Sibata MT-11 D Operation Manual

Fit tester
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CODE 080200-1100
Fit Tester
Operation Manual
(for Main Unit)
Thank you for purchasing this product.
●
This operation manual contains important safety information and product handling instructions.
●
Before use, read through this operation manual to ensure safe and proper use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT-11 D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sibata MT-11 D

Summary of Contents for Sibata MT-11 D

  • Page 1 CODE 080200-1100 Fit Tester Operation Manual (for Main Unit) Thank you for purchasing this product. ● This operation manual contains important safety information and product handling instructions. ● Before use, read through this operation manual to ensure safe and proper use.
  • Page 2 Every effort has been made to ensure that the information contained in this operation manual  is correct. If you discover any errors or omissions, however, please contact your Sibata representative. The copyright of this operation manual belongs to Sibata Scientific Technology Ltd. This ...

  • Page 3: Table Of Contents

    Table of Contents Safety Precautions ..................4 Users (Important)....................4 Graphical Symbols .................... 4 Caution Labels ....................6 About this Product ..................7 Overview ......................7 Measurement Principle ..................7 Precautions ...................... 10 Names of Parts ....................12 Preparation ....................13 Types of Data and Measurement Results ............

  • Page 4: Safety Precautions

    Sibata representative. Never operate the product if it is not functioning normally. Also, never allow anyone other than a qualified service engineer to disassemble or modify the product.
  • Page 5 Do not use this product in an environment where it is exposed to toxic gases, acidic or alkaline  substances, or anything other than air. Otherwise, a malfunction, explosion, or fire could result. If this product is used in a manner other than that specified by Sibata, the protective  functionality built into it could be lost.

  • Page 6: Caution Labels

    Be careful not to bump into the suction ports or the other protrusions. Although the corners and  other potentially hazardous areas on this product have been smoothed, be careful during handling. Otherwise, an injury could result. The materials used in this product (including accessories and optionally available parts) could ...

  • Page 7: About This Product

    2 About this Product Overview This measuring instrument checks the degree of adhesion when the user wears a respirator (disposable or replaceable type). Measurements can be performed in a general indoor space. Individuals have differently shaped faces. Many different types of respirators are sold by respirator manufacturers, so select a respirator that is a good fit to your face when it is worn.
  • Page 8 Quantification of the Degree of Adhesion of the Respirator  The method used to quantitatively assess the degree of adhesion between the respirator and the face of the person wearing the respirator is as follows. If there is a gap that particles can just pass through between the face of the wearer and the respirator, depending on the size of this gap, particles outside the respirator will penetrate inside the respirator during respiration.
  • Page 9 Block Diagram  OUTSIDE MASK Touch panel RS-232C output Control circuit Solenoid valve Classifier Condensation nucleus counter Exhaust (CNC) Filter Pump Purge  A purge time is established to exchange the air remaining inside the detector with air subject to measurement when measurement starts and during switching between OUTSIDE and MASK.

  • Page 10: Precautions

    Precautions Cautions When Carrying the Product  This measuring instrument is equipped with a detector and processor, so be careful not to bump or swing it when moving or handling it. Opening and Closing the Mirror  When opening and closing the mirror, support the main unit with one hand. Connecting to the Respirator ...
  • Page 11 Face Contact  There are some parts, such as the test guide, tube joint, etc., that touch or may touch your face. If you have any allergies, be sure to check that you are not allergic to any of the materials (see p.66).

  • Page 12: Names Of Parts

    Names of Parts Mirror Color LCD touch panel (pressure sensitive type) [POWER] switch Suction ports “MASK” “OUTSIDE” Alcohol cartridge insertion port USB connectors Stylus pen Type A: 2 ports, for USB flash drive, USB mouse, and USB keyboard Type B: 1 port, for connecting a PC RS232C external output connector (with cap)

