MODE ECO:
Your steam generator iron has an ECO mode function which uses less power whilst still guaranteeing a
sufficient steam flow for you to iron your garments properly. In order to use this function, once the
thermostat of your iron has been correctly set (see table above), position the steam flow setting on the
ECO segment
However, for very thick or wrinkled fabrics, we recommend using the maximum temperature in order to
guarantee best results.
Dry ironing
- Do not press the steam control button under the iron handle.
Recommendations: for
fabrics other than linen or
cotton, hold the iron a
few centimetres from the
garment to avoid burning
the fabric.
Refilling the water tank
• When the red "water tank empty" light starts flashing, it means that you have no more steam.fig.11.
1.Close the protection cover until you hear a "click". fig.2.
2.Remove the water tank by pulling on the handle (at the front of the generator) and fill it, taking care not to exceed
the maximum level.
3. Slide the tank back into its housing until its clicks into place.
4. Press the "restart" button on the control panel – fig.12. to continue ironing. When the green light stops flashing,
the steam is ready.
5. Open the protection cover – fig.3.
• Press the Turbo control 2 or 3 times when you need extra steam:
- for ironing thicker fabrics,
- for getting rid of creases,
- for powerful vertical steaming.
Use the Turbo function with care as its exceptional steam power can cause burns.
Catalysis Autoclean Soleplate
• The iron of your steam generator comes with a self-cleaning soleplate which functions by catalysis.
• Its unique coating makes it possible to eliminate all the impurities arising from normal usage.
• We recommend you always place your iron on its base or on the iron rest plate in order to protect its self-cleaning
coating.

Maintenance and cleaning

Cleaning your generator
• Do not use detergent or descaling products for cleaning the soleplate base-unit.
• Never hold the iron or the base unit under the tap.
• Cleaning the soleplate (depending on model): The iron of your steam generator comes with a
self-cleaning soleplate which functions by catalysis. Its unique coating actively allows it to
continually eliminate all the impurities which are generated every day when the appliance is in
normal use. Nevertheless, using your iron at an unsuitable temperature can leave marks which
will need to be cleaned manually. In this case we advise you to use a soft damp cloth on the
soleplate whilst it is still warm so as not to damage the coating.
• Clean the plastic parts of the appliance occasionally with a soft cloth.
Do not use any descaling substances
(vinegar, industrial descaling products,
etc.) when rinsing the anti-scale valve :
they could damage it. Before descaling
or cleaning your generator, you must let
it cool down for at least 2 hours to
avoid any risk of burns.
- .
fig.17 Using the Eco mode will allow you to press fabrics at minimum temperature ••.
• Set the iron temperature control slide and the steam output control dial (located on the
control panel) to the MAX position.
• Hang the garment on a coat hanger and hold the fabric slightly taut with one hand.
As steam is very hot : never attempt to remove creases from a garment while it is being
worn, always hang garments on a coat hanger.
• Holding the iron in a vertical position, tilted slightly forwards, press repeatedly on the steam
control button (underneath the iron handle) moving the iron from top to bottom – fig.9.
For longer generator life, and to avoid scale emissions, your generator is equipped
with a built-in anti-scale valve. This valve, located in the tank, automatically
removes the scale that forms inside.
Operation:
• An orange "anti-scale" light located on the control panel starts blinking to tell
you that the anti-scale valve needs rinsing - fig.14
TURBO Function (according to model)
Descaling your generator easily
74
Vertical steam ironing
Cleaning tip: For
easier, non-corrosive
cleaning of your
iron's soleplate, use a
damp sponge on the
soleplate while it is
still warm.
:
