Expert Manufacturing Princeton PN R Series Disassembly Instructions

Expert Manufacturing Inc.
Princeton
Return Freestanding
Disassembly Instructions
Product designed for disassembly
in a reasonable time frame.(5 minutes or less)

ITEM DESCRIPTION

1 TOP PANEL
2 GABLE LEFT
3 GABLE RIGHT
4 MODESTY PANEL
5 BLUM CONNECTOR
6 BLUM DOWEL
7 MODULAR CONNECTOR
8 MODULAR SCREW
9 WOOD SCREW
10 ADJUSTABLE LEVELLER
11 INSERT NUT
12 GROMMET
13 1/4-20 INSERT
Please contact Expert Manufacturing service representative
at 905.738.7575 for any questions or concerns.
6
4
7
2
10
11
NOTE:Any alteration to listed components will void the manufacturer's warranty.The manufacturer will not be responsible for any damage or bodlly harm
caused by alterations in accordance with national or local electrical codes and manufacturer's specifications.In accordance with the manufacturer's policy
of continual product improvement, the product presented in this document is subject to change without notice or obligation.
QTY MATERIAL
1 PARTICLE BOARD
1 PARTICLE BOARD
1 PARTICLE BOARD
1 PARTICLE BOARD
10
PLASTIC-Polypropylene PP
10 STEEL
4 STEEL
4 STEEL
8 STEEL
4 STEEL&PLASTIC
4 STEEL
1
PLASTIC-Polypropylene PP
34 STEEL
12
PNXXXXR

Required tools:

Phillips screwdriver size #2
Rubber mallet
Safety glasses
1
3
Page 1 of 2
