  • Page 1 User guide EOS 8 ©2023...

  • Page 2: Table Of Contents

    Logging in..............35 4.10.3 Enabling for Service access........37 4.10.4 Synchronisation with network........39 Brunner App..............40 Emergency Operation..........42 Heating with manually controlled combustion air supply..42 Cleaning................ 44 Changing the battery...........44 Caution messages............45 User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 3 Subject to technical changes! Please keep the User Guide for future reference! Waste on fire = Toxins in your garden © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 4: Registration

    In connection with a BHZ, for example, it is possible to operate the complete system comfortably from one place. It is possible to connect extra displays to the EOS 8. In this case, the heating sys- tem can be operated from each connected display. If further systems, like BHZ for example, are using the data bus technology, then the entire system can be op- erated from each connected display.
  • Page 5 All sensors, actuators, pumps, etc. are connected to the electronics of the EOS 8. The EOS 8 display unit is connected to the control unit with a connecting cable. Display The display of EOS 8 is divided into three fields.

  • Page 6: Functional Principle Mybrunner Local

    It is important that your device is also connected to the same home net- work! NOTE: This feature works only through the myBRUNNER app. User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 7 © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 8: Licenses

    For the visualization of our user interface we use an open source operating sys- tem, which is subject to different license models. You can see the licenses used in the software under the menu: „Settings“→“Display“→“Licenses/Contact“ User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 9: Operation

    Under 'Settings' one finds the possibilities to configure the EOS 8 and to adapt it to your installation. Select the menu option and enter the pin code 9999.

  • Page 10: Menu

    In the menu some basic functions of the EOS can be programmed. The possibilities depend on the configured installation. 4.1.1 NETWORK ADVERTS Display with a myBRUNNER connection Display for an existing network connection, whether WLAN or LAN. User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 11: Combustion Log

    Heat up er- How often a heat up error was detected when Heat up error counter lighting a fire. Heating er- How often a heating error was detected during Heating error counter combustion. © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 12: Display Customization

    Stove hot counter How often the threshold value was exceeded. DISPLAY CUSTOMIZATION The display of the EOS 8 is customizable with different display options. This chapter describes all possible settings for display options. Tap the softkey Settings and enter your PIN code.
  • Page 13 Illustration 3: Display cus- or left tomization - Brightness 4. Confirm by pressing O.K. → The settings are applied. You can set the length of the long sound, which indicates errors or status messages. © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 14 3. Set the desired time (in seconds): a) by tapping + or - b) by moving your finger on the sliding bar to the right or left 4. Confirm by pressing O.K. → The settings are applied. User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 15 3. Confirm by pressing O.K. → The settings are applied. Automatic daylight saving time To enable automatic switching between Summer and Winter time, you must set the time zone of your residence. © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 16 4. If the language setting is changed, the control unit will restart; 5. The control unit will restart after tapping O.K. to confirm → The control unit is initialized again, and the language is changed. User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 17: Eco-Function

    Touching the tiled stove symbol in the upper navigation bar leads to the tiled stove information page. Above on the left in the middle navigation field now the symbol for the Eco-function appears. © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 18: Lighting Fire In A Cold Fireplace

    Please note: big logs are not easy to light and heavy to burn in a cold fireplace. Never use petrol or alcohol as aids for lighting fire! User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 19: Adding Fuel In A Warm Fireplace

    Closing the door is the signal for the EOS that a heating proce- dure is started. On the display the markings and messages appear as described in the chapter 'Lighting fire in a cold fireplace' . © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 20: Winter/Summer-Operation

    EOS if possible. Stove priority makes that the switching flap does not switch to the boiler function; the burn-up is always done over the stove (smoke channels). User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 21: Type Of Wood

    Set in this case, the type of wood on hardwood. Menu / Wood Soft wood = short combustion type/ Mixt wood = normal combustion Hard wood= extended combustion © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 22: 4.10 Remote Access Via Mybrunner

