  • Page 1 Mixed Flow Fans Belt and Direct Drive Models QEI-L, QEI, QEID 2012...
  • Page 2 Quiet & Efficient, Inline Mixed Flow Fans Model QEI-L – Belt Drive Mixed flow inline fans can be used for supply, exhaust, • 11 sizes available (12 thru 36) or return air installations. Our patented design excels • Volume Range: 700 - 40,000 cfm in commercial applications where low sound is critical. (1190 - 67,960 m /hr) In addition, Greenheck’s mixed flow fans are more • Static Pressure: Up to 5 in. wg (1245 Pa) efficient than comparably sized tubular centrifugal and vane axial fans, thus reducing the required motor horsepower and lowering operating costs. Greenheck’s mixed flow fans are the quietest tubular inline fans in the industry! • Performance as cataloged is assured. All sizes are licensed to bear the AMCA Certified Sound (both inlet and outlet) and Air Performance Seal.
  • Page 3 Standard Construction Housing Slip-Fit Duct Connection (QEI-I/II & QEID) Tubular housings are constructed of welded steel to Inlets and outlets are designed with extended collars eliminate air leakage. Integral straightening vanes are for slip-fit duct connections as standard. QEI-L is constructed from steel and welded into place. flanged as standard. Companion flanges can be ordered for slip fit connections. Wheel – Mixed Flow Adjustable Motor Bases (Belt Drive) Fabricated wheels are constructed from steel. The blade profiles are angled and contoured for the most Rigid, heavy-gauge steel motor bases are welded to efficient and quiet performance. the fan housing and include heavy-duty adjustment screws for belt tensioning. Bearings (Belt Drive) Extended Lube Lines Standard bearings are premium air handling quality, grease lubricated, self-aligning, ball or roller type. Belt drive units have nylon lubrication lines with Bearings are selected with a basic rating fatigue life grease fittings that allow bearing lubrication without per ABMA standards, in excess of 80,000 hours...
  • Page 4 Value Added Features Quality Assurance Test Before shipment, all Greenheck mixed flow fans are tested at the design speed after final assembly. QEI-L fans are checked for amp draw and the levels are recorded. QEI-I/II and QEID fans are subjected to a complete vibration analysis. The maximum allowable vibration on a QEI-I/II at the fan bearings is 0.15 in/sec. peak velocity for the specified RPM. QEID maximum vibration is 0.08 in/sec. peak velocity on the fan housing for the specified RPM. A record of the vibration test result is available upon request. By performing the vibration test, we are able to provide more than wheel balancing, it is also a diagnostic tool for finding potential problems. A defective bearing or motor, bent shaft or misaligned sheaves may cause excessive vibration. A complete vibration test will uncover these problems before the fan leaves the factory. Electrostatic Powder Coatings Powder coatings offer a uniform, durable and high-quality finish. Standard powder coating is a one-coat process applied over a phosphatized surface that generally meets or exceeds the corrosion resistance of a comparable wet paint. Greenheck offers a number of in-house coatings applied via “electrostatic powder.” The standard coating, Permatector™, is excellent for indoor or outdoor applications and is resistance to many common chemicals. Consult Greenheck’s Product Application Guide, Performance Coatings for Ventilation Products, for a complete listing of coatings and a relative resistance chart. For corrosive environments (i.e. coastal), see page 9 for information on our zinc-rich basecoat technology.
  • Page 5 Inlet and Outlet Sound Power Levels All Greenheck mixed flow fans have AMCA licensed sound power levels for both the fan inlet and outlet. Application and installation determines which sound power reading (inlet, outlet, or both) is critical. The differences between the generated sound from the inlet and outlet are important and noticeable. AMCA licensed inlet and outlet sound power data provides complete sound information to select a fan based on the acoustical requirements. For additional information on sound, refer to page 6. Greenheck’s Sound Lab Field Rotatable Housing / Compact Size The QEI-L and QEI are designed to accommodate changing fan mounting positions and motor orientation in the field. Mounting fixtures are securely bolted to the fan casing and can be relocated to reposition how the fan is installed or the position the motor is oriented. Flexibility in a motor’s location is important for easier access and can determine where the unit will fit. Last minute design changes or unexpected obstacles during installation are no longer a problem. Greenheck’s mixed flow fans were designed for compact size. Keeping size to a minimum is important when fitting into tight spaces like mechanical rooms or air handlers. Slip-Fit Duct Connections The inlet and outlet ends of the QEI-I/II and QEID are designed to accept “slip-fit” connections. Often companion flanges are bolted to a fan’s inlet/outlet flange to provide a slip-fit connection for a flexible sleeve, as with the QEI-L. This extra step is now eliminated by directly attaching the flexible sleeve to the duct and fan. This saves time and money in the installation process. It is recommended to use a flexible sleeve connection instead of a rigid duct connection.
