Owner’s Manual Industrial-Grade Models: U360-004-IND USB 3.2 Hub U360-007-IND U360-010-IND Important Safety Instructions Features System Requirements Package Contents Powering the Hub Mounting Kit Installation Specifications Warranty Español 12 Français 23 Deutsch 34 Italiano 45...
Before attempting to connect, operate or adjust this product, please read the entire Owner’s Manual first. Important Safety Instructions • Always read the safety instructions carefully • Keep this Owner’s Manual for future reference • If any of the following situations arise, schedule an appointment to have your equipment inspected by a service technician: º...
Page 3
Features • Increases the number of SuperSpeed USB ports from a single computer port (4 ports for U360-004-IND model / 7 ports for U360-007-IND model / 10 ports for U360-010-IND model) • USB 3.2 compliant with data transfer rates up to 5 Gbps •...
System Requirements • Compatible with all USB-enabled operating systems Package Contents • U360-004-IND, U360-007-IND or U360-010-IND Industrial-Grade USB 3.2 Hub • USB 3.2 cable • 3-pin power terminal block • DIN mounting hardware • Wall-mount hardware • Owner’s Manual Powering the Hub DC-In To power the hub, plug the user-supplied power adapter into the wall outlet.
Mounting Kit Installation Mounting Hardware Installation The U360-004-IND, U360-007-IND and U360-010-IND hubs can be placed on a flat surface, or mounted using the included wall-mount brackets or DIN rail hardware. Reference the diagram below when installing the mounting hardware. Wall-Mount Hardware Installation To install the wall-mount brackets, insert the bracket tabs into the slots on the bottom of the unit and then pull outward to lock into...
Page 6
Mounting Kit Installation DIN Rail Hardware Installation Using the included hardware, mount the DIN rail to the side of the unit. DIN rail Screw (x2)
Page 7
Mounting Kit Installation Note: The U360-007-IND and U360-004-IND’s dimensions are the same; the only difference between the two models is the number of USB ports. 80.00 50.00 34.00 15.00 15.00 17.00 19.00 17.00 14.20 14.20 14.20 14.20 14.20 14.20 25.00 19.00 16.00 23.00...
Specifications Item Description Ports 4 x USB 3.2 (U360-004-IND model) 7 x USB 3.2 (U360-007-IND model) 10 x USB 3.2 (U360-010-IND model) ESD Protection +/- 20 kV EFT Protection +/- 2.5 kV Transmission Speed Up to 5 Gbps Power Requirement Bus-power 9-40V DC power supply 3-pin terminal (9-40V DC)
The user must use shielded cables and connectors with this equipment. Any changes or modifications to this equipment not expressly approved by Eaton could void the user’s authority to operate this equipment.
Page 11
Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended. Eaton has a policy of continuous improvement. Specifications are subject to change without notice. Eaton...
Manual del Propietario Hub USB 3.2 de Grado Modelos: U360-004-IND Industrial U360-007-IND U360-010-IND Instrucciones de Seguridad Importantes Características Requisitos del Sistema Contenido del Empaque Alimentación del Hub Instalación del Juego para Montaje Especificaciones Garantía English 1 Français 23 Deutsch 34 Italiano 45...
Antes de intentar conectar, operar o ajustar este producto, por favor primero lea el Manual del Propietario completo. Instrucciones de Seguridad Importantes • Lea siempre con cuidado las instrucciones de seguridad • Conserve este Manual del Propietario para consulta futura •...
Page 14
Características • Aumenta el número de puertos USB SuperSpeed desde un solo puerto de computadora (4 puertos para modelo U360-004-IND / 7 puertos para modelo U360-007-IND / 10 puertos para modelo U360-010-IND) • El USB 3.2 cumple con tasas de transferencia de datos hasta 5 Gbps •...
Requisitos del Sistema • Compatible con todos los sistemas operativos habilitados para Contenido del Empaque • Hub USB 3.2 de Grado Industrial U360-004-IND, U360-007-IND o U360-010-IND • Cable USB 3.2 • Bloque de terminales de alimentación de 3 pines • Accesorios de instalación DIN •...
Page 16
Instalación del Juego de Montaje Instalación de los Soportes de Montaje Los hubs U360-004-IND, U360-007-IND y U360-010-IND pueden colocarse sobre una superficie plana o instalarse usando los soportes para instalación en pared o los accesorios para riel DIN. Consulte el diagrama siguiente al instalar los accesorios de montaje. Instalación de los Soportes para Instalación en Pared Para instalar los soportes para instalación en pared, inserte las pestañas del soporte en las ranuras en la parte inferior de la unidad...
