Vulcan-Hart GH30 Specifications

Model GH30C
Shown with 17" backguard
SPECIFICATIONS
Heavy duty radial n hot top gas range with oven, Vulcan-Hart
Model No. GH30. Stainless Steel body and 6" adjustable legs. 1
diameter front gas manifold. Radial n hot top with ceramic re
brick provides graduated heat from 900° center to 300° outside
area. Three concentric cast ring burners with separate manual
controls. Inner ring 10,000 BTU/hr., middle ring 15,000 BTU/hr.,
outer ring 20,000 BTU/hr. Pilot ignition. Oven interior measures
26"w x 28"d x 14"h. Porcelain enamel on steel hearth, door and
side liners. One oven rack and two rack positions. 50,000 BTU/hr.
heavy cast "Flame Retention" burner with pilot ignition.
Thermostat adjusts from 150° to 500°F. Controls located in the
cool zone.
Exterior dimensions: 34"w x 39
6" legs.
CSA design certi ed. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-31510 (05/06)
"
⁄
1
4
⁄ "d x 36" working height on
1
8
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL GH30
RADIAL FIN HOT TOP HEAVY DUTY GAS RANGE
GH30 Standard Oven
GH30C Convection Oven
Standard Base
GH30S
STANDARD FEATURES
Stainless steel body and 6" adjustable legs.
1 ⁄ " diameter front gas manifold.
1
4
Radial n hot top with ceramic re brick provides graduated
heat from 900° center ring to 300° outside area. Three
concentric cast ring burners with separate manual controls.
Inner ring 10,000 BTU/hr., middle ring 15,000 BTU/hr., outer
ring 20,000 BTU/hr. Pilot ignition.
Oven controls located in the cool zone.
Oven interior measures 26"w x 28"d x 14"h. Porcelain enamel
on steel hearth, door and side liners. One oven rack and two
rack positions. 50,000 BTU/hr. "Flame Retention" burner
with pilot ignition. Thermostat adjusts from 150° to 500°F.
One year limited parts and labor warranty.
OPTIONS
Snorkel convection oven in place of standard oven. Add
TM
su x "C" to the model number. Porcelain enamel on steel
interior measures 26 ⁄
1
racks and ve rack positions. 32,000 BTU/hr. burner with
pilot ignition. Thermostat adjusts from 200° to 500°F.
blower motor with 7 foot power cord and plug. 120/60/1,
5 amps.
Stainless steel back nishing panel.
Common front top ledge up to 68" wide. (Not for use on
griddle tops, spreader plates and deep fat fryers.)
Cap and cover manifold end(s). (No charge.)
1 ⁄ " stainless steel toe base - 31
5
8
Set of four 5" diameter casters, two locking.
Stainless steel dolly frame with casters, up to 102" wide.
Cooling fan for Snorkel
when unit is installed with a back nishing panel or a toe base.
Rear gas connection. (Reference spec sheet F-31525.)
Second year extended limited parts and labor warranty.
650° Thermostat Statement.
Stainless steel center shelves on cabinet base units statement.
Cabinet storage base in place of standard oven. Add the
su x "S" to the model number.
C.S.I. Section 11420
" w x 22 ⁄ " d x 14 ⁄ " h. Three oven
3 1
8 32 8
⁄ " working height.
5
8
convection oven motor. Required
TM
⁄ H.P.
1
4