  • Page 6 Design & Performance Mixed Flow: Axial/Centrifugal Hybrid Centrifugal A mixed flow wheel is a hybrid between an axial propeller and a centrifugal wheel. The result is a design that combines the best axial and centrifugal properties: highly efficient air movement, increased Mixed Flow pressure capabilities, extremely low sound levels, and a steep fan performance curve. To further enhance the fan’s performance, Axial straightening vanes are incorporated in the housing. These serve to convert swirling airflow into a straight axial flow with a resulting static pressure rise and energy savings. Airflow Profiles Axial Fans: Straight through nearly linear airflow. Centrifugal Fans: Two 90° deflections, before airflow exits the fan. Mixed Flow Fans: Slight airflow deflection from Axial Centrifugal Mixed Flow straight through. Sound and Efficiency Sound power levels and fan efficiency are two very important factors when selecting a fan. There is a noticeable difference between impeller types. The table and chart below compare the sound power (L A) and the static efficiency of the belt-driven mixed flow fan wheel versus tubular centrifugal and vane axial inline fans. Over a wide range of operating points, the mixed flow fan provides the quietest and most efficient selection.
  • Page 7 Wheel Characteristics Belt Drive: Fan Class Class I and II fans have different wheel designs with different performance characteristics. Class I mixed flow wheels are optimized for performances involving low pressures and high volumes. Class II wheels are designed for a steeper fan curve with higher pressure capabilities. This is illustrated in the graph with the two different class wheels plotted at identical fan RPMs. When selecting a mixed flow fan, it cannot be assumed that moving into a Class II fan will produce the same results as a Class I mixed flow fans. Model QEI-L utilizes a Class I wheel. Class II Class I Direct Drive: Percent Wheel Width Direct drive mixed flow fans are optimized for performance requirements by the use of partial width wheels. This is necessary because the fan RPM is commonly fixed and identical to the motor RPM. A reduction in the width of the wheel (or the air passage) results in reduced airflow capacity and a steeper fan curve. This is similar to the effect of a reduced pitch in a direct drive vane axial fan. QEID wheels are available in 5% increments from 50 - 100% wheel width. QEID fans can be used in conjunction with variable frequency drives (VFD’s) for variable air volume (VAV) systems. In these applications, the wheel width is optimized to ensure efficient operation and stable performance throughout the turndown range. VFD’s are also used for final system balancing and to reduce the airflow when building requirements are reduced. In this case, the fan and wheel width are selected using the Inter final design CFM and static pressure. Wheel 50% Wheel Width Width 100% Wheel Width Intermediate 100% Wheel...
  • Page 8 Optional Features Sure-Aire™ The Sure-Aire™ flow monitoring system measures fan flow within a 3% accuracy. Unlike traditional flow probes mounted in the fan venturi that create a system effect hindering fan performance, Sure-Aire™ does not interfere with airflow and will not impact the fan’s air or sound performance. This option is available on all mixed flow fan models and ships completely assembled from our factory. An electronics package with pressure transmitter and digital read out is available with the Sure-Aire™ system. The electronic kits are available for 50 or 60 Hz power supplies and provide a 4-20 mA output that can be tied into the building’s automation system. Sound Sensitive Areas Sound Vault Housing - Radiated Sound Enclosure The sound vault housing is an excellent product for fans that will be positioned adjacent to an occupied work space or in sound critical applications. It locks in radiated sound from the fan casing, motor and drives, and minimizes vibration transmission. Standard construction includes an acoustically lined housing, integral spring isolators, and internal flexible connections at the fan’s inlet and outlet to effectively isolate the fan from the system. Vertical or horizontal mounting configurations are available. Why use a Sound Vault? • Sound power attenuation levels determined by sound intensity tests on actual units • Ships fully assembled with fan • Internal isolation to limit breakout noise • Access panels for inspection of fan and motor • Bearing lubrication lines extended to outside of...
