• Phone line powered (no AC needed)
• Generates CPC disconnect on:
- Return to dial tone (programmable)
- Busy signal
- Reorder (fast busy)
- Steady silence (programmable)
• LED shows:
- In use
- Audio detected
- Generated CPC signal
• Caller ID compatible
