SFS 4133 Series
Full Installation Guide
Everything you need to get your Era 300 mounted, in no time
Before you start
...we just wanted to say thanks for choosing Vogel's. Smart choice.
And you're already making another smart choice – reading the manual! Keep reading to learn all about safe, efficient installation, and how to
use your new speaker stand.
Stay safe
Warning
Always read these safety instructions carefully before installing and using this product.
Following these instructions is strictly required. Incorrect mounting and/or installation could put you, your speaker, and your family at
substantial risk.
Don't dare risk it... Read all
https://manuals.vogels.com/en-us/sfs4133.html
SFS 4133 Series
1/7
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for vogel's SFS 4133 Series
Summary of Contents for vogel's SFS 4133 Series
- Page 1 2023-10-31 08:57 SFS 4133 Series SFS 4133 Series Full Installation Guide Everything you need to get your Era 300 mounted, in no time Before you start …we just wanted to say thanks for choosing Vogel’s. Smart choice. And you’re already making another smart choice – reading the manual! Keep reading to learn all about safe, efficient installation, and how to use your new speaker stand.
- Page 2 2023-10-31 08:57 SFS 4133 Series Vogel’s recommends that the mounting and/or installation of this product should be carried out by a suitably qualified expert. Vogel’s cannot be held responsible for any injury and/or damage caused by incorrect installation. Please be advised that this speaker stand is exclusively designed for the use with the Sonos Era 300 speaker model. Utilizing this stand with other models or brands could potentially result in instability, malfunction, or damage to your equipment, and may also pose a safety risk.
- Page 3 2023-10-31 08:57 SFS 4133 Series Got your tools ready? Don’t start without all the necessary tools: Cable guide tool (included) No.3 Allen key (included) Crosshead screwdriver Ready… set… get installing! Step 1: Assemble the speaker stand 1. Put the pole Ⓐ on the floor plate Ⓑ.
- Page 4 2023-10-31 08:57 SFS 4133 Series 3. Put the cable guide tool Ⓔ on the speaker plug of the ERA 300 cable (included with the speaker). 4. Push the plug with the cable guide tool Ⓔ into the bottom of the floor plate Ⓑ and through the pole Ⓐ.
- Page 5 2023-10-31 08:57 SFS 4133 Series Step 2: Attach ERA 300 to the speaker stand 1. Attach the Era 300 speaker to the top plate Ⓓ using the 2x M5*20mm bolts Ⓗ. 2. Connect the plug to the speaker. Job done now! Enjoy listening to your Era speaker! Having a cable mess? Do you need inspiration about how to hide and guide your cables? Take a look at our website vogels.com...
- Page 6 2023-10-31 08:57 SFS 4133 Series Confused? Unsure? Going crazy? There’s plenty of help waiting for you, online: info@vogels.com (mailto:info@vogels.com) www.vogels.com/contact (http://www.vogels.com/contact) facebook.com/ VogelsForSure/ (https://www.facebook.com/VogelsForSure/) instagram.com/ vogels_official/ (https://www.instagram.com/vogels_official/) www.youtube.com/ c/VogelsForSure (https://www.youtube.com/c/VogelsForSure) Simple troubleshooting Found a problem you can’t fix? Don’t panic… try these!
- Page 7 Vogel’s guarantee shall lapse in the following cases: If the product has not been installed or used in accordance with the instructions; If applicable, if the holes in the wall have not been properly drilled in accordance with the Vogel's installation instructions for the applicable wall type;...
