- Page 1 12/2018 Mod: CGE11-P Production code: NB-UA-104E DI...
- Page 2 EN CONVECTION OVENS INSTRUCTIONS FOR THE INSTALLATION, USE AND MAINTENANCE GUA-304EB GUA-606EB GUA-404EB GUA-006EB GUA-104EB GUA-110EB GUA-604EB GUA-610EB GUA-004EB GUA-010EB GUA-106EB 2200742 FML423 E104-UAE CPE434-P NB-UA-304E NB-SA-006E 2200744 FML443 E106-UAE CPE644-P NB-UA-404E NB-UA-610E 2200746 FML461 E110-UAE CPE664-BP NB-UA-604E NB-UA-010E FML661...
-
Page 3: Installation
INDEX Dimensions Foreword Declaration of Conformity European Directive ROHS 2012/19/UE Transport of the oven and packaging removal Informative labels INSTALLATION Oven positioning Electrical connection Technical data for electrical connection Hydraulic connection water inlet Plumbing – water drainage Spare parts replacing Checking the functions USE AND MAINTENANCE Description of the control panel... - Page 4 4 x 2/3 GN - 4 x 460x340 Dimensioni Capacità Distanza teglie Peso a vuoto Dimensions Capacity Trays distance Empty weight Abmessungen Kapazität Einschubabstand Leergewicht Dimensions Capacité Ecartement grilles Poids à vide Dimensiones Capacidad Distancia bandejas Peso en vacío Afmetingen Capaciteit Afstand dienbladen Leeggewicht...
- Page 5 4 x 1/1 GN - 4 x 60x40 - 4 x 1/1 GN 60x40 Dimensioni Capacità Distanza teglie Peso a vuoto Dimensions Capacity Trays distance Empty weight Abmessungen Kapazität Einschubabstand Leergewicht Dimensions Capacité Ecartement grilles Poids à vide Dimensiones Capacidad Distancia bandejas Peso en vacío Afmetingen...
- Page 6 6 x 1/1 GN - 6 x 60x40 - 6 x 1/1 GN 60x40 Dimensioni Capacità Distanza teglie Peso a vuoto Dimensions Capacity Trays distance Empty weight Abmessungen Kapazität Einschubabstand Leergewicht Dimensions Capacité Ecartement grilles Poids à vide Dimensiones Capacidad Distancia bandejas Peso en vacío Afmetingen...
- Page 7 10 x 1/1 GN - 10 x 60x40 - 10 x 1/1 GN 60x40 Dimensioni Capacità Distanza teglie Peso a vuoto Dimensions Capacity Trays distance Empty weight Abmessungen Kapazität Einschubabstand Leergewicht Dimensions Capacité Ecartement grilles Poids à vide Dimensiones Capacidad Distancia bandejas Peso en vacío Afmetingen...
-
Page 8: Declaration Of Conformity
FOREWORD The contents of this manual are generic and not all the functions described may be available on your product. The manufacturer declines all responsibility for possible inaccuracies contained in this pamphlet, due to printing or copy errors. We reserve the right to make on our own products those changes to be considered necessary or useful, without jeopardizing the essential characteristics. -
Page 9: Informative Labels
1.4 INFORMATIVE LABELS On each oven there are applied some metal labels, that give important info concerning characteristics of the oven, electric and plumbing connections and eventually the drain connection. On the right hand side panel there is the label A. The info contained on this label are: •... -
Page 10: Technical Data For Electrical Connection
1.7 TECHNICAL DATA FOR ELECTRICAL CONNECTION Power loading no. and motor Heating Absorbed Feed cable Model and voltage power power current section 4 x 2/3 GN 3.3 kW 220-240 V 1N ~ 1 x 240 W 3.0 kW 14.0 A cable included 50/60 Hz 4 x 460x340... -
Page 11: Replacing Spare Parts
2.6 PLUMBING – WATER DRAINAGE (mod. Combi with direct steam) Drainage for the water is at the back of the oven and must be connected directly to the end of the stainless steel drainpipe. The drain must have no trap and be made in rigid pi- pes that can withstand a temperature of 110°C. - Page 12 USE AND MAINTENANCE INSTRUCTIONS FOR A SAFE USE OF THE OVEN • Ensure the oven is on a stable position and safety devices installed upstream are efficient. • Always use adequate protection gloves to introduce or pull out the trays. •...
-
Page 13: Maintenance
9.0 MAINTENANCE All external stainless steel parts should be: 1 - cleaned with clear, soapy water; 2 - rinsed with water; 3- dried thoroughly. It is absolutely forbidden to use scrapers, metal soap pads and other common steel tools as they could besides scratching the surface, deposit iron particles that, oxidizing would cause rust to form.
