALINITY BALANCER (WV00091) Increases total alkalinity and prevents fluctuating pH values.
  • Page 19 PH MINUS (WV00096) The pH value of the water in your spa is very important. If the pH value is good, the disinfection products can do their work in a good way. Wellis Crystal pH Minus lowers the pH in your spa.
  • Page 20 3. Rinse the filter, and put it back in its place. WELLIS CRYSTAL ALL-IN-ONE (WV00081) Instructions: – Shake the Wellis Crystal bottle well. – Add the correct amount to your spa using the table below. – Let the pump run at full power for 2 minutes.

  • Page 21: In Line Quickstart Guide

    IN LINE QUICKSTART GUIDE Power off the spa For your safety, it is best to turn off the main power supply Open the side panel of your spa to access the unit control box Installation must be done by a professional Close the slice valves Remove the manifold caps...
  • Page 22 IN LINE QUICKSTART GUIDE Install the compression fittings Store the sensor boxes and end caps Turn conductivity sensor: water flow Screw the sensors on the manifold passing through the hole Place the sensors in the manifold, with respect to the flow direction: 1.
  • Page 23 IN LINE QUICKSTART GUIDE Connect the sensors to the control box Restore the power supply to the Spa to turn on WIS IN LINE Download the application (free App) Download the application on the user's phone on the...
  • Page 24 IN LINE QUICKSTART GUIDE Scan QR code and follow the instructions Follow the WiFi connection steps in the app...

  • Page 25: Jet Directions

    JET DIREC TIONS EVEREST LIFE...

  • Page 26: Kilimanjaro Life

    JET DIREC TIONS KILIMANJARO LIFE...

  • Page 27: Atlas Life

    JET DIREC TIONS ATLAS LIFE...

  • Page 28: Makalu Life

    JET DIREC TIONS MAKALU LIFE...

  • Page 29: Teide Life

    JET DIREC TIONS TEIDE LIFE...

  • Page 30: User Interface

    USER INTERFACE - SMART TOUCH SMART TOUCH TOUCH SCREEN KEYPAD No buttons, keys and overlays! Mode and function selection wheels, all-on or all-off one touch activation key of last used settings, interactive display icons and on-screen messages are all elements of the Smart Touch user interface designed to let spa users interact intuitively with their spa and its value-added accessories.
  • Page 31 USER INTERFACE - SMART TOUCH SPA MODE SPA MODE START OR STOP ACCESSORIES WATER TEMPERATURE To select the spa mode, slide the left To start or stop an accessory (pump, The temperature shown at the bottom wheel up or down until the spa icon is blower, light), touch the associated of the screen shows the current water temperature.
  • Page 32 USER INTERFACE - SMART TOUCH SETTINGS You can use the Settings mode to manage settings of your spa system. Direct to function selection wheel: Mode selection wheel: – water care settings icon – maintenance – date & time – keypad List of –...
  • Page 33 USER INTERFACE - SMART TOUCH MODIFYING WATER CARE SCHEDULES In Economy mode, the set point will be You can modify the programmed Once you have set the schedule, use reduced by 20°F, which means that the schedules by selecting one and adjust- the calendar icon to go back.
  • Page 34 USER INTERFACE - SMART TOUCH MAINTENANCE & ERROR LOG MAINTENANCE STANDBY REMINDERS To modify maintenance settings, slide The Standby mode allows you to Smart Touch keypad will provide the right wheel until the maintenance service your spa. Pumps will stop for 30 reminders about maintenance required on your spa, like rinsing or cleaning the icon is highlighted in the middle.
  • Page 35 USER INTERFACE - SMART TOUCH KEYPAD SETTING KEYPAD SETTINGS TEMPERATURE UNITS DISPLAY ORIENTATION To modify keypad settings, slide the Use this page to set or change the Use this page to set or change the nor- right wheel until the keypad icon is temperature in F˚...
  • Page 36 USER INTERFACE - SMART TOUCH WIFI (This function is available only if an in.touch module is connected to your system.) WIFI SETTINGS WIFI NETWORKS WIFI NETWORK PASSWORD To modify wifi network settings, slide After a few seconds the available net- If the wifi network is password protect- the right wheel until the wifi icon is works will appear on the screen, as well...
  • Page 37 USER INTERFACE - SMART TOUCH ABOUT YOUR SPA SYSTEM ABOUT To get info about your spa system, slide the right wheel until the about icon is highlighted in the middle. Information about Smart Touch soft- ware number and the revision numbers of the different components of your system will be displayed.
  • Page 38 USER INTERFACE - SMART TOUCH AUDIO MODE (only available if the system detects a connected Aquasoul Pro audio station) Direct to function selection wheel: – on/off – speakers Mode – source selection wheel: – bluetooth audio mode Mute / last track / play/pause / next track To select the audio mode, slide the left wheel up or down until the audio icon menu is highlighted in the middle.
  • Page 39 USER INTERFACE - SMART TOUCH SPEAKER CALIBRATION AUDIO SOURCE SELECTOR BLUETOOTH PAIRING If you are using a device with Bluetooth TO CALIBRATE YOUR SPEAKERS TO SELECT AN AUDIO SOURCE technology, it must be connected for Slide the right wheel until the speaker Slide the right wheel until the source functions to work.
  • Page 40 USER INTERFACE - SMART TOUCH COLOR MODE (only available if the in.mix is detected among the spa accessories) color wheel rainbow icon synchronization/ zone 1 desynchronization icon zone 2 mode selection wheel: in.mix icon intensity By default, the in.mix selects Zone 2 when you access the menu. To select the color mode, slide the left wheel up or down until the in.mix icon menu is highlighted in the middle.
  • Page 41 USER INTERFACE - SMART TOUCH TOO MUCH WATER ON INSTALLATION ERROR MESSAGES DISPLAY Upon connecting Smart Touch to your spa system you may see one of two error messages. Please follow the instructions in the message or contact your dealer for more information.

