W) PIONEER'
The Art of Entertainment
Service
_ ORDER.NO.
CRT1701
CONTENTS
4. SPECIFICATIONS......--essececseeees eee
eT Rn, 2
2. OPERATIONS AND CONNECTION ......cesccesecesceeeares ce
3. DISASSEMBLY .......cecescccssccocececsecesssesessseessceaterecencers 10
4, ELECTRICAL PARTS LIST ..csccscssccsesscssssesseceeeseseeseee 15
5. CIRCUIT DIAGRAM AND PATTERN .......00.esseeeeeeee 17
6. BLOCK DIAGRAM ......eescccccsscesssceccsssecesercentenesscescees 25
7. EXPLODED VIEW ........ Pddleatiraeteiera
tends iedesuuatnees 26
PIONEER ELECTRONIC CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153, Japan
PIONEER ELECTRONICS SERVICE, INC.
P.O.Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V.
Haven 1087 Keetberglaan 1, 9120 Melsele, Betgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD.
501 Orchard Road, #10-00 Lane Crawford Place, Singapore 0923.
