Installation Instructions
Original Instructions
ASEM 6300B Box PCs and 6300T Thin Clients
Catalog Numbers 6300B-xxA, 6300B-BMB, 6300B-xxF, 6300B-xxN, 6300T-BA, 6300T-BB
The following catalog numbers are ASEM™ 6300B Edge Box PCs intended for use with FactoryTalk® Edge™ Manager:
• 6300B-BMBDNE-3DBAE01FNNBNN-NN1S
• 6300B-BMBDNE-7EDAE01FNNDNN-NN1S
These catalog numbers have a unique Edge Virtualization Engine operating system (EVE-OS) orchestrated from FactoryTalk Edge Manager. If you have sent
the product to be returned or repaired, the device software and data has been erased and the EVE-OS has been reinstalled. For more information on
FactoryTalk Edge Manager, see publication
Summary of Changes
This publication contains the following new or updated information. This list includes substantive updates only and is not intended to reflect all changes.
Topic
Update to European Union and UK Directive Compliance and addition of Hazardous Locations
content in Installation Precautions section
Installation Precautions
Environment and Enclosure Information
ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in 
IEC 60664-1), at altitudes up to 2000 m (6561 ft) without derating.
This equipment is considered Group 1, Class A industrial equipment according to IEC/EN 61326-1. Without appropriate precautions, there can be potential
difficulties with electromagnetic compatibility in other environments due to conducted as well as radiated disturbance.
This equipment is considered open equipment, which means it must be mounted in an enclosure where the equipment can be operated from the front
panel.
The enclosure in which this equipment is installed must be accessed only with a key or tool, and only by trained and authorized personnel.
In addition to this publication, see the following:
• Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1, for more installation requirements.
• UL 50, CSA C22.2 No. 94.1, and IEC 60529, as applicable, for explanations of the degrees of protection provided by enclosures.
European Union and UK Directive Compliance
This equipment meets the European Union and UK Directive requirements when installed within the European Union, UK, or EEA regions and have the CE or UK marking.
A copy of the declaration of the conformity is available at rok.auto/certifications.
ATTENTION: This equipment is intended to operate in an industrial or control room environment, which uses some form of power isolation from the
public low-voltage mains. Some computer configurations cannot comply with the EN 61000-3-2 Harmonic Emissions standard as specified by the
EMC Directive of the European Union or UK.
All I/O cables must be used only indoors.
Hazardous Locations
Only the ASEM 6300B-xxN and 6300T-BB Thin Client devices for hazardous locations are suitable for these location categories. All other products covered by this guide are
suitable for use in normal operating conditions.
Location Categories for Hazardous Locations
Region
Class I Division 2, Groups A, B, C, D T4
United States
Class I Zone 2, IIC, T4
Class I Division 2, Groups A, B, C, D T4
Canada
Class I Zone 2, IIC, T4
Europe (ATEX)
United Kingdom (UK)
• 6300B-BMBDNE-3DBAE01NNNBNN-NN1S
• 6300B-BMBDNE-7EDAE01NNNDNN-NN1S
95055-UM007-EN-P
Rating
II 3 G, Ex ec IIC T4 Gc
=
=
= II 3 G, Ex ec IIC T4 Gc
and publication 95055-QS003-EN-P.
Page
1
Temperature Range
Storage:
-20 °C ≤ T ≤ +60 °C
a
(-4 °F ≤ T ≤ +140 °F)
a
Operating:
0...+50 °C
(+32...+122 °F)