  • Page 13: Preparation

    3 Preparation Types of Data and Measurement Results Data used for measurement include People, Respirator, Operator, and Protocol (Fit Test settings). These can be created using PC software and stored on a PC, transferred to a database file on a USB flash drive, or used in stand-alone measurements with this main unit. These types of data can also be created with the main unit.
  • Page 14 Inject alcohol up to the line at the bottom of the alcohol fill case. Insert the alcohol cartridge, and turn it clockwise until you feel a click. If you overfill it, the alcohol might overflow when the alcohol cartridge is re-inserted. Leave it as is for 2 to 3 minutes.
  • Page 15 After using the main unit, check that the power is OFF. Then remove the storage cap from the alcohol fill case. Remove the alcohol cartridge, and store it by inserting it into the alcohol fill case. Attach the storage cap to the alcohol cartridge insertion port. Do not leave the alcohol cartridge inserted into the main unit as is when not in use or during shipment.

  • Page 16: Supplying Power, Startup, And Shutdown

    Then connect the power cord at the other end to an AC outlet. If some problem is detected with the product, discontinue use immediately, unplug the power cord from the outlet, and contact the distributor where you purchased the product or your Sibata representative.

  • Page 17: Main Menu Screen

    OFF the [POWER] switch, and then turn it ON again. If the problem persists, the product may be malfunctioning. So, discontinue use immediately and contact the distributor where you purchased the product or your Sibata representative. Checking the Version Information 3-4-1 Touch [Ver.

  • Page 18: Basic Screen Configuration And Operations

    Basic Screen Configuration and Operations The following shows the basic configuration of the screen. Title area Field Title bar Subarea Operation keys Title area This displays the icons and title of the screen being displayed, and the current date and time. In the measurement mode screen, this also displays icons related to the measurement status.
  • Page 19 These are the basic operations in the selection and input screens. Settings configured Provisional setting Selection and input Selection only Select Input only Cancel key Factory reset key Save key Page key Selection and input With this item, touching the mark at the right edge enables selection from a pull down list.
  • Page 20 A numerical keypad is displayed for inputting only numerical values or figures. Close key Name of settings (settings range) Clear key Delete key Enter key Name of Settings Displays the details for the value being configured, and its settings range. Close key Touch this to cancel the entry and close the numerical keypad.

  • Page 21: Preparing For Measurement

    When the factory reset key is touched, a factory reset confirmation message is displayed. With the Fit Test settings only, factory reset affects the protocol being set, not the Fit Test settings as a whole (see p.40). [OK] Touch this to return the settings to the factory defaults. [Cancel] Touch this to cancel the operation and close the confirmation message.

  • Page 22: Selecting How To Connect To The Respirator

    Selecting How to Connect to the Respirator 3-6-2 Select how to connect to the respirator. To check the degree of “ Connecting and Test guide ⇒ ⇒ Wearing the Respirator adhesion of a respirator that will actually be worn Using the Test Guides”. Tube joint “...
  • Page 23 Attaching/Connecting the Tube Joint and Wearing the Respirator  Be careful not to pierce your hand or fingers with the tip of the tube joint attachment tool. Do not point the tip toward anyone. (1) Fit a tube joint to the convex side of the tube joint Tube Joint attachment tool provided.

  • Page 24: Checking The Particle Concentration In The Environmental Air

    Checking the Particle Concentration in the Environmental Air 3-6-3 For correct measurements, there must be a certain amount of particles in the environmental air. If there are too few particles during measurement, an alert will be displayed and the measurements will stop. (Regarding the minimum particle standards leading to the display of an alert, see p.43 for the Fit Check mode, and see p.44 for the other modes.) The particle concentration in the environmental air is checked as follows.

  • Page 25: Checking And Cleaning The Suction Ports

    Checking and Cleaning the Suction Ports 3-6-5 With extended use, or use in very dusty environments, contaminants can accumulate within the suction ports, reducing the intake of air, leading to an impact on the measurements. Check the interior of the suction ports periodically, and clean them if necessary (see p.60). As a diagnostic procedure, remove the sampling tube from the suction port, and switch repeatedly to the Fit Check mode (see p.36).

  • Page 26: Measurement

    4 Measurement Measurement Modes This product is equipped with four measurement modes. Reference Measurement Mode Description Page Measurements are performed in accordance with a preprogrammed sequence (protocol), and the leakage percentage, and fit factor/protection factor Fit Test mode are automatically calculated. Use this when selecting a respirator for each person and when having practice of wearing a P.31...

