Ideal Heating IMAX XTRA 2 Manual

Conversion kit natural gas to propane
Hide thumbs Also See for IMAX XTRA 2:

Advertisement

Quick Links

Download this manual
H E A T I N G
CONVERSION KIT
NATURAL GAS TO
PROPANE
IMAX XTRA 2
80 120 160 200 240
When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Heating.
For the very latest copy of literature for specification and maintenance practices visit our website idealheating.com
where you can download the relevant information in PDF format.
Sep 2021
UIN 228011 A02

Advertisement

loading
Need help?

Need help?

Do you have a question about the IMAX XTRA 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Ideal Heating IMAX XTRA 2

Summary of Contents for Ideal Heating IMAX XTRA 2

  • Page 1 When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Heating.
  • Page 2 Boilers that show CAT. I on the data badge cannot be converted. kW (NG) Product No. Imax Xtra 2 80 225464 Imax Xtra 2 120 225465 Imax Xtra 2 160...

  • Page 3: Kit Contents

    KIT CONTENTS HEAT INPUT "Q" = 0086 21 GROSS kW (Btu/h) kW (Btu/h) 80kW IMAX XTRA 2 M A X 80.0(272,950) 87.0(296,708) M I N 24.0 (81,900) 26.1(89,012) HEAT OUTPUT "P" = 230V 50HZ FUSED AT 13A CONDENSING N O N - C O N D ' G...
  • Page 4 CASING REMOVAL AND ACCESS CONTROL POD REMOVAL (SCREW) SECTION 3.7 SECTION 3.8 REMOVAL AND ACCESS FAN REMOVAL Top Panel 1. Remove the two bolts at the rear of the top panel. Lift up from side panel retention studs and remove. Control Pod 2.
  • Page 5 INSTALLING THE ORIFICE PLATE 1. Whilst supporting the gas valve, remove the four bolts The orifice plate should be orientated so that the etching securing the gas valve to the venturi. on the plate is facing the venturi and is visible . See views below for correct orientation.
  • Page 6 INSTALLING THE FLUE ADAPTOR (200 kW BOILER ONLY) Condensate collector 1. Remove the existing flue condensate collector from its 3. The flue adaptor has a cutaway which needs to be location in the boiler flue outlet as shown in the image orientated to the rear of the boiler for clearance against the above.
  • Page 7 Boiler Setup Configuration Diagram Quick > 3 start seconds Assisted Quick Start Imax Xtra 2 280kW assisted commissioning process NEXT Main Board Firmware V1.0 Display Firmware V1.0 NEXT Configuration List Boiler/System Pump: Boiler Pump After loading the settings CH1 Pump:...
  • Page 8 Steps to follow for boiler that has been previously configured This is when the Imax boiler has been installed and configured i.e. converted from a configured NG boiler to a LPG boiler. 1. Refer to safety section. 3. Follow the steps below to upload the parameters for propane.

  • Page 9: Gas Valve Adjustment

    GAS VALVE ADJUSTMENT Maximum rate adjustment Minimum rate adjustment 1. Switch the boiler on and set the boiler into service mode 4. To ensure the boiler operates at minimum rate without maximum which will last for 10 mins but can be exited modulating, set the fan speed to minimum following the earlier.
  • Page 10 ACCESSING SERVICE MODE FOR GAS VALVE ADJUSTMENT TARGET ACTUAL TARGET ACTUAL 75° 75° 75° 75° Hot Water Heating No Demand Demand On MENU Switched Live Control 8° 100% Burner Stabilisation Press MENU Menu Status Settings Service Configuration Access Level Press Service To set the boiler to run at To set the boiler to run at Maximum Rate for 10 Minutes...
  • Page 11 PROPANE DATA LABEL AND OVERLAY 1. Ensure that the boiler has had the correct orifice plate fitted 5. Once all details have been recorded, adhere one of the two and the parameters have been updated for Propane. tear off strips over the existing label at the rear of the boiler and the other one over the existing label on the cover of the 2.
  • Page 12 At Ideal Heating we take our environmental impact seriously, therefore when installing any Ideal Heating product please make sure to dispose of any previous appliance in an environmentally conscious manner. Households can contact their local authority to find out how.