    4.10 REMOTE ACCESS VIA MYBRUNNER 4.10.1 REGISTRATION 1. Start the first registration 1.1. Go to www.mybrun- ner.de; 1.2 Click the button Regis- ter now; This window/box appears: User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 23 1.6 Optionally - for in- creased security - you can enter your mobile phone number. 1.7. Click next to complete your entries on this page. © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 24 Your meaningful year number? Your favorite restaurant? Please enter a valid answer, which will be used later for confirmation. 1.10 Click the button Register now when finished. 1.11 The details of your registration will be shown: User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 25 2.1 Open the e-mail from “websystem” and subject line: “Brunner Zentrale Benutzerverwaltung: Registrierungsbestäti- gung” (Brunner Central User Administration: Con- firmation of registration) 2.2 Click on the link; 3. Login 3.1 Click Login © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 26 New Control Neues Bedienteil. NOTE: If you had previously registered a different control unit, click the Add another control unit button Weit- eres Bedienteil hinzufügen. 4. Activate the network User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 27 Settings 4.2 Enter the PIN Code 9999 4.3 Click on the control display button Bedien- teil 4.4 Click on the my- Brunner button 4.5 Navigate down with the arrow key: © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 28 4.1 Click in the upper menu bar on Settings 4.2 Enter the PIN-Code 9999 4.3 Click on the display button Bedienteil 4.4 Click on the display button myBrunner 4.5 Navigate down with the arrow key: User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 29 4.6 Set up WLAN: - Select WLAN name. if the name you are looking for is not avail- able for the WLAN name, click on search Suche 4.7 Enter WLAN-Pass- word and click O.K. © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 30 4.8 Navigate up with the arrow key 4.9 Click: 5. Set up mybrunner on Touch Display 5.1 Click: User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 31 Touch Display (control pan- el). This number is dis- played for 2 hours. You should use this reg- istration code for your control unit to continue the registration on the © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 32 7. Registration of your Brunner system 7.1 The control unit (touch display) of the Brunner system must be registered. To do this, click the New Control Unit button Neues Bedi- enteil. NOTE: If you had previously registered a different control unit, click the Add another control unit button here.
  • Page 33 8. Complete registration on Touch Display 8.1 Confirm the mes- sage about successful registration with O.K. 8.2 Exit settings (with © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 34 The Parameter sections under Settings are excluded. During remote access you will see the follow- ing identical screen on the Touch Display: → The registration process is complete. User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 35: Logging In

    Login page at mybrunner.de, in the “Kennwort” field. If you want to change your password again, or change your contact data, or apply extended security settings, please go to Mein Profil (My Profile). © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 36 The current overview of your system will appear on the screen of your PC, notebook, tablet or smartphone. On the Touch Display of your BRUNNER system To see the myBRUN- NER status click: Set- tings + PIN-Code (9999) / Bedien-...

  • Page 37: Enabling For Service Access

    4.10.3 ENABLING FOR SERVICE ACCESS To enable Service access for BRUNNER technicians or a heating contrac- tor, the owner of the system must approve it first. This is done using a fixed Service PIN Code, which is defined in the User account.
  • Page 38 Enter this 6-digit numer- ic PIN code in the first field (PIN) and in the second field (purpose of release) please write your family name and lo- cation of the system. User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 39: Synchronisation With Network

    The system operator can revoke the tradesman or BRUNNER service’s access to the system at any time. When access is granted, the following message is displayed: When a contractor has access to your system via myBRUNNER link, you'll see the following on the Touch Display: 4.10.4...

  • Page 40: Brunner App

    The disabled time alignment is dis- played with a gray box. The adjustment of the time or date with the BRUNNER network can be activated at any time. BRUNNER APP The myBRUNNER App makes it easier to access the heating system with smartphones or tablets.
  • Page 41 Account settings or registration of control panels can not be done with the app. Account settings or registration of control panels can not be done with the app. Both activities are only possible via a browser via mybrun- ner.de. © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 42: Emergency Operation

