- Page 1 INSTALLATION MANUAL Remote user interface EKRUMC...
- Page 2 x100h x100h...
- Page 3 Serial module µ chiller compact 4 5 6 7 8 9...
- Page 4 USE, ALWAYS CONTACT YOUR DAIKIN DEALER FOR ADVICE AND INFORMATION. NTRODUCTION Thank you for purchasing the EKRUMC remote user interface. This remote user interface will enable you to control the chiller remotely in the same way you can control the chiller locally.
- Page 5 Connect the remote user interface to the address card with the appropriate cable with a maximum distance of 150 m. Cable: 6-pole shielded cable, with twisted pair cable (0.25 mm ) (field supply) EKRUMC Installation manual Remote user interface 4PW16029-1...
- Page 6 OFF. The figure shows the default setting. buzzer on buzzer off The setting of the dipswitch has to be performed NOTE before fixing the remote user interface to the wall. Installation manual EKRUMC Remote user interface 4PW16029-1...
- Page 7 Select parameter code h8 using the A and/or Z key. Press the R key to switch to the parameter value. Select the appropriate setting using the A and/or Z key. Press the R key to return to the list of parameter codes. EKRUMC Installation manual Remote user interface 4PW16029-1...
- Page 8 In the second case, the display starts flashing. Approximately 40 seconds later, the controller leaves the list of user parameters without saving the modifications. The inlet water temperature reappears on the display. Installation manual EKRUMC Remote user interface 4PW16029-1...
-
Page 9: User Interface
LEDs providing extra user information. All buttons that are present on the digital controller are also present on the remote user interface. Figure: Remote user interface EKRUMC Installation manual Remote user interface 4PW16029-1... - Page 10 A and Z keys on the digital controller on the unit simultaneously for approximately 5 seconds. The extra button can be used to select three different contrast levels on the display of the remote user interface. Installation manual EKRUMC Remote user interface 4PW16029-1...
- Page 11 Additional alarm The “vn” alarm code appears on the screens when the remote user interface is disconnected. To reset the alarm, refer to the chapter “Resetting alarms” in the operation manual of the unit. EKRUMC Installation manual Remote user interface 4PW16029-1...
- Page 12 Zandvoordestraat 300, B-8400 Oostende, Belgium 4PWEN16029-1...
