VocoPro GIG-MAN Owner's Manual

All-in-one digital karaoke / jam-along system

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Featur es:

All-in-One Design with 4-Speaker Cabinet Provides 100W Total Power (Peak to Peak)

Multi-Format Player with Direct Track Access Supports VCD, CDG, MP3, Photo-CD, CD,

CD-R, and CD-RW Formats

1/4" Guitar and Keyboard Inputs with Individual Volume Controls

Two 1/4"/XLR Microphone Inputs with Bass, Treble and Individual Volume Controls

Digital Echo, Repeat and Delay Controls for Vocal Enhancement

14-step Digital Key Controller to Transpose the Key of Built-in Disc Player Audio

Vocal Cancel and Partner Modes for Canceling Vocals from Multiplexed Media

7-Band Equalizer for Precise Audio Adjustments and Room Tuning

External Speaker Jacks with Internal/External Speaker Selector

Remote Control for Easy Operation

Inputs/Outputs: 3 A/V (RCA) and 2 A/V (RCA) / 1 Balanced Audio (L/R XLR)

110/230V and NTSC-PAL Compatible for Worldwide Use

A l l - i n - O n e D i g i t a l K a r a o k e / J a m - A l o n g S y s t e m

GIGMAN

STANDBY

MUSIC EQ

200Hz 400Hz 1KHz 3KHz

6KHz 16KHz

60Hz

POWER

+12dB

0dB

DISC

INPUT

AV1

-12dB

60Hz 200Hz 400Hz 1KHz 3KHz

6KHz 16KHz

AV2

AV3

MUSIC VOLUME

PLAY

PAUSE

CDG

EQ ON

STOP

PBC

B-SCAN

F-SCAN

MUTE

EQ OFF

AV3 INPUT

HEADPHONES VOL.

VOL.

KEYBOARD

GIG MAN

COMPACT

MULTI-FORMAT PLAYER/MIXING AMPLIFIER

PRO DIGITAL ECHO

DIGITAL AUDIO

BASS

TREBLE

ECHO

REPEAT

DELAY

MIC EFFECTS

EJECT

MIC VOLUME

VOCAL

CANCEL

L/R

REPEAT

VOCAL

PARTNER

PLAYER KEY CONTROLLER

MIC1

MIC2

VOL1

VOL2

GUITAR

VOL.

Table of Contents

Need help?

Do you have a question about the GIG-MAN and is the answer not in the manual?