  • Page 9 Optional Two-coat Paint System In 1972, Greenheck took the lead as the first commercial and industrial fan manufacturer to introduce electrostatic powder coatings. Today, Greenheck continues to lead by being the first to offer a superior zinc-rich powder basecoat and powder coating finish. This zinc-rich basecoat technology is used extensively outside the HVAC industry to protect bridge beams, automotive components and other heavy-gauge steel products. Now, this advanced technology is available on Greenheck welded steel products. Greenheck’s coating process starts with a minimum of five wash stages to treat all components prior to painting. Cleaner parts result in better coating adhesion and durability. We then use an advanced two-coat powder application method that includes a basecoat of zinc-rich powder and a topcoat of Greenheck’s Permatector™ or Hi-Pro Polyester. The combination of these two topcoats over the zinc-rich basecoat results in the two-coatings, Perma-Z and Hi-Pro-Z. These oven-cured coatings provide superior corrosion resistance along with a tough, uniform finish to combat the most extreme conditions. Zinc Advantage When compared to a traditional single coat One Coat Process application, the benefits of the two-coat system include: Topcoat Standard 2-3 mils Surface Preparation • An automatic powder coat application that produces uniform coverage and Base Steel unmatched paint quality. • A double coat thickness that provides superior durability and protection from Two-coat Process Zinc-rich Primer air and water. (70% zinc) Topcoat • A zinc-rich basecoat that includes...
  • Page 10 Certifications & Listings Tau Bot 7880 7090 6300 5510 Seismic Certification 4720 3930 3140 2350 1560 The International Building Code (IBC) has been adopted at the state and local level throughout the United States. With the adoption of this code, comes the introduction of standards intended to improve the performance and design of non-structural systems subject to seismic events. QEI-I/II and QEID • Meet the 2006 IBC, 2009 IBC • California OSHPD requirements (horizontal mount only) OSP 0223-10 • S hake table tested at an independent test facility in accordance with ICC-ES AC 156 Structural Finite Element Analysis • All equipment certified to worst case scenario seismic conditions Results for LC 3, EQ neg Z dir (0.7*4.5) Rice Engineering Inc QEI-54 Class I Seismic Design Category F...
  • Page 11 Belt Drive versus Direct Drive Belt Drive Advantages • Lower sound levels • Motor out of the airstream for easy access • Motor size may be changed to accommodate possible future air capacity requirements • Final system balancing accomplished by changing drives Direct Drive Advantages • Fewer wear components and less maintenance, no shaft, bearings, pulleys, or belts • More compact than equivalent belt drive size • Motor in airstream for increased motor efficiency and cooling • Equal loading between mounting brackets • Final system balancing accomplished by adjusting the motor speed (ex. variable frequency drive use). High Efficiencies = Lower Operating Costs Example of Annual Operating Cost Savings For a system performance requirement of 25,000 cfm at 2.5 inches of static pressure (wg) the corresponding operating power requirements are 13.97 Bhp with a QEI-I size 36 and 19.8 Bhp for a size 36 tubular centrifugal fan.
  • Page 12 Belt Drive Mounting Configurations QEI-I/II Sizes 9-27 and all QEI-L Universal Mounting QEI-I/II models sizes 9-27 and all QEI-L models can be mounted horizontally or vertically. For ease of installation, eight mounting brackets are welded on each fan. These Optional Mounting eight brackets along with standard mounting supports Rails provide for Greenheck’s Universal Mounting System. Motor positions are viewed from the discharge end. Fig. 1 Horizontal Base Mount Fig. 1 Fig. 2 Each fan is shipped as standard in this arrangement. Motor at “A” position (12 o’clock) is standard. Fig. 2 Horizontal Base Mount with motor at “C” or “G” position (3 or 9 o’clock). A set of optional mounting Optional Mounting rails are recommended for this installation. Rails Fig. 3 Horizontal Ceiling Hung In this installation the supports can be positioned for mounting the motor at “A” or “E” (12 or 6 o’clock). Fig. 4 Horizontal Ceiling Hung with motor at “C” or “G” (3 or 9 o’clock). A set of optional mounting rails are Fig.
