1 0 . T R O U B L E S H O O T I N G
Should the UPS fail to function correctly we recommend you perform the following tests before
calling the Hot Line.
Check list:
• Is the UPS plugged into the mains power supply?
• Is the main switch in the "ON" position?
• Does the power supply fall within specified unit values?
• Is the UPS overloaded?
• Is the battery flat or defective?
LED indications and alarm
500/700/1000
LED lighting
Normal
Flash once
Battery
every 30
Discharge
seconds
Flash once
every 2
Battery Low
seconds
Flash once
every 0.5
Overload
seconds
Off charging
LED off
mode
LED off
Fault
Problem
The UPS does not
perform expected
runtime
The UPS will not
turn on.
Outlets do not
provide power to
equipment
Power Master
software is inactive