  • Page 27: Configuration Of The Measurement Mode Screen

    Configuration of the Measurement Mode Screen Each of the measurement modes shares the following basic screen configuration. Error icon Respirator mode icon Title bar Data area Utility space Main Menu key Step marks Settings key Error icon Errors are displayed here. Touch this to display a message related to the error details.
  • Page 28 The respirator mode icon displays the current respirator mode. 99+ mode: This is displayed when the mode set is for measuring respirators with a filter efficiency of at least 99 %. 95 mode: This is displayed when the mode set is for measuring respirators with a filter efficiency of less than 99 %.

  • Page 29: Daily Check Mode

    Daily Check Mode Touch [Daily Check] in the Main Menu screen. In the Daily Check mode, the system checks whether there is a sufficient number of particles in the measurement environment and whether the product is operating normally before starting the Fit Test.
  • Page 30 With the Daily Check, the high-performance zero check filter provided is used. Connect/disconnect the high-performance zero check filter as described in Guidance (1). Then proceed with measurements as per the operations in Guidance (2). Remaining time Progress bar NG (fail) mark Remaining time Displays the remaining time for all measurements as a numerical value.

  • Page 31: Fit Test Mode

    Fit Test Mode Touch [Fit Test] in the Main Menu screen. If you turn ON the power but do not perform a Daily Check, a confirmation message asking if you want to perform the Daily Check will be displayed. [Implement] Touch this to proceed to the Daily Check mode (see p.29).
  • Page 32 In order to set the measurement conditions, or to record the measurements, select the data in the following sequence. Person → Respirator・Mask size → Protocol → Operator Each selection key will blink in sequence, so select the data accordingly. If the conditions for starting measurements are met, the [Start] key will be enabled.
  • Page 33 High Fit Factor Alert (data area) Exercise display Remaining time Progress bar High Fit Factor Alert (step mark) Step marks Guidance (1) Guidance (2) NG (fail) mark First, an OUTSIDE measurement is performed and then a MASK measurement is performed. The measurements are repeated as many times as the number of the set steps.
  • Page 34 If you touch [Stop], a confirmation message asking if you want to stop the measurement will be displayed. Measurement will continue even while this message is displayed. [OK] Touch this to stop the measurement and return to “Waiting”. The measurement results for the steps to that point are not saved. [Cancel] Touch this to cancel the operation and restart the measurement.
  • Page 35 Touch the Change Current Step keys to change the display of results in the data area in sequence by step number. Touch the [List of results] tab to display a list of the measurement results for each step in the Fit Test.

  • Page 36: Fit Check Mode

    Fit Check Mode Touch [Fit Check] in the Main Menu screen. In the Fit Check mode, the leakage percentage is measured once. In order to confirm the degree of adhesion of the respirator before entering a workplace, use this mode using the test guides. Displays the preceding measurement results.
  • Page 37 First, an OUTSIDE measurement is performed and then a MASK measurement is performed for the same interval. Data area Displays the measurement results. “----” will be displayed in all value fields at the start of Fit Check mode, or when returning after configuring settings. The results display will update each time a measurement finishes.

  • Page 38: Training Mode

    Training Mode Touch [Training] in the Main Menu screen. In the Training mode, the real-time measurement is simply performed. Use this when having practice of wearing a respirator. Measurements of particle concentrations in the environmental air are performed here as well (see p.24). If a respirator wearing practice is held in the Training mode, do not perform the test as is with the Fit Test mode.
  • Page 39 An OUTSIDE measurement is first performed and then MASK measurements are performed consecutively. The results are compared between the first OUTSIDE measurement and the latest MASK measurement. “Preparing for Training” is displayed until the MASK measurement starts. “Measuring” is displayed during the MASK measurement, and the graph is plotted. When the “Outside sample cycle”...

