The TR-1 is Touch Tone program-
mable and will restrict Touch Tone
or pulse dialing on outbound calls.
F
e
a
t
u
r
e
s
F
e
a
t
u
r
e
s
• Phone line powered
• Non-volatile E
memory
2
• Compatible with Touch Tone or rotary phones
• .5 to 49.5 minute call timer with disconnect
• Programmable allow or restrict table stores up
to forty 12-digit phone numbers, prefixes or
area codes
• 6-digit bypass code for unrestricted access
• Programmable to ignore phone system line
access numbers
• Programmable ignore table stores up to
twelve 12-digit phone numbers, ideal for
67,
69, etc.
✱
✱
• Programmable maximum digit string length
• Concealed in a standard RJ11C jack
• Allow or restrict 1-800 numbers
• Operational alert tones
• Will not restrict dialing on inbound calls
• Allows emergency and toll free numbers
Carefully review all emergency numbers required for your area prior to installing the toll restrictor. These emergency numbers could include, 911, fire, police, rescue,
!
sheriff, poison center, etc. After installation of the toll restrictor is complete, make a test call to each of the emergency numbers for the area! This will allow you to
verify that you have not inadvertently blocked any required emergency numbers.
S
S
C
O
M
O
L
U
T
I
O
N
S
C
O
M
O
L
U
T
I
O
N
S
Prevent Telephone Line Abuse with a
Programmable Toll Restrictor
P
r
a
c
P
r
a
c
2
1
C
2
1
C
F
O
R
T
H
E
S
T
F
O
R
T
H
E
S
T
The TR-1 is a cost effective, user programmable Toll
Restrictor, ideal for applications where unauthorized
phone calls cannot be tolerated.
Concealed in a standard wall mount RJ11C jack, the
TR-1 is designed to allow or restrict local and/or
specified long distance numbers. The TR-1 provides
a 40-number allow/restrict table, a 6-digit bypass
code (allows authorized users unrestricted access),
and an inbound/outbound call timer with disconnect.
A
p
p
l
A
p
p
l
• Courtesy phones in banks, hotels, etc.
• Prevent outgoing calls on public phones, etc.
• Limit call times
• Force long distance calls through alternate
long distance carriers
• Prevent the use of hand held dialers
h
t
t
h
t
t
S
p
e
c
S
p
e
c
Power: Phone line powered (24V DC @ 20 mA minimum)
Dimensions: 70mm x 57mm x 22mm (2.75" x 2.25" x .88")
Shipping Weight: .45 kg (1 lb)
Environmental: 0° C to 32° C (32° F to 90° F) with 5% to 95%
non-condensing humidity
!
Connections: Phone- (1) RJ11 jack, Line- (2) screw terminals
Programmable
t
i
c
e
t
i
c
e
Tone/Pulse
Toll Restrictor
E
N
T
U
R
Y
E
N
T
U
R
Y
March 15, 2004
