Campbell 109SS Instruction Manual

Temperature probe
Hide thumbs Also See for 109SS:
Table of Contents

Advertisement

Quick Links

Download this manual
Model 109SS
Temperature Probe
Revision: 4/18
C o p y r i g h t
©
1 9 8 3 - 2 0 1 8
C a m p b e l l
S c i e n t i f i c ,
I n c .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 109SS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Campbell 109SS

Summary of Contents for Campbell 109SS

  • Page 1 Model 109SS Temperature Probe Revision: 4/18 C o p y r i g h t © 1 9 8 3 - 2 0 1 8 C a m p b e l l S c i e n t i f i c ,...
  • Page 4 (780) 454-2655. Campbell Scientific (Canada) Corp. is unable to process any returns until we receive this form. If the form is not received within three days of product receipt or is incomplete, the product will be returned to the client at the client’s expense.
  • Page 5 Periodically (at least yearly) check electrical ground connections. WHILE EVERY ATTEMPT IS MADE TO EMBODY THE HIGHEST DEGREE OF SAFETY IN ALL CAMPBELL SCIENTIFIC PRODUCTS, THE CLIENT ASSUMES ALL RISK FROM ANY INJURY RESULTING FROM IMPROPER INSTALLATION, USE, OR MAINTENANCE OF TRIPODS, TOWERS, OR ATTACHMENTS TO TRIPODS AND TOWERS SUCH AS SENSORS, CROSSARMS, ENCLOSURES, ANTENNAS, ETC.
  • Page 6 PLEASE READ FIRST About this manual Please note that this manual was originally produced by Campbell Scientific Inc. (CSI) primarily for the US market. Some spellings, weights and measures may reflect this origin. Some useful conversion factors: Area: 1 in...

  • Page 8: Table Of Contents

    Table of Contents PDF viewers: These page numbers refer to the printed version of this document. Use the PDF reader bookmarks tab for links to specific sections. 1. Introduction ..............1 2. Precautions ..............1 3. Initial Inspection ............1 4.
  • Page 9 109SS thermistor probe schematic ............7 Tables 7-1. Wire Color, Function, and Datalogger Connection ......5 C-1. 109SS Thermistor Resistance and Temperature ......C-1 CRBasic Examples B-1. 109SS Program for CR300-Series, CR800-Series, CR1000, CR1000X-Series, CR3000, and CR5000 Dataloggers ....B-1 B-2.

  • Page 10: Introduction

    Short Cut is an easy way to program your datalogger to measure the 109SS probe and assign datalogger wiring terminals. Short Cut is available as a download on www.campbellsci.com. It is included in installations of LoggerNet, PC200W, PC400, or RTDAQ.
  • Page 11 Model 109SS Temperature Probe In the search box under the Available Sensors and Devices heading, type in 109 or find the 109 in the Sensors | Temperature folder. Double-click the 109 Temperature Probe. Data defaults to degree Celsius. This can be changed by clicking the Deg C box and selecting Deg F, for degrees Fahrenheit, or K, for Kelvin.

  • Page 12: Overview

    This design protects the thermistor, allowing the 109SS to be buried or submerged in harsh, corrosive environments. It can be submerged in water to 45 m (150 ft) or 63 psi. See Section 6, Specifications , for a complete list of compatible dataloggers.

  • Page 13: Specifications

    Model 109SS Temperature Probe Specifications Features: Measures soil or water temperature • Compatible with AM16/32-series multiplexers • Easy to install or remove • Durable • • Compatible with the following CRBasic dataloggers: CR200(X) series, CR300 series, CR6 series, CR800 series, CR1000,...

  • Page 14: Installation

    Model 109SS Temperature Probe Compliance: View the EU Declaration of Conformity at www.campbellsci.com/109ss Overall probe accuracy is a combination of thermistor interchangeability, bridge-resistor accuracy, and error of the Steinhart-Hart equation. Interchangeability is the principle component error. If needed, an estimate of the interchangeability error for 0 to 50 °C, that can be used as the Offset parameter of the Therm109() instruction, can be determined with a 1-point or 2-point calibration.