  • Page 40: Settings

    5 Settings Setting Menu Touch [Settings] in the Main Menu screen, or touch [Setting menu] on the Database menu or in the sub area on the settings screen to display this screen. Touch the keys to configure the respective settings. Touch [Database menu] or [Main Menu] to display these screens.
  • Page 41 Protocol Select a protocol to browse and edit from the pull down list. When this is changed, other settings items as well will change to the settings for this protocol. Newly created protocols are marked with a “★”. Criterion Sets the criterion for evaluating the measurement results. For the criterion item, select from “Leakage”, “Fit Factor”, and “Protection Factor”.
  • Page 42 On page 2, the settings are configured for each step with respect to the protocol selected on page 1. Total measurement time Measurement time setting area Step number (exclusion setting) Exercise setting area Protocol Displays the protocol configured on page 1. Newly created protocols are marked with a “★”.

  • Page 43: Fit Check Settings

    Fit Check Settings The following screen is used to configure the settings for the Fit Check mode (see p.36). Min. Particle Check Sets the criterion value for displaying an error message if the OUTSIDE particle concentration is insufficient for calculating the measurement results.

  • Page 44: Daily Check Settings

    Daily Check Settings The following screen is used to configure the settings for the Daily Check mode (see p.29). Min. Particle Check Sets the particle concentration that will be the lower limit value for the Min. Particle Check. This also sets the value for the standard for displaying an error message if the OUTSIDE particle concentration is insufficient for calculating the measurement results.

  • Page 45: Training Settings

    Training Settings The following screen is used to configure the settings for the Training mode (see p.38). Criterion Sets the criterion for evaluating the measurement results. For the criterion item, select from “Leakage”, “Fit Factor”, and “Protection Factor”. Display range Select a candidate for the maximum value for the vertical axis in the line graph.

  • Page 46: Date/Time Settings

    Date/Time Settings The following screen is used to set the date and time. Current date and time Enter the current date and time. Display format Select a candidate for the format for the date and time display. When you change the setting and then touch [Save], if an impossible date (such as the February 31) has been set as the provisional setting, a confirmation message will be displayed.

  • Page 47: Basic Settings

    Basic Settings The following screen is used to configure the basic settings for this product. The Basic settings are configured in three pages. Factory resets and [Save] settings are performed separately for each page. The basic settings for the product are performed on page 1. Backlight Sets the length of time until the touch panel display goes dark when not in use.
  • Page 48 The cue sound settings are performed on page 2. When the cue sound is set, the product beeps at set intervals to assist with periodic operations during the measurements. Cycle Sets the time interval at which the cue sound beeps. The setting is the same for all modes.
  • Page 49 The settings for displaying alerts and the conditions for their occurrence are configured on page 3. For error details and procedures, see “9 Troubleshooting” (p.62). Min. particle Alert Sets whether to display an error message if the OUTSIDE particle concentration is insufficient for calculating the measurement results. The conditions for the occurrence of a Min.

  • Page 50: Touch Panel Correction

    Touch Panel Correction Correct the touch position on the touch panel. Try performing this correction if the operation performed does not match the position you touch on the screen. Touch the center of the red mark until the timer displayed at the center of the screen completes.

  • Page 51: Database

    The data operated using the Database menu and the Protocol settings (Fit Test settings, see p.40) are saved to the database file on the USB flash drive. In the unlikely event some sort of problem occurs, note Sibata accepts no responsibility for providing compensation for data that could not be acquired or recorded, loss of data or other content, or for any other direct or indirect damages involved.

  • Page 52: Database Selection

    Database Selection The following screen is used to select the database to use. Touching the Database selection key (see p.16) will also display this screen. Database Select the database to use from the pull down list. [Create new] Creates a new database. Touch this to display a screen for inputting the name of the database.

  • Page 53: Database Management

    Database Management The following screen is used to manage database. Database Select the database to manage from the pull down list. [Create new] Creates a new database. Touch this to display a screen for inputting the name of the database. [Clear data] Empties the database by deleting the data.

  • Page 54: People Data

    People Data The following screen is used to browse or create People data. The PC software is used to edit or delete the data. The items marked with an * are required when creating new data. Person Select the People data to display from the pull down list. Create new Creates new People data.

