Page 4
Control Box Control Box Mounting bracket With control box in place, secure it with M6 socket head bolts (14), split lock Slide control box on top of the drum washers (15), flat washers (16). support and beneath the tie bar bracket.
Page 5
Drum support Spacer Winch mount goes Pull in the direction Feet bolted in between of front feet downward...
Page 6
Connect to Yellow Connect to Connect to Terminal Red Terminal Black Terminal Connect to Ground Terminal Black Terminal Terminal Yellow Terminal Motor Ground Terminal Red Battery Cable Connect Black Battery Cable...
Page 7
Route through the right Route through the hole second left hole first End of the rope Route the rope underneath the winch drum Rope Once rope is threaded through both holes on the drum, tighten the set screws...
Page 9
Replace M6 Remove all Hardware M6 Bolts (11) Rotate gear box to desired position Ensure winch is in free-spool Secure all M6 Bolts back in place Optional Configuration 1...
Page 10
Figure 18 Push up to winch out Push down to winch in Strap loop for storage Figure 19 Plug remote cable into control box...
