OWNER'S MANUAL
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
32BR55U/32BR55UK
32UR550/32UR550K
32UR500/32UR500K
www.lg.com
32UR50B/32UR50BK
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
Advertisement
Table of Contents
Related Manuals for LG 32UR550K
Summary of Contents for LG 32UR550K
- Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32BR55U/32BR55UK 32UR550/32UR550K 32UR500/32UR500K www.lg.com 32UR50B/32UR50BK Copyright © 2020 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 OPEN SOURCE SOFTWARE NOTICE The terms HDMI, HDMI High-Definition Multimedia Interface, INFORMATION ..........3 HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 3: Open Source Software Notice
The power cord provided may differ depending upon the region. other relevant documents, please visit https://opensource.lge.com. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing Supported Drivers and Software such distribution (such as the cost of media, shipping, and handling) upon email request to ... -
Page 4: Product And Button Description
You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ down with your finger. 32BR55U/32BR55UK 32BR55U/32BR55UK Basic Functions 32UR550/32UR550K 32UR550/32UR550K Press the joystick button once with your finger Power on to turn on the monitor. -
Page 5: Adjusting The Stand Height
Place the monitor mounted on the stand base in an upright position. the wall to ensure sufficient ventilation. Handle the monitor with both hands for safety. 32BR55U/32BR55UK 32UR500/32UR500K 32UR50B/32UR50BK 32UR550/32UR550K Max. 110.0 mm 32BR55U/32BR55UK 32UR550/32UR550K 100 mm 100 mm 100 mm... -
Page 6: Adjusting The Angle
The angle of the screen can be adjusted forward or backward from -5° to 15° for a comfortable viewing experience. 32UR500/32UR500K 32BR55U/32BR55UK/32UR550/32UR550K 32UR50B/32UR50BK The angle of the screen can be adjusted forward or backward from -5° to 20° for a comfortable viewing experience. -
Page 7: Installing The Wall Mount Plate
Install the monitor at least 100 mm away from the wall and leave about 100 mm of space at each side of the • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable monitor to ensure sufficient ventilation. Detailed installation instructions can be obtained from your local retail for any accidents relating to the use of non-standard screws. - Page 8 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this way will not be covered by the product warranty.
-
Page 9: Using The Monitor
CAUTION HDMI Connection • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Transmits digital video and audio signals from your PC to the monitor. • Do not press the screen for a prolonged time. This may cause image distortion. -
Page 10: Displayport Connection
Connecting AV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection NOTE HDMI transmits digital video and audio signals from your AV device to the monitor. • There may be no video or audio output depending on the DP (DisplayPort) version of the PC. •... -
Page 11: Connecting Peripherals
Connecting Peripherals CAUTION • Cautions when using a USB device. USB Device connection - A USB device with an automatic recognition program installed, or that uses its own driver, may not be only for 32BR55U/32BR55UK recognized. The USB port on the product functions as a USB hub. - Some USB devices may not be supported or may not work properly. -
Page 12: Headphones Connection
Headphones Connection Connect peripherals to the monitor via the headphones port. NOTE • Peripheral devices are sold separately. • Depending on the audio settings of the PC and external device, headphones and speaker functions may be limited. • If you use angled earphones, it may cause a problem with connecting another external device to the monitor. Therefore, it is recommended to use straight earphones. -
Page 13: User Settings
USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Activating the Main Menu • Main menu disabled: Enables the main menu. • Main menu enabled: Exits the main menu. (Holding down the button more than 3 seconds to turn off the monitor. -
Page 14: Main Menu Features
Main Menu Features Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the [Settings]. Move the joystick up/down and left/right to set the options. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it. - Page 15 [Quick Settings] [Settings] [Quick Settings] (only for 32UR500K) • [Brightness]: Adjusts the brightness of the screen. [Settings] [Quick Settings] • [Contrast]: Adjusts the contrast of the screen. • [Brightness]: Adjusts the brightness of the screen. • [Volume]: Adjusts the volume level. •...
- Page 16 [Input] [Picture] [Settings] [Input] [Settings] [Picture] [Picture Mode] • [Input List]: Selects the input mode. • [Picture Mode] on SDR (Non HDR) signal [Aspect Ratio]: Adjusts the aspect ratio of the screen. The display may look the same for [Full Wide] and [Original] options at the recommended resolution (3840 x 2160).
