Summary of Contents for Treesat FMC150
- Page 2 Detailed functionalities that can be used by the User by installing FMC150 in the vehicle can be found at treesat.io.
- Page 3 Log in to the Web application – you will receive login details by e-mail. The device has been added to your account by Treesat. Create a vehicle in the system and assign the number of the mounted device. Your devices are in the drop-down list.
- Page 4 Installation manual FMC150 - version 23.01 CONNECTION AND WIRE DESCRIPTION Color Destiny Installation tips Powering the device Connect to a permanent power supply via a 3A fuse Black Device weight Connect to ground Brown and CAN device 1 Connect to car directly or using ECAN02...
- Page 5 Installation manual FMC150 - version 23.01 The CAN module must be connected to the appropriate CAN network of the vehicle so that so that all expected information is sent to the system! OPERATION CHECK After connecting the device, check its correct operation by observing the diodes.
- Page 6 Installation manual FMC150 - version 23.01 TECHNICAL SPECIFICATIONS GNSS ● GSM: B2/B3/B5/B8 ● GPS, GLONASS, GALILEO, BEIDOU, ● LTE FDD: B1/B3/B7/B8/B20/B28 SBAS, QZSS, DGPS, AGPS ● Tracking: 33 channels interface ● Sensitivity -165 dBM ● 3 digital input, 2 analog input ●...
- Page 7 Installation manual FMC150 - version 23.01 SIGNS CE mark. This marking informs that the device complies with the terms of Directive 2014/30/EU regarding the compliance of Member States with electromagnetic compatibility regulations and the terms of Directive 2014/35/EU regarding compliance by Member States with low voltage regulations and safety related to the operation of electrical equipment.
