6 . D E S C R I P T I O N
X 1 + F R / S C H U K O - I E C - U K – 5 0 0 T O 2 2 0 0 V A - F R O N T P A N E L
X1+ 500/700/1000 VA

ON/OFF LED indicator (LED is illuminated in orange when the UPS is working)

Information LED indicators (X1+ 1300/1600/2200 VA only)
LED indicators:
▪
Green LED: AC mode is present
▪
Yellow LED: Battery mode
▪
Red LED: fault mode
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 10 23 AA 36 204 13


X1+ 1300/1600/2200 VA