    HEATING WITH MANUALLY CONTROLLED COMBUSTION AIR SUPPLY In the case of a power failure as well as in the case of device errors, your heating insert with EOS 8 can be controlled manually. Proceed as follows: • Attach the operating tool to the square bar of the air valve motor.
  • Page 43 The air valve should never be put in this position during the burning and degassing phase, as by sudden oxygen admission (for ex. opening of the firing door) the in the combustion chamber “standing gases” can re- act with the oxygen. © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 44: Cleaning

    Moisten a cloth with the glass cleaner and then wipe off the glass plate. CHANGING THE BATTERY If the message “Change battery”, appears on the display, please replace the 9 Volt block battery in the EOS 8 control unit. User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 45: Caution Messages

    In a normal situation, there are no faulty components! Caution messages are dis- played and confirmed by the user with O.K. If the caution messages are still active, they are visible in the Messages window. © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 46 Make a break before • putting more wood into your stove or fireplace. The stove/fireplace is working in unfavorable operating conditions. User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 47 Cleaning could not be done in a given time. Cleaning must be made in a no-heating pe- riod, when the combustion cham- ber is cold. © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 48: Error Massages

    No signal from the buffer tank Replace the temperature sen- Pt1000 buffer sen- temperature sensor. sor defect Temperature sensor is damaged Replace cable cable broken or disconnected. Reconnect cable Limited emergency operation is possible. User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 49 Check wiring and correct it. K2 positioning error K2 cannot reach the set position Check the terminal resistors. Bus wiring is faulty Check combustion air flap Jammed mechanics. mechanics. Manual operation is still pos- sible © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 50 * EOS with damper flap actuator WARNING Contact your stove setter! After the error is fixed, the error message must be confirmed. Therefore, please touch the highlighted icon of the Info page and then select 'Reset'. User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 51: Update Of The Control Unit

    45 minutes with older display versions, so allow enough time). The update process should not be interrupted. DO NOT touch the display (touch field) during the entire update process. © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 52: 11.1 Software From Pc On The Usb-Stick

    1. You will receive an email with a link -> click on the link: 2. A dialog window opens in which you should click on Datei speichern (Save file) 3. Confirm with OK User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 53 6. Now select the zip file with a right click and click on Hier entpack- 7. The unzipped files for updating the control are displayed: 8. Remove the USB stick from the PC (Auswerfen) © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 54: Software From Usb-Stick On The Control Unit

    Variant 2 = The control is disconnected from the power supply 11.2.1 VARIANT 1 1.To remove the display unit, insert the supplied tool (1) at the top between the wall and the glass front and release the lock with light pressure. User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 55 IMPORTANT: Check that the USB stick is correct- ly inserted and seated! Press the Settings button on the home screen Enter the PIN code 9999 confirm with OK © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 56 Update fond...appears => the Up- date loads the data. Wait a few minutes until the text Bitte USB-Stick entfernen (Please remove USB stick) appears on the displayt. Then follow the indications on the display. User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 57: Variant 2

    8. Remove the USB key from display unit; 9. Switch on the power supply for the complete system; → As part of the update process, the system will reboot and the update is finished. © 2023 Brunner GmbH User guide EOS 8 (1.10)

  • Page 58: What To Do If The Update Does Not Start

    Please indicate the item number of the display and the currently installed software version (see picture). The arti- cle number can be found on the back of the display printed on the sticker (article no.Exxxxxx). User guide EOS 8 (1.10) © 2023 Brunner GmbH...

  • Page 59: Remove Of The Touch-Display

    REMOVE OF THE TOUCH-DISPLAY To remove the EOS 8 Display unit, insert the supplied tool (1) above between wall and glass front and loosen the lock with light pressure. © 2023 Brunner GmbH User guide EOS 8 (1.10)
  • Page 60 User guide EOS 8 (1.10) © 2023 Brunner GmbH...
  • Page 61 Ulrich Brunner GmbH BRUNNER products are offered and sold exclusively by quali- fied dealers and service centres. Zellhuber Ring 17-18 Technical and range-related changes as well as errors re- D-84307 Eggenfelden served. All images may contain additional functions or special equip- Tel.: +49 (0) 8721/771-0...