Page 17
Instalación del Juego de Montaje Instalación con los Accesorios para Riel DIN Usando los accesorios incluidos, instale el riel DIN en el costado de la unidad. DIN rail Screw (x2)
Page 18
Instalación del Juego de Montaje Nota: Las dimensiones del U360-007-IND y el U360-004-IND son las mismas; la única diferencia entre ambos es el número de puertos USB. 80.00 50.00 34.00 15.00 15.00 17.00 19.00 17.00 14.20 14.20 14.20 14.20 14.20 14.20 25.00 19.00...
Especificaciones Rubro Descripción Puertos 4 USB 3.2 (modelo U360-004-IND) 7 USB 3.2 (modelo U360-007-IND) 10 x USB 3.2 (modelo U360-010-IND) Protección ESD +/- 20 kV Protección EFT +/- 2.5 kV Velocidad de Hasta 5 Gbps Transmisión Requerimiento de Alimentado por Bus Energía Alimentación de 9-40V CD Terminal de 3 pines (9-40V CD)
Page 21
Nuestra obligación bajo esta garantía está limitada a la reparación o reemplazo (a su entera discreción) de cualquier producto defectuoso. Antes de devolver cualquier equipo para reparación, visite Tripplite.Eaton.com/support/product- returns. Esta garantía no se aplica a equipos que hayan sido dañados por accidente, negligencia o mal uso, o hayan sido alterados o modificados de alguna manera.
Page 22
Eaton tiene una política de mejora continua. Las especificaciones están sujetas a cambio sin previo aviso. Eaton...
Manuel d'utilisation Hub USB 3.2 de Modèles : qualité industrielle U360-004-IND U360-007-IND U360-010-IND Consignes de sécurité importantes Caractéristiques Configuration requise Contenu de l'emballage Alimentation de l'hub Installation du kit de montage Spécifications Garantie English 1 Español 12 Deutsch 34 Italiano 45...
Avant d'essayer de connecter, d'utiliser ou de régler ce produit, veuillez d'abord lire l'intégralité du manuel d'utilisation. Importantes consignes de sécurité • Lisez toujours attentivement les consignes de sécurité • Conservez ce manuel d'utilisation pour référence ultérieure. • Si l'une des situations suivantes se présente, prenez rendez-vous pour faire inspecter votre équipement par un technicien de maintenance : º...
Caractéristiques • Augmente le nombre de ports USB SuperSpeed à partir d'un seul port d'ordinateur (4 ports pour le modèle U360-004-IND/ 7 ports pour le modèle U360-007-IND/ 10 ports pour le modèle U360-010-IND). • USB 3.2 conforme aux taux de transfert de données jusqu'à 5 Gbit/s •...
Configuration système requise • Compatible avec tous les systèmes d'exploitation dotés d'un port USB Contenu de l'emballage • Hub USB 3.2 U360-004-IND, U360-007-IND ou U360-010-IND de qualité industrielle • Câble USB 3.2 • Bornier d'alimentation à 3 broches • Matériel de montage DIN •...
Page 27
Installation du kit de montage Installation du matériel de montage Les hubs U360-004-IND, U360-007-IND et U360-010-IND peuvent être placés sur une surface plane ou montés à l'aide des supports muraux inclus ou du matériel pour rail DIN. Reportez-vous au diagramme ci- dessous lors de l'installation du matériel de montage.
Page 28
Installation du kit de montage Installation du matériel pour rail DIN À l'aide du matériel inclus, montez le rail DIN sur le côté de l'unité. Guida DIN Rail DIN Vis (x2) Vite...
Page 29
Installation du kit de montage Remarque : les dimensions des modèles U360-007-IND et U360-004-IND sont identiques ; la seule différence entre les deux modèles réside dans le nombre de ports USB. 80,00 50,00 34,00 15,00 15,00 17,00 19,00 17,00 14,20 14,20 14,20 14,20...
à la réparation ou au remplacement (à notre seule discrétion) de tout produit défectueux. Veuillez consulter le site Tripplite.Eaton.com/support/product-returns avant d'envoyer un produit pour le faire réparer. Cette garantie ne s'applique pas aux équipements qui ont été...
Page 33
équipement entraîne la défaillance de l'équipement de maintien de vie ou affecte de manière significative sa sécurité ou son efficacité, n'est pas recommandée. Eaton mène une politique d'amélioration continue. Les caractéristiques peuvent être modifiées sans préavis.
Page 34
Betriebsanleitung Industrietauglicher Modelle: USB 3.2-Hub U360-004-INDl U360-007-INDl U360-010-INDl Wichtige Sicherheitshinweise Eigenschaften Systemanforderungen Inhalt des Pakets Stromversorgung des Hubs Einbau des Montagesatzes Spezifikationen Garantie English 1 Español 12 Français 23 Italiano 45...
