Expert Manufacturing Generic Dissambly Instruction

Expert Manufacturing Inc.
Generic
Princeton
Pedestal
Pedestal
Disassembly Instructions
Product designed for disassembly
in a reasonable time frame.(5 minutes or less)
ITEM DESCRIPTION
1 TOP PANEL
2 GABLE LEFT
3 GABLE RIGHT
4 BACK PANEL
5 BOTTOM PANEL
6 DRAWER BOX FRONT
7 DRAWER FILE FRONT
8 DRAWER BOX
9 DRAWER FILE
10 TITUS CAM
11 TITUS DOWEL
12 CASTER WITH BRAKE
13 CASTER WITHOUT BRAKE
14 WOOD SCREW
15 SLIDES/PAIR
16 HANDLES
Please contact Expert Manufacturing service representative
at 905.738.7575 for any questions or concerns.
4
2
15
5
13
NOTE:Any alteration to listed components will void the manufacturer's warranty.The manufacturer will not be responsible for any damage or bodlly harm
caused by alterations in accordance with national or local electrical codes and manufacturer's specifications.In accordance with the manufacturer's policy
of continual product improvement, the product presented in this document is subject to change without notice or obligation.
QTY MATERIAL
1 PARTICLE BOARD
1 PARTICLE BOARD
1 PARTICLE BOARD
1 PARTICLE BOARD
1 PARTICLE BOARD
1 PARTICLE BOARD
1 PARTICLE BOARD
1 PARTICLE BOARD
1 PARTICLE BOARD
20 STEEL
20 STEEL
4 STEEL&PLASTIC
4 STEEL&PLASTIC
48 STEEL
2 STEEL
2 ALUMINUM
PN22MBF
Required tools:
Phillips screwdriver size #2
Rubber mallet
Safety glasses
1
10
8
3
6
9
16
7
14
Page 1 of 2
