Minimum Two
Persons Assembly
60 MIN
Approximate
Assembly Time
Regrettably self-assembly items cannot be returned once assembly is part or fully completed
unless the items are found to be faulty. Should you need to return the unassembled product,
please repack in its original packaging.
Important information
— We suggest you spend a short time reading through this leaflet and then follow the simple
step-by-step instructions.
— Carefully check that you have all the parts before beginning assembly.
— Keep fittings out of children's reach and keep children well away from construction area.
— We suggest you retain these instructions for future reference.
— In the unusual event of an issue with your product would you please quote the batch I.D.
number situated on the main parts of the frame (Head End- Foot End- side Rails).
Product information
— Upholstered Bed Using Fabric Material . Conforms to BS EN1725 & BS 5852.
Care instructions
— Avoid exposing the furniture to excessive heat or direct sunlight as this can cause cracking and
deterioration of the color.
— Periodically check & re-tighten any fastener .
— Periodically dust lightly with a clean soft cloth.
— Do not use silicone based furniture polish.
— Any spills should be removed immediately with a damp cloth.
— TAKE CARE WHEN MOVING THE FURNITURE AND NEVER DRAG THE PIECES ACROSS
THE FLOOR,AS THIS WILL CAUSE DAMAGE TO THE JOINTS.
KT00-12/05/2023
Sandra Bed Frame 135CM
STK778201/STK778204
Assembly instructions
Please keep these instructions for future reference.
Page 1 of 9
