SHARP SMART CONVECTION WALL OVEN WITH
INSTALLATION INSTRUCTIONS
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow
the safety alert symbol and one of the following words: DANGER, WARNING or CAUTION.
DANGER
WARNING
CAUTION
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury and tell you what can
happen if the instructions are not followed.
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
TINSK B 323MR R 0
MICROWAVE DRAWER
MODEL: SWB3085HS
YOUR SAFETY AND THE SAFETY OF OTHERS ARE VERY IMPORTANT.
An imminently hazardous situation. You could be killed or seriously injured if you don't
immediately follow instructions.
A potentially hazardous situation which, if not avoided, could result in death or serious
bodily injury.
A potentially hazardous situation which, if not avoided, may result in moderate or minor
injury.
OVEN
1
1
Aug 25, 2023

Advertisement

Table of Contents
loading

Summary of Contents for Sharp Drawer SWB3085HS

  • Page 1 SHARP SMART CONVECTION WALL OVEN WITH MICROWAVE DRAWER OVEN ™ MODEL: SWB3085HS INSTALLATION INSTRUCTIONS YOUR SAFETY AND THE SAFETY OF OTHERS ARE VERY IMPORTANT. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.
  • Page 2: Installation Requirements

    • CUL Listed Wire Connectors PARTS PROVIDED: • #8- " Screws (8) TECHNICAL DATA ELECTRICAL RATINGS AND MAXIMUM CONNECTED LOAD OVEN MODEL @ 240 VOLTS 60 HZ Sharp Smart Convection Wall Oven with SWB3085HS 40 AMP 950 WATTS (CUL) Microwave Drawer Oven ™...
  • Page 3: Product Dimensions

    PRODUCT DIMENSIONS A Height 45" B Width 29 " C Depth 24 " D 42 " E 40 " F Width with handle 26 " G AC cord length 48"...
  • Page 4: Opening Dimensions

    OPENING DIMENSIONS A Cutout height 43 " F Standard cabinet depth 24" B Cutout width 28 " G Standard countertop height 36" C Cutout minimum depth 24" H Cabinet height 80" D Top of cutout to top of Control Panel 1 "...
  • Page 5: Electrical Requirements

    ELECTRICAL REQUIREMENTS ELECTRICAL CONNECTION To properly install your oven, you must determine the type of If codes permit and a separate ground wire is used, it is recommended electrical connection you will be using and follow the instructions that a qualified electrical installer determine that the ground path is provided for it here.
  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS IMPORTANT: This appliance shall be installed only by authorized 3 Grasp the edges of the oven door with both hands, keeping the door persons and in accordance with the manufacturer’s installation slightly ajar. Lift up and pull oven door toward you to remove. Set instructions, local gas fitting regulations, municipal building codes, the oven door(s) aside on a covered work surface.
  • Page 7: Step 4 - Install Oven

    STEP 4 - INSTALL OVEN STEP 5 - MAKE ELECTRICAL CONNECTION WARNING To properly install your oven, you must determine the type of electrical connection you will be using and follow the instructions EXCESSIVE WEIGHT HAZARD provided for it here. Use two or more people to move and install oven.
  • Page 8 3-WIRE CONNECTION (GROUNDED NEUTRAL) 4-WIRE CONNECTION (UNGROUNDED NEUTRAL) 4-WIRE CABLE FROM HOME POWER SUPPLY WARNING IMPORTANT: Use the 4-wire cable from home power supply in the U.S. where local codes do not allow grounding through neutral. 1 Disconnect power. ELECTRICAL SHOCK HAZARD Grounding through the neutral conductor is prohibited for new branch-circuit installations (1996 NEC);...
  • Page 9: Step 6 - Mount The Oven

    STEP 6 - MOUNT THE OVEN STEP 7 - REPLACE THE DOOR IMPORTANT: The oven door is heavy and fragile, and the door 1 Slide the oven completely into the cabinet until the back surface of the front frame touches the front wall of the cabinet. Center front is glass.
  • Page 10: Step 9 - Complete Installation

    • When the oven has been operating for five minutes, feel for heat. If you do not feel heat or if an error message appears on the display, turn off the oven and contact 1-800-BE-SHARP. • Tap Cancel to turn off the oven.
  • Page 11 SHARP ELECTRONICS CORPORATION 100 Paragon Drive • Montvale, New Jersey 07645 • 1-800-BE-SHARP (237-4277) SHARP ELECTRONICS OF CANADA LTD. 335 Britannia Road East Mississauga • Ontario L4Z 1W9 • 877-278-6709...
  • Page 13: Instructions D'installation