Bevor Sie versuchen, dieses Produkt anzuschließen, zu bedienen oder einzustellen, lesen Sie bitte zuerst die gesamte Betriebsanleitung. Wichtige Sicherheitshinweise • Lesen Sie die Sicherheitshinweise immer sorgfältig durch • Bewahren Sie dieses Benutzerhandbuch zum späteren Nachschlagen • Sollte eine der folgenden Situationen eintreten, vereinbaren Sie bitte einen Termin mit einem Servicetechniker zur Inspektion Ihres Geräts: º...
Page 36
Ausstattung • Erhöht die Anzahl der SuperSpeed-USB-Anschlüsse an einem einzigen Computeranschluss (4 Anschlüsse für das Modell U360-004-IND / 7 Anschlüsse für das Modell U360-007-IND / 10 Anschlüsse für das Modell U360-010-IND) • USB 3.2-kompatibel mit Datenübertragungsraten von bis zu 5 Gbit/s • Abwärtskompatibel mit USB 2.0 und 1.x • Robustes Ganzmetallgehäuse für den Einsatz in industriellen Anwendungen •...
Page 37
Systemanforderungen • Kompatibel mit allen USB-fähigen Betriebssystemen Lieferumfang • U360-004-IND, U360-007-IND oder U360-010-IND USB 3.2-Hub in Industriequalität • USB 3.2-Kabel • 3-poliger Netzanschlussblock • DIN-Montagematerial • Hardware zur Wandmontage • Betriebsanleitung Stromversorgung des Hubs DC-Eingang Um den Hub mit Strom zu versorgen, schließen Sie den vom Benutzer bereitgestellten Netzadapter an die Steckdose an.
Page 38
Einbau des Montagesatzes Montage der Hardware Die Hubs U360-004-IND, U360-007-IND und U360-010-IND können auf einer ebenen Fläche aufgestellt oder mit den mitgelieferten Wandhalterungen oder DIN-Schienen-Hardware montiert werden. Beziehen Sie sich bei der Installation der Befestigungselemente auf die nachstehende Abbildung. Installation der Hardware für die Wandmontage Um die Wandhalterungen anzubringen, setzen Sie die Laschen der Halterungen in die Schlitze an der Unterseite des Geräts ein und...
Page 39
Einbau des Montagesatzes Installation der Hardware für DIN-Schienen Befestigen Sie die DIN-Schiene mit dem mitgelieferten Befestigungsmaterial an der Seite des Geräts. DIN rail Screw (x2)
Page 40
Einbau des Montagesatzes Hinweis: Die Abmessungen von U360-007-IND und U360-004-IND sind identisch; der einzige Unterschied zwischen den beiden Modellen ist die Anzahl der USB-Anschlüsse. 80.00 50.00 34.00 15.00 15.00 17.00 19.00 17.00 14.20 14.20 14.20 14.20 14.20 14.20 25.00 19.00 16.00 23.00 23.00...
Technische Daten Element Beschreibung Anschlüsse 4 x USB 3.2 (Modell U360-004-IND) 7 x USB 3.2 (Modell U360-007-IND) 10 x USB 3.2 (Modell U360-010- IND) ESD-Schutz +/- 20 kV EFT-Schutz +/- 2.5 kV Übertragungsgeschwindigkeit Bis zu 5 Gbps Strombedarf Bus-Stromversorgung 9-40V Gleichstromversorgung 3-polige Klemme (9-40V DC) Lagertemperatur 14° bis 131°F / -10° bis 55°C Betriebstemperatur 32° bis 104°F / 0° bis 40°C Relative Feuchtigkeit 5 bis 90 % Abmessungen, L x B x H 6,2 x 3,1 x 1,3 Zoll. / 158 x 80 x 32 mm (Modelle U360-004-IND und U360-007-IND)
Page 43
Wir garantieren, dass unsere Produkte frei von Material- und Verarbeitungsfehlern sind, und zwar für einen Zeitraum von drei (3) Jahren ab dem Datum des Erstkaufs. Unsere Verpflichtung im Rahmen dieser Garantie beschränkt sich auf die Reparatur oder den Ersatz (nach eigenem Ermessen) der fehlerhaften Produkte. Besuchen Sie Tripplite.Eaton.com/support/product-returns, bevor Sie Geräte zur Reparatur zurücksenden. Diese Garantie gilt nicht für Geräte, die durch Unfall, Fahrlässigkeit oder falsche Anwendung beschädigt wurden oder in irgendeiner Weise verändert oder modifiziert wurden. MIT AUSNAHME DER HIERIN ENTHALTENEN BESTIMMUNGEN GEBEN WIR KEINE GARANTIEN, WEDER AUSDRÜCKLICH NOCH STILLSCHWEIGEND, EINSCHLIESSLICH GARANTIEN DER MARKTGÄNGIGKEIT...