- Page 17 [Settings] [Picture] [Picture Adjust] [Picture Mode] on HDR signal • [Brightness]: Adjusts the brightness of the screen. • [Custom]: Allows the user to adjust each element. • [Contrast]: Adjusts the contrast of the screen. • [Vivid]: Optimized the screen for HDR vivid colors. •...
- Page 18 [Settings] [Picture] [Game Adjust] [Settings] [Picture] [Color Adjust] • • [Response Time]: Sets a response time for displayed pictures based on the movement of the picture on the [Gamma]: screen. For a normal environment, it is recommended that you use [Fast]. When there is a lot of motion, it is - [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes.
- Page 19 [General] [Settings] [Picture] [Picture Reset] • [Do you want to reset your picture settings?] [Settings] [General] - [Yes]: Returns to the default settings. • [Language]: Sets the menu screen to the desired language. - [No]: Cancel the select. • [SMART ENERGY SAVING]: Conserve energy by using luminance compensation algorithm. •...
- Page 20 • [DisplayPort Version]: Set DisplayPort Version to the same version as the connected external device. ([1.4] and • [Information]: The following display information will be shown; [Total Power On Time], [Resolution]. [1.2]) To use the HDR function, set to [1.4]. •...
-
Page 21: Troubleshooting
TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? - Check if the power cord is correctly plugged into the power outlet. • Is the power LED on? - Check the power cable connection and press the power button. •... - Page 22 • Have you installed the display driver? - Be sure to install the display driver from our web site: http://www.lg.com. - Make sure to check if the graphics card supports Plug and Play function. No sound from the headphone port.
-
Page 23: Product Specification
32UR500 32BR55U/32UR550 PRODUCT SPECIFICATION 32UR500/32UR500K 32UR550/32UR550K 32UR50B/32UR50BK 32BR55U/32BR55UK Color Depth 8-bit / 10-bit color is supported. Max Resolution 3840 x 2160 @ 60 Hz 32UN550/32UN550P 32UN55B Resolution Recommended Resolution 3840 x 2160 @ 60 Hz Power Sources Power Rating 19 V 2.4 A... - Page 24 32BR55U/32UR550 PRODUCT SPECIFICATION 32UR500/32UR500K 32UR550/32UR550K 32UR50B/32UR50BK 32BR55U/32BR55UK 32UN550/32UN550P 32UN55B Color Depth 8-bit / 10-bit color is supported. Max Resolution 3840 x 2160 @ 60 Hz Resolution Recommended Resolution 3840 x 2160 @ 60 Hz Power Sources Power Rating 19 V 7.0 A...
-
Page 25: Factory Support Mode (Preset Mode, Pc)
Factory Support Mode (Preset Mode, PC) DisplayPort/USB-C Type 1 Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 2560 x 1440 88.79 59.95 3840 x 2160... - Page 26 Type 2 Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.897 60.317 1024 x 768 48.363 1920 x 1080 67.5 1920 x 1080 67.5 2560 x 1440 88.787 59.951 3840 x 2160 65.688 29.981 Recommended Timing : DP1.2...
- Page 27 HDMI Type 1 Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 2560 x 1440 88.79 59.95 HDMI Preferred timing, HDMI ULTRA HD Deep Color : Off 3840 x 2160 65.69 29.98...
-
Page 28: Hdmi Timing (Video)
HDMI Timing (Video) Type 1 Factory support mode Horizontal Frequency(kHz) Vertical Frequency(Hz) Remarks (Preset Mode) 480p 31.5 720p 45.0 1080p 67.5 2160p When HDMI ULTRA HD Deep Color is set to ON Type 2 Factory support mode Horizontal Frequency(kHz) Vertical Frequency(Hz) Remarks (Preset Mode) 480p... - Page 29 (for 32BR55U/32BR55UK) The model and serial number of the product are located on the back and on one side of the product. This Product qualifies for ENERGY STAR® Record them below in case you ever need service. Changing the factory default configuration and settings or enabling certain optional features and functionalities may increase energy consumption beyond the limits required for ENERGY STAR®...