  • Page 13 Roof Upblast & Spark Resistant Construction Roof Upblast Models QEI-I/II sizes 9 through 54 and model QEID sizes 12 through 54, are available in roof upblast configuration. The roof upblast configuration is ideal for exhausting contaminants away from a building to prevent roof damage and re-entrainment of exhaust air. Both QEI-I/II roof upblast models have the high temperature UL rating and can be used for emergency smoke exhaust applications. Standard construction includes a fully-welded heavy- gauge curb cap to eliminate leaks, a butterfly damper section for backflow prevention, and a windband section to protect the butterfly dampers from debris. A complete line of roof curbs is available for mounting to a roof deck. Spark Resistant Construction Greenheck mixed flow fans are available with spark resistant designs suitable for applications that involve flammable particles, fumes or vapors. Spark resistant construction options adhere to guidelines defined within AMCA Standard 99-0401-10. The fan wheel is constructed of a nonferrous material (aluminum). QEI-I/II Spark B A non-ferrous (aluminum) bearing cover surrounds the driven bearing, shielding it from the airstream. The inlet cone is constructed of non-ferrous material (aluminum). QEI-I/II Spark C A nonferrous (aluminum) bearing...
  • Page 14 Accessories Availability QEI-L QEI-I QEI-II QEID Motor Cover A weatherproof motor cover shields the motor components from dust, dirt and moisture for indoor or outdoor    installations. Motor covers also serve as a personnel guards and meet OSHA standards. Hinged Access Door Hinged access doors provide an opening through the fan housing for cleaning or visual inspection of the wheel. Bolted     access door is standard. Extended Life Air handling quality, flange mounted bearings meet a basic Bearings rating fatigue life L per ABMA standards, in excess of   200,000 hours (L at 1,000,000) at maximum operating speed. Copper Lube Lines Copper lube lines can be used as a replacement for    (Belt Drive) standard nylon lube lines. Flanges Inlet and outlet flanges with prepunched holes, welded to the housing, provide an easy means for bolted connection Std.

  • Page 15: Exploded View

    Exploded View Motor Cover Companion Flange Slip Fit Connection (Standard on QEI-I/II) Inlet Guard Outlet Flange (Standard on QEI-L) Outlet Guard Bolted Access Door (Standard) Spring Base Isolator Neoprene Base Isolator Inlet Flange (Standard on QEI-L) Companion Flange Spring Hanging Isolator Mounting Rails...
  • Page 16 Direct Drive Selection Charts The quick select charts below and on the following page are a convenient method for sizing the fan required for a specific performance. Colored bands for a given size in each chart represent the entire operating range available for that size and speed. For QEID performance pages showing AMCA Licensed data for sound and air performance please refer to the Model QEID Sound and Air Performance Supplement found at www.greenheck.com 1770 RPM (60 Hz) Static Pressure (in. wg) Model QEID 12—33 Volume (cfm x 1000) 1170 RPM (60 Hz) Static Pressure (in. wg) Model QEID 15—49 Volume (cfm x 1000)
  • Page 17 QEID Dimensional Data 870 RPM (60 Hz) Static Pressure (in. wg) Model QEID 36—54 Volume (cfm x 1000) Slip Fit O.D. Length* Weight** Size inches inches lbs. 17.13 25.0 20.88 25.0 Slip Fit O.D. 23.00 26.0 25.38 29.0 27.81 34.0 30.88 35.5 34.00 41.5 1054 37.44 45.0 1143...
