8 fOOT VALANCE
aSSEMBLY iNSTRUCTIONS
Bottom Frame
Valance Frame
SETUP
1) Insert pipes with buttons ( , , ) into fittings with
button holes ( ). Make sure the button snaps into button
hole securely.
Snaps
2) Position Bottom Frame into a rectangle with snaps facing
outward.
3) Assemble Valance Frame and snap vinyl onto frame.
4) Lift the Valance Frame, insert into the Bottom Frame
sockets.
5) Snap Skirt onto Bottom Frame, starting at one end.
6) Clip counter legs onto Bottom Frame. Attach counter
support cross braces.
7) Align counters over Hook & Loop and press down firmly
to secure.
8) Place optional undercounter shelf on bottom counter leg
brace.