  • Page 15: 7.2.1 Therm109() Instruction

    (p. 8) Water Temperature Installation 109SS probes can be submerged to 45 m (150 ft) or 63 psi. The 109SS is not weighted, so a weighting system should be added, or the probe secured to a submerged object such as a piling.

  • Page 16: Operation

    ⏚ — Analog Ground FIGURE 8-1. 109SS thermistor probe schematic Measurement and Output Linearization CRBasic instruction Therm109() measures the 109SS probe thermistor and automatically converts the result to temperature. With reference to the previous FIGURE 8-1, 109SS thermistor probe schematic, Therm109() applies 2500 mV excitation at the Vx line and measures the voltage drop across the 24.9 kΩ...

  • Page 17: Electrically Noisy Environments

    The 60 Hz and 50 Hz integration options include a 3 ms settling time; longer settling times can be entered into the Settling Time parameter. Campbell Scientific suggests doubling the settling time every 50 ft of cable length. The following code snip examples increase settling time by 20000 µs by placing...

  • Page 18: Troubleshooting And Maintenance

    If needed, an estimate of the interchangeability error for 0 to 50 °C, that can be used as the Offset parameter of the Therm109() instruction, can be determined with a 1-point or 2-point calibration. Calibration of the 109SS probe is not necessary unless the accuracy needed in the sensor data requires correction of the thermistor interchangeability offset described in Section 6, Specifications (p.

  • Page 20: Importing Short Cut Code Into Crbasic Editor

    Appendix A. Importing Short Cut Code Into CRBasic Editor This tutorial shows: How to import a Short Cut program into a program editor for • additional refinement How to import a wiring diagram from Short Cut into the comments of •...

  • Page 22: Example Programs

    This following example can be used directly with most of our CRBasic dataloggers. CRBasic Example B-1. 109SS Program for CR300-Series, CR800-Series, CR1000, CR1000X-Series, CR3000, and CR5000 Dataloggers 'Program measures one 109SS temperature probe once a second and 'stores the average temperature every 60 minutes. 'Wiring Diagram '==============...
  • Page 23 NextScan EndProg The following example can be used directly with CR200(X)-series dataloggers. CRBasic Example B-3. 109SS Program for CR200(X)-Series Dataloggers 'Program measures one 109SS temperature probe once a second and 'stores the average temperature every 60 minutes. 'Wiring Diagram '==============...

  • Page 24: Conversion Of Thermistor Resistance Or Voltage Ratio To Temperature

    Appendix C. Conversion of Thermistor Resistance or Voltage Ratio to Temperature TABLE C-1. 109SS Thermistor Resistance and Temperature 10K3MCD1 CRBasic Actual Thermistor Therm109() Temperature (°C) Resistance (Ω) Output (°C) 336103.2 -40.00 314558 -39.00 294529.1 -38.00 275900.8 -37.00 258567 -36.00 242430.2 -35.00...
  • Page 25 Appendix C. Conversion of Thermistor Resistance or Voltage Ratio to Temperature 29500.5 2.00 28054.4 3.00 26687.5 4.00 25395 5.00 24172.5 6.00 23015.9 7.00 21921.2 8.00 20884.7 9.00 19903.2 10.00 18973.3 11.00 18092.2 12.00 17256.9 13.00 16464.9 14.00 15713.7 15.00 15000.9 16.00 14324.5 17.00...
  • Page 26 Appendix C. Conversion of Thermistor Resistance or Voltage Ratio to Temperature 2673.9 58.00 2578.6 59.00 2487.1 60.00 2399.4 61.00 2315.2 62.00 2234.4 63.00 2156.8 64.00 2082.3 65.00 2010.8 66.00 1942.1 67.00 1876 68.00 1812.6 69.00 1751.6 70.00 1693 71.00 1636.6 72.00 1582.4 73.00...
