HDL300 audio conferencing system

Installation requirements and recommendations

Recommended room size

Square footage

Minimum: 8.0ˈ x 8.0ˈ (2.4 x 2.4 m)

Maximum 20.0ˈ x 20.0ˈ (6.1 x 6.1 m)

Integrated microphone and speaker bar recommended installation height

Minimum recommended installation height: 7.1ˈ (2.2 m)

Maximum recommended installation height: 10ˈ (3.0 m)

Minimum: 8.0ˈ (2.4 m)

Maximum: N/A

The microphone array is located along the bottom edge of the microphone and speaker bar. Ensure the

installation location meets the following requirements and recommendations to optimize microphone

pick up.

When installing the system, ensure the microphone and speaker bar has adequate clearance between

the bottom of the bar and any objects located directly below the bar.

Table of Contents

Do you have a question about the HDL300 and is the answer not in the manual?

Page 1 HDL300 audio conferencing system Installation requirements and recommendations Recommended room size Square footage Minimum: 8.0ˈ x 8.0ˈ (2.4 x 2.4 m) Maximum 20.0ˈ x 20.0ˈ (6.1 x 6.1 m) Integrated microphone and speaker bar recommended installation height Minimum recommended installation height: 7.1ˈ (2.2 m) Maximum recommended installation height: 10ˈ...
Page 2 2. Do not install the microphone and speaker bar above hardware with fans. Hanging the product above hardware with fans, such as flat panel displays, can cause interference with the microphone pickup. 3. Allow for adequate space between the outside edges of the speaker bar and the corners of the room Installing the microphone and speaker bar against the corner of a room will impede the microphone pickup.
Page 3 Placing the bar into a recessed area of the room will negatively affect the microphone pickup. ®2017 Nureva Inc. All rights reserved. Nureva and the Nureva logo are trademarks of Nureva Inc. in the United States, Canada and other countries.
