Nureva HDL410 &
CamConnect Pro
Setting Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the HDL410 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nureva HDL410

Summary of Contents for Nureva HDL410

  • Page 1 Nureva HDL410 & CamConnect Pro Setting Guide...
  • Page 2 Discovering/ Enrolling HDL410 Preface: • Accessing Nureva Console • Enrolling HDL410 (console method) • Editing/defining room dimensions Copyright © Lumens. All rights reserved.
  • Page 3 1. Access and enroll HDL410 Access Nureva console: https://www.nureva.com/software-and-services/console Note: There are 2 methods to enroll; 1. USB method and 2. Nureva console. (Nureva console is shown here) • For USB method see here (console client) https://support.nureva.com/faqs-nureva-console/generate-enrollment-code-with-nureva- console-client Copyright © Lumens. All rights reserved.
  • Page 4 1. Access and enroll HDL410 Enrolling HDL410 (console): 1.2.1 enter your enrollment code (located at the bottom of console- hardware). 1.2.2 You will be prompted to enter room level details- see next section Copyright © Lumens. All rights reserved.
  • Page 5 • Accessing room level settings • Editing/defining room dimensions • Defining Room Dimensions for optimum performance • Fine tuning room in relation to seating arrangements and HDL410 ports • Recalibrating HDL410 in defined room Copyright © Lumens. All rights reserved.
  • Page 6 2. Setting up HDL410 in room (room level settings) Defining room type: Shown below is [type =Meeting room]. HDL410 supports up to 8 types (classroom, open space and others). Copyright © Lumens. All rights reserved.
  • Page 7 2. Setting up HDL410 in room (room level settings) Accessing room level settings; Your newly created room will appear in rooms section, click on [room name] to access. Copyright © Lumens. All rights reserved.
  • Page 8 2. Setting up HDL410 in room (room level settings) Editing/defining room dimensions: (HDL40 works as if were a single unit.) Copyright © Lumens. All rights reserved.
  • Page 9 (this will take you to room coverage map) Important: 1.Measure your room space and place HDL410 port 1 and 2 as precise as possible. 2. In my demo, the actual room size is bigger than the defined dimensions. For optimized performance ( to reduce reverberations, echos and background noise).
  • Page 10 2.Setting up HDL410 in room (room level settings) Fine tuning room in relation to seating arrangements and HDL410 ports: - An example for depiction purposes only is shown here, adjust your HDL410 port positioning as needed based on environment and usage scenario.
  • Page 11 Recalibrating HDL410 in defined room: Note: After enrolling and defining room level settings, recalibrate HDL410 in finished room. This ensures all settings are kept and HDL410 “is aware” of environmental/room level changes. General rule = If there are room level changes, recalibrate your HDL410.
  • Page 12 CamConnect Pro (AI-BOX1) Settings Copyright © Lumens. All rights reserved.
  • Page 13 Connected State_AiBox and HDL410 Preface: • Allow HDL410 to send data to CamConnect • Three Basic connection Steps • Fine tuning and mapping of seating positions (Azimuth angles in CamConnect) with HDL410 Copyright © Lumens. All rights reserved.
  • Page 14 3. Connecting CamConnect with HDL410 Allow HDL410 to send data to CamConnect. Use port [8931] & enter Camconnect`s IP address [Ex. 192.168.11.11]. ※Nureva default port is 8931. Please confirm the port is allowed to connect with your PC. Copyright © Lumens. All rights reserved.
  • Page 15 Below items are found under [Supported Device & Settings] HDMI/Web interface. From Device drop down list select = HDL410. Enter HDL410`s IP address = [example : Device IP = 192.168.11.27]. IP of HDL410 can be found as shown in 3.1.
  • Page 16 Connecting CamConnect with HDL410 Fine tuning and mapping of seating positions (Azimuth angles in Camconnect) with HDL410. - In Advanced setting of CamConnect; set the [Audio Trigger level = 65] or stay close to 60 depending on environment. - Camconnect automatically provides 8 Azimuth Angles (these angles are adjustable for fine tuning per environment).
  • Page 17 Thank You! MyLumens.com Contact Lumens...