Questions and answers

Summary of Contents for VocoPro GIG-MAN

Page 1 Featur es: All-in-One Design with 4-Speaker Cabinet Provides 100W Total Power (Peak to Peak) Multi-Format Player with Direct Track Access Supports VCD, CDG, MP3, Photo-CD, CD, CD-R, and CD-RW Formats 1/4" Guitar and Keyboard Inputs with Individual Volume Controls Two 1/4"/XLR Microphone Inputs with Bass, Treble and Individual Volume Controls Digital Echo, Repeat and Delay Controls for Vocal Enhancement 14-step Digital Key Controller to Transpose the Key of Built-in Disc Player Audio Vocal Cancel and Partner Modes for Canceling Vocals from Multiplexed Media...
Page 2: Safety Instructions
Safety Instructions CAUTION RISK OF SHOCK CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No user- serviceable parts inside. Only refer servicing to qualified service personnel. Explanation of Graphical Symbols The lightning flash & arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of danger.
Page 3 UNIT!: This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Vocopro may void your authority, granted by the FCC, to use this product. 2. IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables.
Page 4: Welcome
Club VocoPro for Karaoke news and events, chat rooms, club directories and even a KJ Service directory! We look forward to hearing you sound like a PRO, with VocoPro, your ultimate choice in Karaoke entertainment. Please record the model number and serial number below, for easy reference, in case of loss or theft. These numbers are located on the rear panel of the unit.
Page 5: Table Of Contents
GIG MAN A l l - i n - O n e D i g i t a l K a r a o k e / J a m - A l o n g S y s t e m Contents Introduction Safety Instructions...
Page 6: Listening For A Lifetime
Selecting fine audio equipment such as the unit you've just purchased is only the start of your musical enjoyment. Now it's time to consider how you can maximize the fun and excitement your equipment offers. VocoPro and the Electronic Industries Association's Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
Page 7: Front Panel
Front Panel Description and Functions Front Panel STANDBY POWER INPUT MUSICC VOLUME 1. POWER button - This button is used to turn the GIG MAN 'ON' or place it in STANDBY mode. NOTE: When in STANDBY mode, the GIG MAN is not completely powered down and still contains residual power. 2.
Page 8 Front Panel Description and Functions cont... Front Panel STANDBY POWER INPUT 15. PREV / NEXT buttons - These buttons are used to either go back to a PREVIOUS track or advance the NEXT track on a disc during playback. 16. B-SCAN / F-SCAN buttons - These buttons are used to SCAN either BACKWARD or FORWARD through tracks on a disc during playback.
Page 9: Rear Panel
36. MIC 1 / 2 VOLUME controls - These controls adjust the VOLUME levels of MIC channels 1 and 2 individually. Turn controls clockwise to INCREASE and counter-clockwise to DECREASE. Rear Panel Description and Functions Rear Panel VCD+CDG VOCOPRO www.vocopro.com Rated:AC~115/230V ,50/60HZ, 70W Class1 Laser Product This product complies with DHHS Rules21CFR Chapter1,...
Page 10 Rear Panel Description and Functions cont... Rear Panel VCD+CDG COMBO Model: GIGMAN VOCOPRO www.vocopro.com Rated:AC~115/230V ,50/60HZ, 70W Class1 Laser Product This product complies with DHHS Rules21CFR Chapter1, Subchapter J Made in China Manufactured Date: This device complies with part 15 of the FCC Rules.
Page 11: Remote Control
Remote Control Description and Functions Remote Control POWER button - This button is used to turn the GIG MAN 'ON' or place it in STANDBY mode. NOTE: When in STANDBY mode, the GIG MAN is not completely powered down and still contains residual power. SELECT button - This button is used to make selections in OSD and media menus when an entry is highlighted.
Page 12: Using The Remote Control
Remote Control Description and Functions cont... Remote Control 20. RETURN button - Press this button to return to the point on the disc selected with the BOOKMARK feature. Press it again to RETURN to normal playback 21. OSD button - Press this button to display the DISC PLAYBACK STATUS on the video display.
Page 13: Getting Connected
Getting Connected AV Input Connections To connect an AV source player, use an RCA-type AV cable with red, white and yellow colored plugs. For AUDIO, connect the L and R AUDIO OUTPUT jacks from the source player to the L (white) and R (red) AUDIO INPUT jacks on the GIG MAN, using the AV channel of your choice.
Page 14: Microphone/Instrument Inputs
Getting Connected cont... Microphone/Instrument Input Connection After making your main system connections, it is time to get your microphones and instruments connected and ready for performing. Before you get started with your connections we recommend to take the following tips into consideration: When connecting instruments, refrain from using defective cables as they can cause significant noise and loud pops, posing a threat to system speakers.
Page 15: Speaker Connection
Speaker Connection The GIG MAN has a set of speaker connectors for connection to external speakers. Remember that only speakers with an impedance rating of 8 ohms should be connected. To connect speakers, first unlock the plastic fasteners on each speaker connector by pushing downward on them. Then strip approximately a 1 /2 " of insulation from the speaker wire ends and twist the strands so that they can easily slide through the holes.
Page 16: Mp3 Functions And Operations
Basic and Advanced Operations cont... Displaying the Remaining Time While the disc is playing, pressing the OSD button on the remote control will display the disc's playback status. Press the OSD button to cycle between TRACK TIME REMAINING and DISC TIME REMAINING. Programming a Playback Sequence Press the PROGRAM button to enter PROGRAM mode.
Page 17: Mp3 Glossary
MP3 Functions and Operations cont... Notes on display indications during playback Up to 8 characters are displayed for the name of an album or track. Characters other than uppercase letters ("A" to "Z"), numerals ("0" to "9") and underscore ("_") may not be displayed, or may be displayed in different characters.
Page 18: Karaoke Functions And Operations
Karaoke Functions and Operations Notes on Karaoke Media There are various types of Karaoke media available for playback with the GIG MAN. You can perform Karaoke with MP3, CDG and VCD formats. The thing to remember is how each type differs as far as audio channels and video support. CDG has been the most commonly used format of Karaoke media for the last 7 years.
Page 19: Viewing Vcd's
Viewing VCD's Tips on VCD Discs There are two types of VCD's: VCD 1/1.1 Format This format of VCD has no menu, track search and other video features available, as this format does not support PBC. The same as with audio CD's, these discs will auto-play with full motion-picture audio and video, but with no support for menus and custom track selection.
Page 20: Troubleshooting
Troubleshooting Troubleshooting No audio output. Unable to connect the GIG MAN to my television monitor with the RCA cable provided. There is a loud "squealing" noise coming from the speakers. An MP3 or Photo-CD does not play in the GIG MAN. The input selector is not set to the channel that the active source player is connected The speaker selector is not set correctly.
Page 21 Vocopro 2004 V 1.0 WWW.VOCOPRO.COM...
