Operating Instructions
MaxLite LED Medium Area Light
®
General Safety Information
• To reduce the risk of death, personal injury or property damage from fire,
electric shock, falling parts, cuts/abrasions, and other hazards read all
warnings and instructions included with and on the fixture box and all
fixture labels.
• Before installing, servicing, or performing routine maintenance upon
this equipment, follow these general precautions.
• Commercial installation, service and maintenance of luminaires
should be performed by a qualified licensed electrician.
• DO NOT INSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and
grounded UL listed junction box.
WARNING:
RISK OF ELECTRICALSHOCK
• Turn off electrical power at fuse or circuit breaker box before wiring fixture
to the power supply.
• Turn off the power when you perform any maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label
information.
• Make all electrical and grounded connections in accordance with the National Electrical
Code and any applicable local code requirements.
• All wiring connections should be capped with UL approved wire connectors.
CAUTION:
RISK OF INJURY
• Unit will fall if not installed properly. Follow installation instructions.
• Wear gloves and safety glasses at all times when removing luminaire from carton, installing,
servicing or performing maintenance.
• Avoid direct eye exposure to the light source while it is on.
• Account for small parts and destroy packing material, as these may be hazardous to children.
CAUTION:
RISK OF FIRE
• Keep combustible and other materials that can burn away from luminaire and lamp/lens.
• MIN 75°C SUPPLY CONDUCTORS.
Models:
Example: AR60, AR100, AR140, AR210 and AR280 Series
Operating characteristics:
Operating temperature: -40°C to 55°C
Input voltage range: 100-277, 347-480V, 50/60 HZ
© Copyright 2018. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com
Picture is for illustration purposes only.
Your model may vary.
AR Series
Page: 1
REV: 5/21/18

Advertisement

loading
Need help?

Need help?

Do you have a question about the AR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for MaxLite AR Series

  • Page 1 Example: AR60, AR100, AR140, AR210 and AR280 Series Operating characteristics: Operating temperature: -40°C to 55°C Input voltage range: 100-277, 347-480V, 50/60 HZ © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 1 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 2 • Connect the power lead properly, make wirings inside the straight arm, and tighten the arm door with screws (see FIG.5). • Inspect installation to ensure fixture is secure. © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 2 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 3 Operating Instructions AR Series MaxLite LED Medium Area Light ® Straight Arm Pole Drill Pattern © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 3 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 4 (50.80mm) (7.00mm) 0.43” (53mm) 0.28” (11mm) (7.00mm) (5.70mm) 2.08” (75mm) (53mm) 0.22” (5.70mm) 2.95” (75mm) © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 4 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 5 (63.50mm) (3.29mm) (12.00mm) 0.28” (7.00mm) 0.22” (5.70mm) 2.54” + 0.30 (64.40mm) - 0.00 2.95” (75mm) © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 5 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 6 • Loosen and adjust the adjusting bolts to the right angle, and the maximum is 60°(see FIG.12). • Make wiring connection (see WIRING), • Inspect installation to ensure fixture is secure. © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 6 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 7: Maintenance

    Make sure to use WAGO connector properly to ensure proper and secure wiring, make sure of correct wiring before restoring power supply to light up the fixture. © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 7 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 8 5. FIG.16 is for wirings when dimmable driver, surge protector, FSP-211 sensor are used. FIG.16 © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 8 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 9 NOTE: The Outside Fixture Wall thickness should be no greater than 0.125"(3.18mm) for optimal sensor mounting and security. © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 9 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 10 High or Low level, based on motion detection, until the ambient light increases above the photocell setpoint. © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 10 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 11 FSP-211 sensor parameters such as high/low mode, sensitivity, time delay, cut off, and more. With the FSIR-100 you can also establish and store FSP-211 parameter profiles. © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 11 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 12 Every time the commissioning tool establishes communication with the FSP-211, the controlled load will cycle. © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 12 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 13 Check for blinking red LED. If the LED blinks with long pulses, as opposed to short pulses, the sensor has reached its Hold Off setpoint or Photocell Light Level setpoint. © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 13 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 14 Position and secure House Side Shield in place with (2) existing M4 x 14mm and (4) M4 x 6mm stainless steel screws, flat washer and split locker washer. See Fig 3. © Copyright 2018. MaxLite, Inc. All Rights Reserved. Page: 14 12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com REV: 5/21/18...
  • Page 15: Warranty Information

    MaxLite or its authorized distributor/dealer (the “Warranty Period”), as follows: If a Product fails to operate during the Warranty Period as a result of defects in materials or workmanship, MaxLite will, at its option, repair it, replace it with the same or like Product.