  • Page 18 QEI Dimensional Data QEI-L Airflow Height Airflow Slip Fit Height Height O.D. Length Length QEI-L QEI Class I QEI Class II Slip-Fit O.D. Length Height Slip-Fit O.D. Length Height Length Height Size inches (mm) inches (mm) inches (mm) inches (mm) inches (mm) 17.13 (435) 28.5 (724)
  • Page 19 QEI-9 Class II Performance Data % WOV Maximum Fan RPM 4000 Density 0.075 lb/ft Density 1.2 kg/m Specification Data Maximum Motor 184T Frame Size Minimum Motor 1½ 1/3 hp .25 kW Starting hp Wheel Diameter 15 in. 381 mm Approximate Weight ¾ 170 lbs. 77 kg. (Less Motor & Drives) ½ Maximum Bhp = (Fan RPM / 2671) Outlet Velocity (FPM) = CFM / 1.56 Tip Speed (FPM) = Fan RPM x 3.93 % WOV = (CFM x 100) / (Fan RPM x 0.73) Volume (cfm x 100) Imperial data — Metric data...

  • Page 20: Performance Data

    QEI-12 Class I & QEI-L Performance Data QEI-L 3800 Maximum % WOV Density 0.075 lb/ft Fan RPM Density 1.2 kg/m 3800 Specification Data Maximum QEI-L 184T Motor 184T Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter 15 in. 381 mm QEI-L 120 lbs. 55 kg. Approximate Weight (Less Motor & Drives) 160 lbs.
  • Page 21 QEI-12 Class II Performance Data 7½ Maximum Fan RPM 4000 % WOV Density 0.075 lb/ft Density 1.2 kg/m Specification Data Maximum Motor 184T Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter 15 in. 381 mm 1½ Approximate Weight 180 lbs. 82 kg. (Less Motor & Drives) ¾ Maximum Bhp = (Fan RPM / 2345) ½ Outlet Velocity (FPM) = CFM / 1.56 Tip Speed (FPM) = Fan RPM x 3.93 % WOV = (CFM x 100) / (Fan RPM x 1.16) Volume (cfm x 1000)
  • Page 22 QEI-15 Class I & QEI-L QEI-15I Performance Data 50% WOV QEI-L 2721 Maximum % WOV 60% WOV Density 0.075 lb/ft Fan RPM 2721 Density 1.2 kg/m Specification Data 70% WOV Maximum QEI-L 184T Motor 80% WOV 213T Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter 18.25 in.
  • Page 23 QEI-15 Class II QEI-15II Performance Data 50% WOV 7½ 60% WOV Maximum Fan RPM 3445 % WOV Density 0.075 lb/ft Density 1.2 kg/m Specification Data 70% WOV Maximum Motor 215T 80% WOV Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter 18.25 in. 464 mm Approximate Weight 220 lbs.
  • Page 24 QEI-16 Class I & QEI-L QEI-16I Performance Data 50% WOV 7½ QEI-L 2300 Maximum % WOV 60% WOV Density 0.075 lb/ft Fan RPM 2483 Density 1.2 kg/m Specification Data 70% WOV Maximum QEI-L 184T Motor 80% WOV 213T Frame Size Minimum Motor 1/3 hp .25 kW Starting hp 1½...
  • Page 25 QEI-16 Class II Performance Data Maximum Fan RPM 3145 Specification Data Maximum Motor 215T Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter 20 in. 508 mm Approximate Weight 240 lbs. 109 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 1430) Outlet Velocity (FPM) = CFM / 2.79 Tip Speed (FPM) = Fan RPM x 5.24 % WOV = (CFM x 100) / (Fan RPM x 2.89) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 3000 1075 1199 0.50 1342...
  • Page 26 QEI-18 Class I & QEI-L QEI-18I Performance Data 7½ QEI-L 2232 Maximum 50% WOV % WOV Density 0.075 lb/ft Fan RPM 2232 60% WOV Density 1.2 kg/m Specification Data 70% WOV Maximum QEI-L 215T Motor 80% WOV 215T Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter...
  • Page 27 QEI-18 Class II Performance Data Maximum Fan RPM 2777 Specification Data Maximum Motor 254T Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter 22.25 in. 565 mm Approximate Weight 310 lbs. 141 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 1219) Outlet Velocity (FPM) = CFM / 3.45 Tip Speed (FPM) = Fan RPM x 5.83 % WOV = (CFM x 100) / (Fan RPM x 3.80) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 3800 1101 1124 0.64 1239...
