- Page 1 OneRemote Radio PL7 For use with Bang & Olufsen Speakers DAB/DAB+ – FM - Bluetooth - Internet Radio Spotify Connect- Music Player Setup Guide Control with Bang & Olufsen Remotes 3001.2030.UK.S1...
-
Page 2: Preface
PREFACE This OneRemote PL7 receiver has been equipped with advanced OneRemote circuitry enabling it to be controlled with a Bang & Olufsen remote control terminal. This modified receiver is named OneRemote Radio PL7. OneRemote Radio PL7 connects directly to: • any Bang & Olufsen powered speaker. -
Page 3: Table Of Contents
PREFACE ................................. 2 QUICK GUIDE, INSTALLATION NOTES ....................4 Connecting hardware ................................. 4 Setting up the Oneremote radio PL7 ..........................4 MUSIC-SOURCE SELECTION ........................6 Control With Bang & Olufsen Remote Controls ......................... 6 Control With the UNDOK App for Apple iOS – iPhone, iPad and MAC ................6 Control With the UNDOK App for Android Devices ...................... -
Page 4: Quick Guide, Installation Notes
• IR-receiver. SETTING UP THE ONEREMOTE RADIO PL7 Refer to the OneRemote PL7 User Guide about which buttons to use on a Bang & Olufsen remote control. When PL7 is connected to power it will boot and the blue LED will flash for 8 seconds. This indicates that an option may be entered. - Page 5 5. Now that the WiFi is connected, the final steps are to search channels and setup the presets of the needed Radio channels. As the Radio PL7 is now connected to the WiFi network, any Smartphone or other device on the WiFi network, that has the UNDOK App installed, now can see and control the PL7.
-
Page 6: Music-Source Selection
The OneRemote Radio PL7 may be fully controlled via WiFi with the free UNDOK app for Apple devices like iPhone, iPad and MAC computers. UNDOK is available from the App Store. With more OneRemote Radio PL7 units in the home they may all be controlled with this app, even in groups. -
Page 7: Control With The Spotify App
Start the UNDOK app and select the OneRemote Radio PL7 to be controlled. If its name has not been changed during the initial installation, it is named ‘Digitradio 10 IR’. With more than one OneRemote Radio PL7 in the home their names have been changed to more descriptive ones like ‘living room, bedroom’... -
Page 8: Connections
CONNECTIONS SPEAKERS The OneRemote Radio PL7 connects to Bang & Olufsen BeoLab speakers with an 8-pin cable. So called PowerLink cables with DIN connectors. These connectors carry both right and left signals. The speaker connection is like in any other Bang & Olufsen setup either: 1. -
Page 9: Antenna Dab & Fm
The sound disappears now and then. o One becomes sad. If these problems occur, try moving the Radio PL7 closer to the Wireless Router/ AP or have the WiFi installation adjusted. The WiFi signal strength is shown at the left bottom of the main screen. -
Page 10: Options
& Olufsen remote only. When power is applied to OneRemote Radio PL7 and it is Booting, the LED in the upper left corner of the display, will flash for 8 seconds. Within these 8 seconds an Option code-sequence may be initiated. -
Page 11: Source Idendity Options
L112w VAUX *1 *2 *1 If the LED is flashing, enter the code. or x Soft Boot PL7, make the LED flash press *2 If the Bang & Olufsen remote control used does not have a button, instead use www.oneremote.dk...