  • Page 42: And 1 Single Button Panel

    USER INTERFACE - 4 AND 1 SINGLE BUT TON PANEL ONE SINGLE BUTTON PANEL AUXILIARY KEYPAD FOR YOUR SPA This one single button panel is also an auxiliary keypad designed to be installed as a second keypad on your spa. It allows you to activate the spa pump associated to its respective section.

  • Page 43: Electric Water Diverter For Use

    OTHER ACCESSORIES – ELEC TRIC WATER DIVERTER FOR USE Turning on the water diverter: If you want to use the electric water diverter, the engine equipped with the water diverter must be switched on. When you start the pump it will start the diverter as well. The pump can be started either from the main panel or from the single button keypad.

  • Page 44: The Heat Pump

    OTHER ACCESSORIES - THE HEAT PUMP For further information see the original user manual of the heatpump. It shows the installation and technical details. CONTROL PANEL 1. Heating mode indicator 2. Cooling/Defrost mode indicator 3. ON/OFF button 4. Mode button 5.
  • Page 45 OTHER ACCESSORIES - THE HEAT PUMP HEATING MODE Step 1: Press to switch on your pump. Step 2: Press to switch from one mode to another until the heating mode is displayed. Step 3: Using buttons select the required temperature. EXAMPLE: If the current temperature is 15°C, default setting temperature is 27°...
  • Page 46 OTHER ACCESSORIES - THE HEAT PUMP COOLING MODE Step 1: Press to switch on your pump. Step 2: Press to switch from one mode to another until the cooling mode is displayed. Step 3: Using buttons select the required temperature. EXAMPLE: If the current temperature is 30°C, default setting temperature is 27°...
  • Page 47 OTHER ACCESSORIES - THE HEAT PUMP STATUS VALUES AND ADVANCED SETTINGS WARNING: This operation is used to assist servicing and future repairs. The default settings should only be modified by an experienced professional person. THE SYSTEM’S SETTINGS CAN BE CHECKED AND ADJUSTED VIA THE REMOTE CONTROL BY FOLLOWING THESE Step 1: Keep pressing until you enter the settings verification mode.

  • Page 48: Smart Step Manual

    SMART STEP MANUAL...
  • Page 49 SMART STEP MANUAL...
  • Page 50 SMART STEP MANUAL *only for PeakLife models *only for PeakLife models *only for PeakLife models...
  • Page 51 SMART STEP MANUAL...
  • Page 52 SMART STEP MANUAL...
  • Page 53 SMART STEP MANUAL...
  • Page 54 SMART STEP MANUAL...
  • Page 55 SMART STEP MANUAL...
  • Page 56 SMART STEP MANUAL...
  • Page 57 SMART STEP MANUAL...
  • Page 58 SMART STEP MANUAL...
  • Page 59 SMART STEP MANUAL...
  • Page 60 SMART STEP MANUAL...
  • Page 61 SMART STEP MANUAL...

  • Page 62: Aquasoul Pro

    OTHER ACCESSORIES - AQUASOUL PRO AQUASOUL PRO AUDIO STATION FOR SPAS Aquasoul Pro audio system offers you the perfect means to Aquasoul Pro is equipped with state of the art class D audio amplifiers. This type of amplifier is very power efficient and bring music into your spa.
  • Page 63 OTHER ACCESSORIES - AQUASOUL PRO CONNECTIONS NOTE: In basic configuration (not connected to a keypad or PAIRING WITH A BLUETOOTH ENABLED DEVICE controller), Aquasoul Pro is set in Bluetooth mode. Otherwise, Aquasoul Pro can play music from any device equipped with please refer to your specific keypad operating manual for details Bluetooth wireless technologies, however, you must pair on the Aquasoul Pro functions.

