- Page 1 Installation, Operation and Maintenance Manual Fan Powered Air Terminal Units (ATU)
-
Page 2: Table Of Contents
Document 1041403 Model XG-FCI, XG-FVI, XG-FCL, XG-FVL, XG-FCQ ® Fan Powered ATU Installation, Operation and Maintenance Manual Please read and save these instructions for future reference. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with these instructions will result in voiding of the product warranty and may result in personal injury and/or property damage. -
Page 3: Receiving Inspection And Hanging/Installation Requirements
The model number code provides basic identification of the unit. Brand Model Series Case Inlet 1 Inlet 2 Attenuator Greenheck FCI, FVI, FCL, 1, 2, 3, 01-, 02-, 03-, 04-, 05-, 06-, 00-, 04-, 05-, IDA, NA, FVL, FCQ 4, 5, 6,... -
Page 4: Installation
Installation CAUTION: HAZARD OF EQUIPMENT DAMAGE Do not use the flow sensor, connecting tubing or damper shaft as a lift point. Damage to the components may result. NOTICE: Unit is not recommended for installation above 2,000 m. The Fan Powered Air Terminal should be suspended from the building structure in a horizontal plane with the bottom access panel facing down. - Page 5 NOTICE: Trapeze hangers are not recommended as 1. Slip each inlet duct over the inlet collar of the Fan they can block the bottom access panels for the motor Powered Air Terminal. and blower. 2. Fasten and seal the connection by method prescribed Fan Powered Air Terminal Units are not designed nor by job specification.
- Page 6 NOTICE: If the unit is not ordered with an internal FAN POWERED AIR TERMINALS disconnecting device then a disconnection device that WITH HOT WATER COILS shall disconnect all phases must be provided by the CAUTION: customer and incorporated in the fixed wiring. HAZARD OF EQUIPMENT DAMAGE FAN POWERED AIR TERMINALS The copper tubing should not be used as lift points.
-
Page 7: Troubleshooting
Troubleshooting Investigating Noise Complaints Electric Duct Heater • Noise from a Single Duct Air Terminal can be due to a CAUTION variety of conditions and can be difficult to eliminate. Use extreme care if testing the electric heater with • The first step is to isolate the type, source and power on. - Page 8 Specific Electric Heater Troubleshooting Procedures: PROBLEM: Heater Does Not Energize Cause Solution 1. With a voltmeter, check the power wiring terminals to ensure proper voltage is available to Power not properly connected to the the heater element side of the power terminal block or to the field side of the disconnect heater switch, power fusing or circuit breaker.
- Page 9 Specific Electric Heater Troubleshooting Procedures: PROBLEM: Heater Does Not Energize Cause Solution 1. Allow the duct temperature to cool down below 90ºF. Automatic Safety Reset Switch is 2. If the heater still does not energize, jumper out the automatic safety reset switch. 3.
- Page 10 14x8 Rect 2450 16 FLat Oval 16.25 20x16 Rect 07 Rnd XG-FCl C4 16x8 Rect 2770 24x16 Rect 08 Rnd XG-FCI, XG-FCQ, & 18x16 Rect 6200 09 Rnd XG-FVI C7 10 Rnd XG-TH 20 20x16 Rect 6430 K Factor 12 Rnd...
- Page 11 As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications without notice. Product warranties can be found online at Greenheck.com, either on the specific product page or in the literature section of the website at Greenheck.com/Resources/Library/Literature.