  • Page 55: Respirator Data

    Respirator Data The following screen is used to browse and create Respirator data. The PC software is used to edit or delete the data. The items marked with an are required when creating new data. Respirator Select the Respirator data to display from the pull down list. [Create new] Creates new Respirator data.

  • Page 56: Operator Data

    Operator Data The following screen is used to browse and create data on the Operator conducting the Fit Test. The PC software is used to edit or delete the data. The items marked with an are required when creating new data. Operator Select the Operator data to display from the pull down list.

  • Page 57: External Output

    7 External Output An optional printer is available as an external output device for this product (see p.65). In this case, connect the cable to the RS232C external output connector on the back of the main unit (see p.12), and on page 1 of the Basic settings (see p.47), set “Ext. output” to “Printer”. With external output, the output status and details differ depending on the measurement mode being used.
  • Page 58 In the Fit Test mode, data is printed every time a step finishes, and the overall results are printed at the end of the sequence. However, if Twice in Fit test is set at Outside sample times, all measurement results will be printed when the measurements finish. (For the Outside sample times, see p.40.) CR(0xD) LF(0xA) ←...

  • Page 59: Maintenance

    8 Maintenance Inspections and Maintenance AC Adapter  Before use, make sure that the power cord is not damaged. Use of a damaged power cord might cause electric shock or a short circuit. If the power cord is damaged, stop using it, and replace it with a new one.
  • Page 60 Suction Ports  With extended use, or use in very dusty environments, contaminants can accumulate within the suction ports, reducing the intake of air, leading to an impact on the measurements. Check the interior of the suction ports periodically (see p.25), and clean them if necessary. Check that the main unit is OFF.

  • Page 61: Operational Check With Clean Air

    The interior of the product is judged to be clean. If the measurement results for “Leakage” exceed 0.2 %: ● distributor The interior of the product must be cleaned. Contact the where you purchased the product or your Sibata representative. Consumables Consumables Life Replacement Pump Approx.

  • Page 62: Troubleshooting

    9 Troubleshooting If a problem occurs during use of the product, promptly stop using it. If the error has been caused by a product failure, do not reuse it and request repair. Problems sometimes occur for reasons other than malfunction. Before requesting repair, check the following.
  • Page 63 Symptom Possible Cause Remedy Insufficient alcohol Replenish the alcohol. Increase the particle concentration in the The particle concentration in the environmental air by using a particle environmental air is low. The OUTSIDE particle generator (optionally available). concentration is insufficient. The settings value for the error Lower the settings value for the Daily (The [Outside count is display is too high (Fit Test and...

  • Page 64: Main Specifications

    10 Main Specifications Item Code 080200-1100 Model MT-11D Evaluation of the degree of adhesion between the respirator and the Measurement Target surface of the face Measurement Items Number of particles, Leakage, Fit Factor, and Protection Factor Particle concentration is determined by the condensation nucleus counter (CNC).
  • Page 65 Consumables and Spare Parts  Item Code Product Name 080200-084 Sampling tube (pair tube) 1.5 m x 5 080200-085 Test Guide 10 pcs/set 080200-08211 Tube Joint Set Type M 100 pairs/set 080200-0831 Tube Joint Attachment Tool Type M 080200-033 High-Performance Zero Check Filter for Fit Tester MT Series 080200-100 Alcohol Cartridge 080200-101...
  • Page 66 Main Component Materials  Part Name Material Main Unit Case Aluminum, PPE+PS, EPDM Mirror PC, aluminum Panel Sheet Storage Cap PBT, EPDM Suction Port Nozzle Aluminum, stainless steel, FKM Stylus Pen High-Performance Zero Check Filter PP (PTFE), silicone Alcohol Cartridge Aluminum, PBT, EPDM, silicone Alcohol Fill Case Alcohol Wick...

  • Page 67: Warranty And Repairs

    Sibata. If you ignore the precautions in this manual or fail to create a backup, Sibata shall not be responsible for any damages resulting from lost or damaged data.
  • Page 68 23.12.20 K (03)
