LG 32BR55U Owner's Manual

LG 32BR55U Owner's Manual

Led lcd monitor
Hide thumbs Also See for 32BR55U:

Advertisement

Quick Links

OWNER'S MANUAL
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
32BR55U
32UR550
32UR500
www.lg.com
Copyright © 2020 LG Electronics Inc. All Rights Reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 32BR55U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG 32BR55U

Summary of Contents for LG 32BR55U

  • Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32BR55U 32UR550 32UR500 www.lg.com Copyright © 2020 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 OPEN SOURCE SOFTWARE NOTICE The terms HDMI, HDMI High-Definition Multimedia Interface, and INFORMATION ..........3 the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

  • Page 3: Open Source Software Notice

    The power cord provided may differ depending upon the region. other relevant documents, please visit https://opensource.lge.com. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing Supported Drivers and Software such distribution (such as the cost of media, shipping, and handling) upon email request to ...
  • Page 4 How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ down with your finger. 32BR55U/32UR550 32BR55U/32UR550 Basic Functions Press the joystick button once with your finger Power on to turn on the monitor.
  • Page 5 32BR55U/32UR550 32BR55U/32UR550 Installing on a Table Adjusting the Stand Height • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away from Place the monitor mounted on the stand base in an upright position.
  • Page 6 Adjusting the Angle Using the Kensington Lock 32BR55U/32UR550 The connector for the Kensington security system is located at the back of the monitor. Place the monitor mounted on the stand base in an upright position. For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website Adjust the angle of the screen.
  • Page 7 Install the monitor at least 100 mm away from the wall and leave about 100 mm of space at each side of the • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable monitor to ensure sufficient ventilation. Detailed installation instructions can be obtained from your local retail for any accidents relating to the use of non-standard screws.
  • Page 8 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this way will not be covered by the product warranty.

  • Page 9: Using The Monitor

    CAUTION HDMI Connection • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Transmits digital video and audio signals from your PC to the monitor. • Do not press the screen for a prolonged time. This may cause image distortion.
  • Page 10 Connecting AV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection NOTE HDMI transmits digital video and audio signals from your AV device to the monitor. • There may be no video or audio output depending on the DP (DisplayPort) version of the PC. •...
  • Page 11 Connecting Peripherals CAUTION • Cautions when using a USB device. USB Device connection - A USB device with an automatic recognition program installed, or that uses its own driver, may not be recognized. The USB port on the product functions as a USB hub. - Some USB devices may not be supported or may not work properly.
  • Page 12 Headphones Connection Connect peripherals to the monitor via the headphones port. NOTE • Peripheral devices are sold separately. • Depending on the audio settings of the PC and external device, headphones and speaker functions may be limited. • If you use angled earphones, it may cause a problem with connecting another external device to the monitor. Therefore, it is recommended to use straight earphones.

  • Page 13: User Settings

    USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Activating the Main Menu • Main menu disabled: Enables the main menu. • Main menu enabled: Exits the main menu. (Holding down the button more than 3 seconds to turn off the monitor.
  • Page 14 Main Menu Features Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the [Settings]. Move the joystick up/down and left/right to set the options. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it.
  • Page 15 [Quick Settings] [Input] [Settings] [Quick Settings] [Settings] [Input] • [Brightness]: Adjusts the brightness of the screen. • [Input List]: Selects the input mode. • • [Contrast]: Adjusts the contrast of the screen. [Aspect Ratio]: Adjusts the aspect ratio of the screen. The display may look the same for [Full Wide] and [Original] options at the recommended resolution (3840 x 2160).
  • Page 16 [Picture] [Picture Mode] on HDR signal • [Custom]: Allows the user to adjust each element. [Settings] [Picture] [Picture Mode] • [Vivid]: Optimized the screen for HDR vivid colors. • [Cinema]: Optimized the screen for HDR video. [Picture Mode] on SDR (Non HDR) signal •...
  • Page 17 [Settings] [Picture] [Picture Adjust] [Settings] [Picture] [Game Adjust] • • [Brightness]: Adjusts the brightness of the screen. [Response Time]: Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use [Fast]. When there is a lot of motion, it is •...
  • Page 18 [Settings] [Picture] [Color Adjust] [Settings] [Picture] [Picture Reset] • • [Gamma]: [Do you want to reset your picture settings?] - [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes. Likewise, the - [Yes]: Returns to the default settings. lower the gamma value, the lighter the image becomes.
  • Page 19 [General] • [DisplayPort Version]: Set DisplayPort Version to the same version as the connected external device. ([1.4] and [1.2]) To use the HDR function, set to [1.4]. [Settings] [General] • [HDMI ULTRA HD Deep Color]:Provides sharper images when connected to a device supporting ULTRA HD Deep •...

  • Page 20: Troubleshooting

    TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? - Check if the power cord is correctly plugged into the power outlet. • Is the power LED on? - Check the power cable connection and press the power button. •...
  • Page 21 • Have you installed the display driver? - Be sure to install the display driver from our web site: http://www.lg.com. - Make sure to check if the graphics card supports Plug and Play function. No sound from the headphone port.

  • Page 22: Product Specification

    5U/32UR550 PRODUCT SPECIFICATION 00/32UN500P 32UR500 32UR550 32UN50A/32UN50AP 32BP57U Color Depth 8-bit / 10-bit color is supported. Max Resolution 3840 x 2160 @ 60 Hz 50/32UN550P 32UN55B Resolution Recommended Resolution 3840 x 2160 @ 60 Hz Power Rating 19 V 2.4 A On mode: 45 W Typ.
  • Page 23 32UR500 32UR550 Monitor Size (Width x Height x Depth) Dimensions With Stand 714.3 x 512.0 x 223.3 (mm) 714.3 x 597.1 x 239.3 (mm) Without Stand 714.3 x 420.1 x 45.7 (mm) 714.3 x 420.1 x 45.7 (mm) With Stand 6.2 kg 7.0 kg Weight (Without Packaging)
  • Page 24 32BR55U/32UR550 PRODUCT SPECIFICATION 32UN500/32UN500P 32UR500 32UR550 32UN50A/32UN50AP 32BR55U 32BP57U 32UN550/32UN550P 32UN55B Color Depth 8-bit / 10-bit color is supported. Max Resolution 3840 x 2160 @ 60 Hz Resolution Recommended Resolution 3840 x 2160 @ 60 Hz Power Rating 19 V 7.0 A...
  • Page 25 Factory Support Mode (Preset Mode, PC) Display Port / USB-C (for 32BR55U) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5...
  • Page 26 HDMI Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 2560 x 1440 88.79 59.95 3840 x 2160 65.69 29.98 HDMI Preferred timing, HDMI ULTRA HD Deep Color : Off 3840 x 2160 133.31...
  • Page 27 (for 32BR55U) The model and serial number of the product are located on the back and on one side of the product. This Product qualifies for ENERGY STAR® Record them below in case you ever need service. Changing the factory default configuration and settings or enabling certain optional features and functionalities may increase energy consumption beyond the limits required for ENERGY STAR®...
