- Page 1 Bottle Cage Adapter...
- Page 2 Table of Contents About Installation...
- Page 3 About About the Bottle Cage Adapter The Swytch Bottle Cage Adapter enables you to install your Swytch Kit on your frame in place of a bottle cage, creating additional space on your handlebars. Included in this box: Loose in the box...
-
Page 4: Exploded View
Exploded View Please refer to the Bottle Cage Adapter installation graphic below to identify items on the parts list, and for guidance during assembly. -
Page 5: Installation
2. Installation Screw the Bottle Cage Adapter main group on to your bike Note The Bottle Cage Adapter main group can be simply screwed to your bike Tighten to 2-3 Nm of torque. using the 3mm Allen key and the Visit swytchbike.com/manual/3nm/... - Page 6 Installation Remove the bracket from the mount Using the 3mm Allen key, remove the bracket from the mount. Guide the mount cables through the hole in the adapter Guide all the cables coming out of the mount through the hole in the adapter, as shown.
- Page 7 Fit the mount into the bend of the adapter, it should be a tight fit. Determine which cables you require for your bike setup Determine which cables you require and don’t require for your Swytch bike. The standard kit requires the following cables: Display...
- Page 8 Installation Tuck the unrequired cables and the pedal sensor inside the cable guide like shown Tuck any unrequired cables into the Tuck the pedal sensor cable into the cable guide. In our example we won’t guide as well. We will need to short- need the brake sensors or throttle en it by wrapping it inside the cable cable so they are tucked inside as...
- Page 9 Installation Loop twice round the pedal sensor in the cable guide Feed the pedal sensor cable up the Exit the pedal sensor out the side of the cable guide. bottom hole in the adapter. Install the pedal sensor following Loop the pedal sensor cable twice the main instruction manual steps.
- Page 10 Installation Connect up the three display extension cables 10.1 Connect together the three display extension cables provided. This allows you to have your display mounted on your handlebars. The cable connectors are colour coded. The tall end of the connector connects with the short end.
- Page 11 Connect up 12.1 Connect up all the remaining cables Check your brakes and steering to the parts of the Kit following your still function as normal. Do not bikes cable routing. cable tie your brakes down. 12.2 Secure the cables to the frame using the cable ties and cut the ends using scissors.
