Nureva Dual HDL300
Setting Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual HDL300 and is the answer not in the manual?

Questions and answers

Related Manuals for Nureva Dual HDL300

Summary of Contents for Nureva Dual HDL300

  • Page 1 Nureva Dual HDL300 Setting Guide...
  • Page 2 Nureva Dual HDL300 1. Get Hardware connection Copyright © Lumens. All rights reserved.
  • Page 3 1.1 Get Hardware connection Cable define Cat5e HDMI cable USB 2.0 cable Nureva Dual HDL300 Microphone CamConnect Processor Display (AI-BOX1) HDL300 connect module Lumens PTZ Camera Meeting Room PC Display (Windows OS) Copyright © Lumens. All rights reserved.
  • Page 4 Nureva Dual HDL300 2. Install & step by Nureva Console client Copyright © Lumens. All rights reserved.
  • Page 5 2.1 Install Nureva Console client Using Console client for step Nureva DHL300   Download [Console Client] https://support.nureva.com/97341-download/win-mac-download-nureva-console-client Copyright © Lumens. All rights reserved.
  • Page 6 2.2 Setup Nureva Console client After Nureva Console client setup is completed, launch Console client app and USB cable connect from Nureva connect module to PC Copyright © Lumens. All rights reserved.
  • Page 7 2.3 Setup Nureva Dual HDL300 integration A: Drag the vertical scroll bar of the Console client down B: Scroll down until you see the 'Integrations' option C: Click the down arrow of [Local integrations] Copyright © Lumens. All rights reserved.
  • Page 8 2.4 Setup camera tracking integration A: Click the scroll bar to enable [Network integration settings] B: Copy this IP, and we will use it to fill it in [Device IP] of CamConnect Pro C: Fill the IP of CamConnect Pro and Enter. Copyright ©...
  • Page 9 A: Fill the IP which copy from Nureva Console client [Network integration settings] B: Press [Apply] button and the toggle [connect] bar to enabled ※Nureva default port is 8931. Please confirm the port is allowed to connect with your PC. Copyright © Lumens. All rights reserved.
  • Page 10 Nureva Dual HDL300 3. Set angle position setting Copyright © Lumens. All rights reserved.
  • Page 11 3.1 Setup angle position setting Note: “Azimuth Angle” maximum angle range is from -70 to +70 degrees, which makes 0 degree as its center point. The schematic diagram above shows a sound source detected in the 0 degree region. Copyright © Lumens. All rights reserved.