Page 44
WEEE Compliance-Informationen für Kunden und Verwerter (Europäische Union) Die WEEE-Richtlinie und deren Ausführungsbestimmungen besagen, dass Kunden, die neue Elektro- oder Elektronikgeräte von Eaton kaufen, ein Anrecht auf Folgendes haben: • Einsendung alter Geräte zum Recycling auf einer Eins-zu-Eins-Basis (dies variiert je nach Land) •...
Page 45
Manuale d'uso Hub USB 3.2 di grado Modelli: industriale U360-004-IND U360-007-IND U360-010-IND Istruzioni importanti per la sicurezza Caratteristiche Requisiti di sistema Contenuto della confezione Alimentazione dell'hub Installazione del kit di montaggio Specifiche Garanzia English 1 Español 12 Français 23 Deutsch 34...
Prima di tentare di collegare, utilizzare o regolare questo prodotto, legga prima l'intero Manuale d'uso. Istruzioni di sicurezza importanti • Leggere sempre attentamente le istruzioni di sicurezza • Conservare il presente Manuale d'uso per future consultazioni. • Se si verifica una delle seguenti situazioni, fissare un appuntamento per far ispezionare la sua apparecchiatura da un tecnico dell'assistenza: º...
Page 47
Caratteristiche • Aumenta il numero di porte USB SuperSpeed da una singola porta del computer (4 porte per il modello U360-004-IND / 7 porte per il modello U360-007-IND / 10 porte per il modello U360-010-IND) • USB compatibile con velocità di trasferimento dati fino a 3,2 5 Gbps •...
Requisiti di sistema • Compatibile con tutti i sistemi operativi abilitati all'uso dell'USB Contenuto della confezione • U360-004-IND, U360-007-IND o U360-010-IND: hub USB di livello industriale 3.2 • Cavo USB 3.2 • Morsettiera di alimentazione a 3 pin • Hardware di montaggio DIN •...
Page 49
Installazione del kit di montaggio Installazione dell'hardware di montaggio Gli hub U360-004-IND, U360-007-IND e U360-010-IND possono essere posizionati su una superficie piana, oppure si montano utilizzando le staffe per il montaggio a parete o l'hardware guida DIN incluso. Per l'installazione dell'hardware di montaggio, fare riferimento al diagramma sottostante.
Page 50
Installazione del kit di montaggio Installazione dell'hardware della guida DIN Utilizzando l'hardware incluso, montare la guida DIN sul lato dell'unità. Guida DIN DIN rail Vite Screw (x2)
Page 51
Installazione del kit di montaggio Nota: le dimensioni di U360-007-IND e U360-004-IND sono identiche; l'unica differenza tra i due modelli è il numero di porte USB. 80.00 50.00 34.00 15.00 15.00 17.00 19.00 17.00 14.20 14.20 14.20 14.20 14.20 14.20 25.00 19.00 16.00...
Page 52
Installazione del kit di montaggio 80.00 50.00 34.00 15.00 15.00 17.00 19.00 17.40 14.20 14.20 14.20 14.20 14.20 14.20 14.20 14.20 14.20 25.00 19.00 16.00 23.00 23.00 23.88 16.24 O5.80 8.00 Modello presentato: 7.90 U360-010-IND Dimensioni in mm...
Page 53
Specifiche Articolo Descrizione Porti 4 x USB 3.2 (modello U360-004-IND) 7 x USB 3.2 (modello U360-007-IND) 10 x USB 3.2 (modello U360-010-IND) Protezione ESD +/- 20 kV Protezione EFT +/- 2,5 kV Velocità di trasmissione Fino a 5 Gbps Requisiti di potenza Potenza del bus Alimentazione 9-40V CC Terminale a 3 pin (9-40 V CC)
(a nostra esclusiva discrezione) di qualsiasi prodotto che presenti tali difetti. Prima di inviare un prodotto per la riparazione, visitare Tripplite.Eaton.com/support/product- returns. La presente garanzia non si applica alle apparecchiature che sono state danneggiate da incidenti, negligenza o applicazione errata o che sono state alterate o modificate in qualsiasi modo.
Page 55
Eaton ha una politica di miglioramento continuo. Le specifiche tecniche sono soggette a modifiche senza alcun preavviso.
