Instruction
assembly
FMC920 GATE CONTROL MODULE
v 23.07
WARNINGS
Please read this manual before proceeding with the installation. All connection
operations must be performed without the power supply connected. For security
reasons, the module should be installed by specialists with appropriate qualifications.
It is not allowed to interfere with the structure or carry out independent repairs.
Advertisement
Related Manuals for Treesat FMC920
Summary of Contents for Treesat FMC920
- Page 1 Instruction assembly FMC920 GATE CONTROL MODULE v 23.07 WARNINGS Please read this manual before proceeding with the installation. All connection operations must be performed without the power supply connected. For security reasons, the module should be installed by specialists with appropriate qualifications.
-
Page 2: List Of Devices
5. SPAMEL LK\269 limit switch (one or 2 pcs. depending on the user's requirements regarding information on the gate status) - optional * no additional devices can be purchased from Treesat except for the FMC920 gate control module. 2. DESCRIPTION To meet the expectations of the dynamically changing market of mobile services, Treesat Sp. - Page 3 (and will provide a verification code to be entered in the assembly report) 4. ASSEMBLY OF THE DEVICE Attention! We mount the FMC920 module away from metal elements, sideways printed on the outside of the housing. TECHNICAL SPECIFICATION of the FMC920 module ●...
- Page 4 The FMC920 module can be connected to the controlled device in 3 ways: A. Using an additional 230V 1.25A power supply and an additional control relay - the preferred method is completely isolated from the controlled device, B.
- Page 5 Connect the closed gate limit switch to the gray FMC920 wire, and connect the open gate limit switch to the yellow FMC920 wire. We can also connect only one signal, e.g. a closed gate - in this case we lose information about the gate movement, which will be displayed as an open gate.
- Page 6 Connect the closed gate limit switch to the gray FMC920 wire, and connect the open gate limit switch to the yellow FMC920 wire. We can also connect only one signal, e.g. a closed gate - in this case we lose information about the gate movement, which will be displayed as an open gate.
- Page 7 4C. EXAMPLE OF CONNECTION DIAGRAM IF 230V VOLTAGE IS NOT AVAILABLE AND 12-24VDC IS AVAILABLE Attention! Connection does not require any additional accessories. The FMC920 is connected directly to the gate controller. Before connecting, check whether the accessory power supply output has sufficient current capacity (min.
- Page 8 We connect the signal to the gray wire of FMC920 when the gate is closed, and to the yellow wire of FMC920 we connect the signal when the gate is open. After installation, provide information about whether both limit sensors are connected (if one, which one) to the person adding the device in the application in order to properly set the limit switch options.
- Page 9 * The information presented above regarding the gate control terminals are only indicative data and require verification with the installation manual provided by the manufacturer of the automatic machine. Treesat is not responsible for damage caused in case of incorrect connection of the device.
- Page 10 Treesat Sp. z o. o. is not liable for damages resulting from improper use of the Click2open system and incorrect installation of the control module. Before installing the device, check whether the gate manufacturer allows the installation of external devices.
- Page 11 The symbol of the crossed-out waste bin attached to the product means that the product is covered by the European Directive 2002/96/EC. Information on separate collection points for waste electrical and electronic products can be obtained from the place of residence.
