MaxLite maxLED MLLWP40LED50DS 150 Series Operating Instructions

Operating Instructions
®
MaxLite
LED LARGE WALL PACK (CUTOFF & STANDARD)

General Safety Information

• To reduce the risk of death, personal injury or property damage
from fire, electric shock, falling parts, cuts/abrasions, and other
hazards read all warnings and instructions included with and on the
fixture box and all fixture labels.
• Before installing, servicing, or performing routine maintenance
upon this equipment, follow these general precautions.
• Commercial installation, service and maintenance of luminaires
should be performed by a qualified licensed electrician.
• For Residential installation: If you are unsure about the installation
or maintenance of the luminaires, consult a qualified licensed
electrician and check your local electrical code.
• DO NOT INSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and
grounded UL listed junction box.
WARNING:
RISK OF ELECTRICALSHOCK
• Turn off electrical power at fuse or circuit breaker box before
wiring fixture to the power supply.
• Turn off the power when you perform any maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label information.
• Make all electrical and grounded connections in accordance with the National Electrical Code and any applicable local code
requirements.
• All wiring connections should be capped with UL approved wire connectors.
CAUTION:
RISK OF INJURY
• Wear gloves and safety glasses at all times when removing luminaire from carton, installing, servicing or performing maintenance.
• Avoid direct eye exposure to the light source while it is on.
• Account for small parts and destroy packing material, as these may be hazardous to children.
CAUTION:
RISK OF FIRE
• Keep combustible and other materials that can burn away from luminaire and lamp/lens.
• MIN 90°C SUPPLY CONDUCTORS.
Illustrations on the manual are for installation purposes only. It may not be identical to the fixture purchased.
MLLWP40LED50DSXXXX-150 120-277V 50/60 Hz
MLLWP70LED50DSXXXX-150 120-277V 50/60 Hz
MLLWP60LED50XXXX-150 120-277V 50/60 Hz
MLLWP40LED50XXXX-150 120-277V 50/60 Hz
Model options:
If XX=UH, voltage input 347-480V
If XXXX = PC12, voltage input 120V 50/60 Hz
If XXXX = PC27, voltage input 208-277V 50/60 Hz