  • Page 28 QEI-20 Class I & QEI-L QEI-20 Class 1 Performance Data 50% WOV 7½ QEI-L 1900 Maximum % WOV 60% WOV Fan RPM Density 0.075 lb/ft 2027 Density 1.2 kg/m Specification Data 70% WOV Maximum QEI-L 215T Motor 215T 80% WOV Frame Size Minimum Motor 1/3 hp .25 kW...
  • Page 29 QEI-20 Class II Performance Data Maximum Fan RPM 2517 Specification Data Maximum Motor 254T Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter 24.5 in. 622 mm Approximate Weight 360 lbs. 163 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 1038) Outlet Velocity (FPM) = CFM / 4.14 Tip Speed (FPM) = Fan RPM x 6.41 % WOV = (CFM x 100) / (Fan RPM x 5.07) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 4500 1076 1002 0.74 1110...
  • Page 30 QEI-22 Class I & QEI-L QEI-22I Performance Data QEI-L 1800 Maximum 50% WOV 7½ % WOV 60% WOV Density 0.075 lb/ft Fan RPM 1839 Density 1.2 kg/m Specification Data 70% WOV Maximum QEI-L 215T Motor 254T 80% WOV Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter...
  • Page 31 QEI-22 Class II Performance Data Maximum Fan RPM 2265 Specification Data Maximum Motor 256T Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter 27 in. 686 mm Approximate Weight 420 lbs. 191 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 869) Outlet Velocity (FPM) = CFM / 5.12 Tip Speed (FPM) = Fan RPM x 7.07 % WOV = (CFM x 100) / (Fan RPM x 7.17) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 5600 1093 0.81 1.29 1174...
  • Page 32 QEI-24 Class I & QEI-L QEI-24I Performance Data 50% WOV QEI-L 1450 Maximum 60% WOV % WOV 7½ Density 0.075 lb/ft Fan RPM 1655 Density 1.2 kg/m Specification Data 70% WOV Maximum QEI-L 215T Motor 254T 80% WOV Frame Size Minimum Motor 1/3 hp .25 kW Starting hp Wheel Diameter...
  • Page 33 QEI-24 Class II Performance Data Maximum Fan RPM 2036 Specification Data Maximum Motor 284T Frame Size Minimum Motor 3/4 hp .55 kW Starting hp Wheel Diameter 30 in. 762 mm Approximate Weight 550 lbs. 249 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 729) Outlet Velocity (FPM) = CFM / 6.21 Tip Speed (FPM) = Fan RPM x 7.85 % WOV = (CFM x 100) / (Fan RPM x 9.84) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 6800 1075 0.97 1.56 1051...
  • Page 34 QEI-27 Class I & QEI-L QEI-27I Performance Data 50% WOV QEI-L 1280 Maximum 60% WOV % WOV Density 0.075 lb/ft Fan RPM 1505 Density 1.2 kg/m 7½ Specification Data 70% WOV Maximum QEI-L 215T Motor 80% WOV 256T Frame Size Minimum Motor 3/4 hp .55 kW Starting hp Wheel Diameter...
  • Page 35 QEI-27 Class II Performance Data Maximum Fan RPM 1847 Specification Data Maximum Motor 286T Frame Size Minimum Motor ⁄ 1.1 kW Starting hp Wheel Diameter 33 in. 838 mm Approximate Weight 670 lbs. 304 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 630) Outlet Velocity (FPM) = CFM / 7.54 Tip Speed (FPM) = Fan RPM x 8.64 % WOV = (CFM x 100) / (Fan RPM x 12.9) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 8300 1100 1.21 1.89 3.57...
  • Page 36 QEI-30 Class I & QEI-L QEI-30I Performance Data 50% WOV QEI-L 1200 Maximum 60% WOV % WOV Fan RPM Density 0.075 lb/ft 1360 Density 1.2 kg/m Specification Data 70% WOV Maximum QEI-L 256T Motor 80% WOV 284T Frame Size Minimum Motor 1 hp .75 kW Starting hp Wheel Diameter 36.5 in.
