A Modbus PCB needs to be connected on a FWF or FWC unit which has its own
NOTE
remote controller address.
I
Maximum 8 Modbus PCBs can be connected on a 0.75 mm
I
Maximum 15 FWF or FWC units can be connected on a FWF or FWC unit which
has its own remote controller address.
I
The cable terminal (resistor) is integrated in the Modbus PCB and is enabled by
NOTE
means of a DIP switch (SS2).
I
In case the Modbus PCB is used as cable terminal (refer to "E:
Modbus communication line on page
otherwise it must be set to OFF.
I
DIP switch SS1 must always be set to OFF.
Installation manual
6
5"), the DIP switch SS2 must be set to ON,
2
wire.
Termination of the