  • Page 64: Ozone

    OTHER ACCESSORIES - OZONE OZONE DISINFECTION (assuming that the time of day is properly set). The filtration FILTRATION AND OZONE time and duration are programmable. In a system without circulation engines the low setting of the massage engine and the ozone generator will switch on A second filtration cycle can be freely entered.

  • Page 65: In.grid

    OTHER ACCESSORIES - IN.GRID Heat Mode Operations You can choose between four different water regulation Use this mode for a maximum energy saving purpose. The modes available. Your in.grid is automatically detected by the spa control system will only use your external heating system spa control system at power up.

  • Page 66: In.touch 2

    OTHER ACCESSORIES - IN.TOUCH 2 in.touch 2 Easily integrate your spa to the Internet of Things! Simplest of setups in.touch 2 eliminates all the complexities of con- necting your spa to the Internet and transforms your smartphone or tablet into your ultimate Wi-Fi spa remote control.
  • Page 67 OTHER ACCESSORIES - IN.TOUCH 2 in.touch 2 overview Home Transmitter (EN Module) Spa Transmitter (CO Module) Fastening bracket Pairing activation Status LED Status LED CO pack connection Micro USB power RJ45 Ethernet connection in.touch 2 dimensions Home Transmitter (EN Module) Spa Transmitter (CO Module)
  • Page 68 OTHER ACCESSORIES - IN.TOUCH 2 Home Transmitter (EN Module) installation The Home Transmitter unit must be installed inside the house near the router as it needs to be connected to it. The Home Transmitter is provided with an Ethernet cable and a power supply. If required, a longer cable of good quality can be used by the installer (longer cable not provided) to install the Home Transmitter closer to the spa within the home.
  • Page 69 OTHER ACCESSORIES - IN.TOUCH 2 Pairing the Spa Transmitter (CO Module) and the Home Transmitter (EN Module) The pairing process is used when you need to replace one module of the in.touch 2 kit. Other- wise, the in.touch 2 arrives pre-paired from the factory. 1.
  • Page 70 OTHER ACCESSORIES - IN.TOUCH 2 Each in.touch 2 module has a status LED that can be used for troubleshooting purposes. The LED is located on the top of both enclosures. status status Home Transmitter Spa Transmitter Pairing mode Pairing mode Yellow (Blinking) Yellow (Blinking) Spa controller not detected...
  • Page 71 Internet connection anywhere in the world. The Wellis Spa Control (in.touch 2) app is waiting for you in the App Store for iOS devices and on Google Play for Android — search for «Wellis Spa Control» then click on it to install. Use this application...
  • Page 72 OTHER ACCESSORIES - IN.TOUCH 2 Setup your Wi-Fi on your device Before using your application, go to the Wi-Fi section of your device’s settings. Make sure you are connected to your home network. This needs to be the same Wi-Fi provided by the router to which you connected your Home Transmitter.
  • Page 73 OTHER ACCESSORIES - IN.TOUCH 2 Start the in.touch 2 application Find the icon for the in.touch 2 application, then tap on it to open it. The first time you use the application a message will ask you: “in.touch 2” Would like to send you notifications. If you choose Allow, the application will send you notifications about the status of your spa.
  • Page 74 OTHER ACCESSORIES - IN.TOUCH 2 Login page Before using your application, you must create an account first and then, you’ll be able to sign in. Your account will give you the opportunity to have access to your spa from any in.touch 2 application.
  • Page 75 OTHER ACCESSORIES - IN.TOUCH 2 Choose a spa This page displays all the spas detected by your applica- tion. To detect your spa, you need to connect your mobile device to the same network to which you connected your Home Transmitter.
  • Page 76 OTHER ACCESSORIES - IN.TOUCH 2 Spa state This page displays all the active states of your spa. Below is a quick description of each state you may encounter on your spa. Each state is associated to a priority and color that determines the color of the widget on the home page.
  • Page 77 OTHER ACCESSORIES - IN.TOUCH 2 Turn on/off accessories According to your spa pack configuration, you can start or stop an accessory by simply touching the associated icon. The icon will become animated when the acces- sory is on. Simply press on the icon to start or stop the accessory.
  • Page 78 OTHER ACCESSORIES - IN.TOUCH 2 Control your in.mix 300 This menu is only available if an in.mix 300 is detected in your spa accessories To turn on or off the in.mix 300, you can use, if you want, the light icon on your home page.
  • Page 79 OTHER ACCESSORIES - IN.TOUCH 2 Water Care The Water Care page will help you set up your ideal filtration and heating settings. Choose between Away from Home, Beginner, Energy Savings, Super Energy and Weekender, depending on your need. Touch the Water Care name you would like to activate, a green check- mark will appear on the icon, indicating you have selected it.
  • Page 80 OTHER ACCESSORIES - IN.TOUCH 2 Reminders Reminders page will help you to make a follow-up of your main- tenance. The in.touch 2 will remember you to perform required mainte- nance tasks on your spa, such as rinse filter or clean filter. Each task has its own reminder duration based on normal use.
  • Page 81 OTHER ACCESSORIES - IN.TOUCH 2 Modifying schedules In this menu it is possible to add, remove or edit schedules of economy or filtration. To have access to this menu, simply touch the tabs: Water Care menu - the little pen at the right of the wanted water care Touch the Economy tab to modify the economy schedules and Filter cycle tab for the filtration schedules.
  • Page 82 OTHER ACCESSORIES - IN.TOUCH 2 Spa Settings In the Settings page you can access the following: • in.touch network • Temperature units • Change spa name • Technical info To select an item, tap on the arrow next to it. It will open the selected menu.
  • Page 83 OTHER ACCESSORIES - IN.TOUCH 2 Change channel The Change channel page allows you to change the channel used by the two in.touch 2 modules. In some cases, this can help you to have a stronger signal. You can have access to this page by touching the following tabs: Spa settings (at the bottom right) - in.touch network - channel Temperature units...
  • Page 84 OTHER ACCESSORIES - IN.TOUCH 2 Name This section allows you to edit the name of the spa. You can have access to this page by touching the following tabs: Spa settings (at the bottom right) - Change spa name Technical Info This section shows information about the in.touch 2 software number and the revision numbers of the different components of your...
  • Page 85 OTHER ACCESSORIES - IN.TOUCH 2 Settings In the Settings page you can access the following: • Add a spa from local network • Account • Tutorial • *Legal • **Patents To select an item, tap on the arrow next to it. It will open the selected menu.
  • Page 86 OTHER ACCESSORIES - IN.TOUCH 2 Account This section gives you access to your account information. You can have access to this page by touching the following tabs: Settings (up right corner) - account Tutorial This section gives you a quick overview of your in.touch 2 application’s functions.
  • Page 87 OTHER ACCESSORIES - IN.TOUCH 2 Technical Support invitation When you receive an invitation for Technical Support, a red circle will be displayed next to the “setting” logo (top right corner). Authorizing an invitation All the invitations you may receive are under the dealers tab in the “settings”...
  • Page 88 OTHER ACCESSORIES - IN.TOUCH 2 Dealer page Once you’ve had a dealer on your in.touch 2 app, you can, at all times, have access to his information. If you don’t want your dealer to have access to your spa an- ymore, simply swap to the left the “Allow access to your spa”...
  • Page 89 Troubleshooting At any time, if the water temperature drops to 40°F (4.5°C), the resistive heater will give a boost to avoid freezing. The freeze protection will stay active until water temperature DIAGNOSTIC LED reaches the minimum allowed set point (usually 59°F / 15°C). The diagnostic LED will help you with the status of the con- Normal EXT mode will resume functioning thereafter.