  • Page 37 QEI-30 Class II Performance Data Maximum Fan RPM 1670 Specification Data Maximum Motor 324T Frame Size Minimum Motor ⁄ 1.1 kW Starting hp Wheel Diameter 36.5 in. 927 mm Approximate Weight 1000 lbs. 454 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 533) Outlet Velocity (FPM) = CFM / 9.31 Tip Speed (FPM) = Fan RPM x 9.56 % WOV = (CFM x 100) / (Fan RPM x 17.4) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 10000 1084 1.43 2.26 4.31...
  • Page 38 QEI-33 Class I & QEI-L QEI-33I Performance Data QEI-L 1000 Maximum 60% WOV % WOV Density 0.075 lb/ft Fan RPM 1234 Density 1.2 kg/m Specification Data 70% WOV Maximum QEI-L 256T 80% WOV Motor 286T Frame Size Minimum Motor ⁄ 1.1 kW Starting hp Wheel Diameter 40.25 in.
  • Page 39 QEI-33 Class II Performance Data Maximum Fan RPM 1522 Specification Data Maximum Motor 324T Frame Size Minimum Motor 2 hp 1.5 kW Starting hp Wheel Diameter 40.25 in. 1022 mm Approximate Weight 1200 lbs. 544 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 450) Outlet Velocity (FPM) = CFM / 11.27 Tip Speed (FPM) = Fan RPM x 10.5 % WOV = (CFM x 100) / (Fan RPM x 23.5) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 12500 1109 1.76 2.84 5.47...
  • Page 40 QEI-36 Class I & QEI-L QEI-36I Performance Data QEI-L Maximum % WOV 60% WOV Fan RPM Density 0.075 lb/ft 1116 Density 1.2 kg/m Specification Data 70% WOV Maximum QEI-L 256T Motor 80% WOV 286T Frame Size Minimum Motor ⁄ 1.1 kW Starting hp Wheel Diameter 44.5 in.
  • Page 41 QEI-36 Class II Performance Data Maximum Fan RPM 1377 Specification Data Maximum Motor 326T Frame Size Minimum Motor 3 hp 2.2 kW Starting hp Wheel Diameter 44.5 in. 1130 mm Approximate Weight 1400 lbs. 635 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 381) Outlet Velocity (FPM) = CFM / 13.79 Tip Speed (FPM) = Fan RPM x 11.7 % WOV = (CFM x 100) / (Fan RPM x 31.7) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 15000 1088 2.08 3.39 6.58...
  • Page 42 QEI-40 Class I QEI-40I Performance Data Maximum Fan RPM 1013 60% WOV % WOV Density 0.075 lb/ft Specification Data Density 1.2 kg/m 70% WOV Maximum Motor 324T Frame Size 80% WOV Minimum Motor 5 hp 3.7 kW Starting hp Wheel Diameter 49 in. 1245 mm Approximate Weight 1500 lbs. 680 kg. 90% WOV (Less Motor & Drives) Maximum Bhp = (Fan RPM / 324)
  • Page 43 QEI-40 Class II Performance Data Maximum Fan RPM 1251 Specification Data Maximum Motor 364T Frame Size Minimum Motor ⁄ 5.5 kW Starting hp Wheel Diameter 49 in. 1245 mm Approximate Weight 1900 lbs. 862 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 324) Outlet Velocity (FPM) = CFM / 16.77 Tip Speed (FPM) = Fan RPM x 12.8 % WOV = (CFM x 100) / (Fan RPM x 42.4) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 18000 1077 2.48 4.06 7.91...
  • Page 44 QEI-44 Class I QEI-44I Performance Data Maximum Fan RPM 60% WOV % WOV Density 0.075 lb/ft Specification Data Density 1.2 kg/m Maximum Motor 70% WOV 326T Frame Size 80% WOV Minimum Motor ⁄ 5.5 kW Starting hp Wheel Diameter 54.25 in. 1378 mm Approximate Weight 2000 lbs. 907 kg. 90% WOV (Less Motor & Drives) Maximum Bhp = (Fan RPM / 273) Outlet Velocity (FPM) = CFM / 20.49...
