- Page 2 Detailed functionalities that can be used by the User by installing FMB125+CAN in the vehicle can be found at treesat.io.
- Page 3 Log in to the Web application – you will receive login details by e-mail. The device has been added to your account by Treesat. Create a vehicle in the system and assign the number of the mounted device. Your devices are in the drop-down list.
- Page 4 Installation manual FMB125+CAN - version 22.04.07 CONNECTION AND WIRE DESCRIPTION Color Destiny Installation tips Powering the device Connect to a permanent power supply Black Device weight Connect to ground Yellow and blue CAN device Connect to Teltonika CAN module (e.g. ALL-CAN300) info@treesat.io...
- Page 5 Installation manual FMB125+CAN - version 22.04.07 CAN MODULES The following CAN modules can be connected to the FMB125 device: LV-CAN200 and ALL-CAN200 CAN CONTROL You can also use ECAN01 to not interfere with the car's CAN installation: ECAN01 The CAN module must be connected to the appropriate CAN...
- Page 6 Installation manual FMB125+CAN - version 22.04.07 OPERATION CHECK After connecting the device, check its correct operation by observing the diodes. Behavior of the “Status” LED (GSM): ● The LED blinks every second – normal operation, GSM signal has been stabilized.
- Page 7 Installation manual FMB125+CAN - version 22.04.07 TECHNICAL SPECIFICATIONS GNSS ● Quad band 850/900/1800/1900MHz ● GPS, GLONASS, GALILEO, BEIDOU, ● GPRS class 12 SBAS, QZSS, DGPS, AGPS ● Tracking: 33 channels interface ● Sensitivity -165 dBM ● 1 digital input, 1 analog input ●...
- Page 8 Installation manual FMB125+CAN - version 22.04.07 SIGNS CE mark. This marking informs that the device complies with the terms of Directive 2014/30/EU regarding the compliance of Member States with electromagnetic compatibility regulations and the terms of Directive 2014/35/EU regarding compliance by Member States with low voltage regulations and safety related to the operation of electrical equipment.
