Summary of Contents for Treesat FMC920
- Page 2 There is also an ignition lock function. Detailed functionalities of individual products can be found at treesat.io. The device is ideal for applications where location acquisition of distant objects is required.
- Page 3 Installation manual FMC920 - version 23.07 MOUNTING THE DEVICE IN THE VEHICLE When mounting the device in a vehicle, remember to avoid sensitive places that may suppress the GSM and GPS signal. The best place to mount the device is its installation under elements made of plastic, e.g.: upholstery, post, etc.
- Page 4 Installation manual FMC920 - version 23.07 IGNITION CUT-OFF CONNECTION DIAGRAM Remote ignition cut-off is only possible for Car Assistant services To be sure of operation, perform a function test “Ignition cut off” in the mobile application. Connection in the car Relay pin description info@treesat.io...
-
Page 5: Operation Check
Installation manual FMC920 - version 23.07 OPERATION CHECK After connecting the device, check its correct operation by observing the diodes. Behavior of the “Status” LED (GSM): ● The LED blinks every second – normal operation, GSM signal has been stabilized. - Page 6 Log in to the Web application – you will receive login details by e-mail. The device has been added to your account by Treesat. Create a vehicle in the system and assign the number of the mounted device. Your devices are in the drop-down list.
-
Page 7: Technical Specifications
Installation manual FMC920 - version 23.07 TECHNICAL SPECIFICATIONS GNSS ● 2G/4G: B2, B3, B5, B7, B8, B20, B28 ● GPS, GLONASS, GALILEO, BEIDOU, ● LTE Cat 1 SBAS, QZSS, DGPS, AGPS ● Tracking: 33 channels interface ● Sensitivity -165 dBM ●... -
Page 8: Contact Details
Installation manual FMC920 - version 23.07 SIGNS CE mark. This marking informs that the device complies with the terms of Directive 2014/30/EU regarding the compliance of Member States with electromagnetic compatibility regulations and the terms of Directive 2014/35/EU regarding compliance by Member States with low voltage regulations and safety related to the operation of electrical equipment.