  • Page 90: Wiring Diagram - W3000

    WIRING DIAGRAM - W3000 W3000...
  • Page 91 WIRING DIAGRAM - W3000 ELECTRICAL WIRING ELECTRICAL WIRING: W3000 (EUROPEAN) Refer to wiring diagram in the enclosure box lid for more information. 1-phase 2-phase 2-phase used from 3-phase 3-phase Delta – no neutral with single neutral L1 current returns with single neutral L1+L2 through neutral currents return through Use 2-phase setting...

  • Page 92: Breaker Setting

    BREAKER SET TING FOR COLOR DISPLAY KEYPAD GO IN SETTING MENU W3000 It is important to specify Choose the number of The values displayed by the phases supplying your spa the current rating of the system correspond to 80% Selecting number of phases GFCI/RCD used to ensure a (1 to 3).
  • Page 93 BREAKER SET TING POWER UP AND BREAKER SETTING IMPORTANT Please read the following before starting the device. Verify that all accessories are linked to the ground lug and connected to the to the control system. A minimum flow of 68 LPM (18 GPM) is required. Make sure that all valves are open in the spa plumbing and that the water flow is sufficient between the main pump and the water heater.

  • Page 94: Common Hardware Issues

    COMMON HARDWARE ISSUES Problem Usual Cause Solution – House circuit breaker tripped or in OFF System not operating – Reset circuit breaker on house breaker panel position – Add water to reach 6" (15.5 cm) below top – Water level too low lip of spa –...
  • Page 96 Version: 23.05_v1...