  • Page 45 QEI-44 Class II Performance Data Maximum Fan RPM 1129 Specification Data Maximum Motor 365T Frame Size Minimum Motor 10 hp 7.5 kW Starting hp Wheel Diameter 54.25 in. 1378 mm Approximate Weight 2300 lbs. 1043 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 274) Outlet Velocity (FPM) = CFM / 20.49 Tip Speed (FPM) = Fan RPM x 14.2 % WOV = (CFM x 100) / (Fan RPM x 57.5) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 22000 1074 3.02 4.95 9.67...
  • Page 46 QEI-49 Class I QEI-49I Performance Data Maximum Fan RPM 60% WOV % WOV Density 0.075 lb/ft Specification Data Density 1.2 kg/m 70% WOV Maximum Motor 364T Frame Size 80% WOV Minimum Motor 10 hp 7.5 kW Starting hp Wheel Diameter 60 in. 1524 mm Approximate Weight 7½ 2400 lbs. 1089 kg. (Less Motor & Drives) 90% WOV Maximum Bhp = (Fan RPM / 231)
  • Page 47 QEI-49 Class II Performance Data Maximum Fan RPM 1020 Specification Data Maximum Motor 405T Frame Size Minimum Motor 15 hp 11 kW Starting hp Wheel Diameter 60 in. 1524 mm Approximate Weight 3100 lbs. 1406 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 231) Outlet Velocity (FPM) = CFM / 24.85 Tip Speed (FPM) = Fan RPM x 15.7 % WOV = (CFM x 100) / (Fan RPM x 77.8) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 27000 1078 3.72 6.09 11.9...
  • Page 48 QEI-54 Class I QEI-54I Performance Data Maximum Fan RPM % WOV 60% WOV Density 0.075 lb/ft Specification Data Density 1.2 kg/m 70% WOV Maximum Motor 365T Frame Size 80% WOV Minimum Motor 10 hp 7.5 kW Starting hp Wheel Diameter 66 in. 1676 mm Approximate Weight 2900 lbs. 1315 kg. (Less Motor & Drives) 90% WOV Maximum Bhp = (Fan RPM / 197) Outlet Velocity (FPM) = CFM / 30.46...
  • Page 49 QEI-54 Class II Performance Data Maximum Fan RPM Specification Data Maximum Motor 405T Frame Size Minimum Motor 15 hp 11 kW Starting hp Wheel Diameter 66 in. 1676 mm Approximate Weight 3600 lbs. 1633 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 197) Outlet Velocity (FPM) = CFM / 30.46 Tip Speed (FPM) = Fan RPM x 17.3 % WOV = (CFM x 100) / (Fan RPM x 104) Imperial data — Metric data Performance Data STATIC PRESSURE (inches wg) 33500 1105 4.71 7.61 14.7 23.0...
  • Page 50 QEI-60 Class I Performance Data Maximum Fan RPM % WOV Density 0.075 lb/ft Density 1.2 kg/m Specification Data Maximum Motor 405T Frame Size Minimum Motor 15 hp 11 kW Starting hp Wheel Diameter 73 in. 1854 mm Approximate Weight 3500 lbs. 1588 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 167) Outlet Velocity (FPM) = CFM / 37.23 Tip Speed (FPM) = Fan RPM x 19.1 % WOV = (CFM x 100) / (Fan RPM x 159) Volume (cfm x 1000) Imperial data — Metric data Volume (m /hr x 1000) Performance Data...
  • Page 51 QEI-60 Class II Performance Data Maximum Fan RPM % WOV Density 0.075 lb/ft Density 1.2 kg/m Specification Data Maximum Motor 405T Frame Size Minimum Motor 15 hp 11 kW Starting hp Wheel Diameter 73 in. 1854 mm Approximate Weight 4200 lbs. 1905 kg. (Less Motor & Drives) Maximum Bhp = (Fan RPM / 167) Outlet Velocity (FPM) = CFM / 37.23 Tip Speed (FPM) = Fan RPM x 19.1 % WOV = (CFM x 100) / (Fan RPM x 140) Volume (cfm x 1000) Imperial data — Metric data Volume (m /hr x 1000) Performance Data...

  • Page 52: Specifications
