Computer Interface; Battery - INFOSEC UPS SYSTEM X1+ User Manual

Do not obstruct the ventilation slots. Install the unit in an environment which is free from dust,
chemical vapours and conductors. Moreover, in order to avoid any interference, keep the UPS
at least 20 cm away from the CPU (central processing unit).
4. Connection
Check the identification plate at the top of the UPS to make sure that the power supply is
compatible with network voltage and that the device is powerful enough to protect the given
load. Plug the UPS power cable into a 2-pole, earthed outlet. Then, plug directly your
equipment in FR/Schuko or UK outlets or IEC cables to connect your equipment in X1+ IEC
model.
5. On/Off
To turn the UPS unit on, lightly press the power switch for 2 seconds. To turn it off, press the
power switch again.
Note: For maintenance purposes, please turn the UPS on before the PC and other loads, and
turn it off after the connected loads are turned off. When turning on X1+, the ON/OFF button
will light orange.
6. DC Start
X1+ is equipped with an integrated DC start function. To start the UPS in the absence of a
power supply and with a full battery, simply press the button for 2 seconds.
8 . C O M P U T E R I N T E R F A C E f o r X 1 + F R / S C H U K O 5 0 0 , 7 0 0 , 1 0 0 0 ,
1 3 0 0 , 1 6 0 0 & 2 2 0 0 V A
To prevent an abrupt computer system shutdown, connect a USB cable to your computer.
Then you can install and use the automatic shutdown software.
Power Master+ management software provides a user-friendly interface for your power
systems. Please follow procedure below to install the software.
Installation procedure:
1. Free download Power Master software from the website: www.infosec-ups.com
2. Double-click the file and follow the installation steps. When your computer restarts, the
Power Master+ software will appear as a blue icon located in the system tray.
9 . B A T T E R Y
The battery is the only UPS component which is not in permanent use. It has a useful life of
approximately 3 to 5 years. However, frequent major discharges or exposure to temperatures
over 20C will shorten its life span. We therefore recommend that users recharge the battery
once every 3 months when the unit is not in use in order to compensate for natural discharging.
UPS backup time will depend on the powered load, as well as the age and condition of the
batteries.
WARNING!
Batteries should always be replaced by qualified technicians. Batteries have a very high
short circuit current: connection errors could cause electric arcs resulting in serious
burns.
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
10
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 11 23 AA 36 204 14
