Summary of Contents for Branch Double Standing Desk
- Page 1 Double Standing Desk Assembly Guide...
- Page 3 The new way of working you’ve been waiting for. Scan here for a digital copy of your assembly guide.
- Page 4 Caution The system should be away from water and corrosion resistant gas.
- Page 5 Components Desktop Left Leg Right Leg Support Beam Bracket Cable Tray Screen Clip Connection Beam M6*12 Screw x24 Plastic Pad x24 ST3 5*19 Screw x4 M6*10 Screw x16 M6*16 Screw x8 ST4 8*19 Screw x4 Control Box Control Switch Power Cord M8*16 Screw x8 ST4 8*25 Screw x24 Plastic Lid...
- Page 6 Place the Desktop upside-down on a clean flat surface and position the Support Beam on top. Use the Allen Wrench to loosen the 4 set screws on the Support Beam and adjust the Beam width to align to the pre-drilled holes in the Desktop. Do not screw the Beam to the Desktop, you’ll do that in a later step.
- Page 7 Attach the Connection Beams (x2) to the legs using the M8*16 Screws (x8). Using two people, carefully flip the table over and then install the Cable Tray (x1) to the Connection Beams using the M6*16 Screws (x8).
- Page 8 Rubber Cushion Plastic Attach the Screen Clips (x2) to the Connection Beams using the M6*16 Screws (x8). Next, attach the Desktop Brackets (x4) to the ends of Support Beams using the M6*12 Screws (x8). Push the Rubber Cushions (x16) into the open holes of the Desktop Brackets. Then insert the Plastic Pads (x16) through bottom of each Rubber Cushion.
- Page 9 Attach the Desktops (x2). Align the pre-drilled holes in the Desktop to the Support Beam (as done in Step 1). Secure with the 8*25 Screws (x24). Position and screw down the Control Box (x2) with the 8*19 Screws (x8) and Control Switch (x2) with the 5*19 Screws (x4). For each Desk, connect the two Leg Motor wires, Control Switch wire, and power cable into the Control Box.
- Page 10 User Guide System Initialization Press and hold on both up and down arrow buttons together until the lifting column is at its lowest stand and you hear a beep, and the display shows the number for the lowest height. If the system doesn't work after this process, try repeating the procedure above again. Setting Memory Function When the desk rises to the height which you want to memorize, please press and hold the "M"...
-
Page 11: Optional Elements
Optional Elements In-Desk Power Optional: Attach the Power Boxes to the bottom of the Desktops using the included Screws (x8). Connect the power cord to building power. - Page 12 Contact Have a question, comment, or suggestion? hello@branchfurniture.com branchfurniture.com...
