Connecting the Units
Note:
This unit is for vehicles with a 12-volt battery
When an external power amp is being used with
and negative grounding. Before installing it in a
this system, be sure not to connect the blue/white
recreational vehicle, truck, or bus, check the bat-
lead to the amp's power terminal. Likewise, do
tery voltage.
not connect the blue/white lead to the power ter-
minal of the auto-antenna. Such connection could
To avoid shorts in the electrical system, be sure
to disconnect the · battery cable before begin-
cause excessive current drain and malfunction.
ning installation.
To avoid short-circuiting, cover the disconnected
lead with insulating tape. Especially, insulate the
Refer to the owner's manual for details on con-
unused speaker leads without fail. There is a pos-
necting the power amp and other units, then
sibility of short-circuiting if the leads are not
make connections correctly.
insulated.
Secure the wiring with cable clamps or adhesive
To prevent incorrect connection, the input side of
tape. To protect the wiring, wrap adhesive tape
the IP-BUS or optical cable connector is blue,
around them where they lie against metal parts.
and the output side is black. Connect the connec-
Route and secure all wiring so it cannot touch
tors of the same colors correctly.
any moving parts, such as the gear shift, hand-
If this unit is installed in a vehicle that does not
brake and seat rails. Do not route wiring in
have an ACC (accessory) position on the ignition
places that get hot, such as near the heater outlet.
switch, the red lead of the unit should be con-
If the insulation of the wiring melts or gets torn,
there is a danger of the wiring short-circuiting to
nected to a terminal coupled with ignition switch
the vehicle body.
ON/OFF operations. If this is not done, the vehi-
cle battery may be drained when you are away
Don't pass the yellow lead through a hole into
from the vehicle for several hours.
the engine compartment to connect to the battery.
This will damage the lead insulation and cause a
very dangerous short.
Do not shorten any leads. If you do, the protec-
tion circuit may fail to work when it should.
Never feed power to other equipment by cutting
the insulation of the power supply lead of the
unit and tapping into the lead. The current capac-
ACC position
No ACC position
ity of the lead will be exceeded, causing over-
heating.
When replacing fuse, be sure to use only fuse of
The black lead is ground. Please ground this lead
the rating prescribed on the fuse holder.
separately from the ground of high-current prod-
Since a unique BPTL circuit is employed, never
ucts such as power amps.
wire so the speaker leads are directly grounded or
If you ground the products together and the
the left and right · speaker leads are common.
ground becomes detached, there is a risk of dam-
Speakers connected to this unit must be high-
age to the products or fire.
power types with minimum rating of 50 W and
To ensure proper heat dissipation of this product,
impedance of 4 to 8 ohms. Connecting speakers
take special care not to block the cooling fan side
with output and/or impedance values other than
of this product.
those noted here may result in the speakers catch-
ing fire, emitting smoke or becoming damaged.
Cords for this product and those for other prod-
When this product's source is switched ON, a
ucts may be different colors even if they have
control signal is output through the blue/white
the same function. When connecting this prod-
lead. Connect to an external power amp's system
uct to another product, refer to the supplied
remote control or the car's Auto-antenna relay
Installation manuals of both products and con-
control terminal (max. 300 mA 12 V DC). If the
nect cords that have the same function.
car features a glass antenna, connect to the anten-
na booster power supply terminal.
Connecting the power cord
This product
When you connect a power amp (sold
separately), be sure to use the blue/white
lead of this unit. If you use the blue/white
lead of the head unit, it causes noises.
Blue/white
To system control terminal of the power
amp or Auto-antenna relay control terminal
(max. 300 mA 12 V DC).
Yellow
Fuse holder
To terminal always supplied with
power regardless of ignition switch
position.
Black (ground)
To vehicle (metal) body.
Black/white
+
Center speaker
Black
Left
Right
White
Gray
+
+
Front speaker
Front speaker
White/black
Gray/black
Green
Violet
+
+
Rear speaker
Rear speaker
Green/black
Violet/black
Do not connect anything to the speaker
leads that are not connected to speakers.
<ENGLISH>
Connecting to a sold separately power amp
This product can be connected to a sold separately power amp using the RCA output jacks.
System remote control
Blue/white
To system control terminal of the power
amp or Auto-antenna relay control terminal
(max. 300 mA 12 V DC).
When you connect a power amp (sold
This product
separately), be sure to use the blue/white
lead of this unit. If you use the blue/white
lead of the head unit, it causes noises.
Rear output
Front output
Center output
Subwoofer output
Power amp
(sold separately)
Power amp
(sold separately)
Power amp
RCA cables
(sold separately)
(sold separately)
Power amp
(sold separately)
+
+
Front speaker
Front speaker
+
+
Rear speaker
Rear speaker
+
+
Center speaker
Subwoofer