    FOUR MURAL INTELLIGENT À CONVECTION DE SHARP AVEC FOUR MICRO-ONDES TIROIR MICROWAVE DRAWER ™ MODÈLE SWB3085HS INSTRUCTIONS D’INSTALLATION VOTRE SÉCURITÉ ET LA SÉCURITÉ DES AUTRES SONT TRÈS IMPORTANTES. Nous avons fourni plusieurs messages de sécurité importants dans ce manuel et sur votre appareil. Toujours lire et suivre tous les messages de sécurité.
  • Page 14: Exigences Concernant L'emplacement

    • Vis no 8- po (8) DONNÉES TECHNIQUES CARACTÉRISTIQUES ÉLECTRIQUES ET CHARGE MAXIMALE FOUR MODÈLE CONNECTÉE @ 240 VOLTS 60 HZ Four mural intelligent à convection Sharp avec four micro-ondes tiroir Microwave SWB3085HS 40 A 950 W (CUL) Drawer ™...
  • Page 15: Dimensions Du Produit

    DIMENSIONS DU PRODUIT A Hauteur 114,3 cm (45 po) B Largeur 76,04 cm (29 C Profondeur 62,23 cm (24 D 108,59 cm (42 E 102,71 cm (40 F Largeur avec poignée 67,15 cm (26 G Longueur du cordon c.a. 121,92 cm (48 po)
  • Page 16 DIMENSIONS D'OUVERTURE A Hauteur de l’ouverture 109,86 cm (43 E Bas de l’ouverture jusqu’au sol 45,40 cm (17 B Largeur de l’ouverture 72,87 cm (28 F Profondeur standard de l’armoire 60,96 cm (24 po) C Profondeur minimum de l’ouverture 60,96 cm (24 po) G Hauteur standard du comptoir 91,44 cm (36 po) D Dessus de l’ouverture au-dessus du panneau de commande H H Hauteur des armoires 203,2 cm (80 po)
  • Page 17: Exigences Électriques

    EXIGENCES ÉLECTRIQUES CONNEXION ÉLECTRIQUE Pour installer correctement votre four, déterminer le type de con- Si les codes le permettent et qu’un fil de mise à la terre séparé est nexion électrique à utiliser et suivre les instructions fournies ici. utilisé, il est recommandé qu’un installateur électrique qualifié détermine que le chemin de mise à...
  • Page 18 INSTRUCTIONS D’INSTALLATION IMPORTANT : Cet appareil ne doit être installé que par des 3 Saisir les bords de la porte du four avec les deux mains, en main- personnes autorisées et conformément aux instructions d’installation tenant la porte légèrement entrouverte. Soulever et tirer la porte du fabricant, aux réglementations locales relatives aux raccords de du four vers soi pour la retirer.
  • Page 19 ÉTAPE 4 – INSTALLER LE FOUR FIL DIRECT MISE EN GARDE MISE EN GARDE RISQUE DE POIDS EXCESSIF Il faut au moins deux personnes pour déplacer et installer le four. Le non-respect de cette consigne peut entraîner des blessures au dos ou d’autres blessures. RISQUE D’ÉLECTROCUTION 1 À...
  • Page 20 2 Relier les deux fils noirs B à l’aide d’un connecteur homologué CONNEXION À TROIS FILS (MISE À LA TERRE CUL. NEUTRE) 3 Connecter les deux fils neutres (blancs) C et le fil de terre (vert ou MISE EN GARDE nu) d (du câble du four) à...
  • Page 21 ÉTAPE 6 – INSTALLER LE FOUR ÉTAPE 7 – REPLACER LA PORTE DU FOUR IMPORTANT : La porte du four est lourde et fragile, et la façade 1 Glisser le four complètement dans l’armoire jusqu’à ce que la surface arrière du cadre avant touche la paroi avant de l’armoire. de la porte est en verre.
  • Page 22: Étape 9 - Terminer L'installation

    5 Vérifier le fonctionnement du micro-ondes ÉTAPE 9 – TERMINER L’INSTALLATION • Sur la page d’accueil, appuyer sur Lower Microwave Oven 1 Vérifier que toutes les pièces sont maintenant installées. S’il reste une pièce supplémentaire, retourner aux étapes précédentes pour •...
  • Page 24 SHARP ÉLECTRONIQUE DU CANADA LTÉE. 335, rue Britannia Est, Mississauga (Ontario) L4Z 1W9 • 877-278-6709...
