Summary of Contents for Burkert 6516 Series
- Page 1 Type 6516 – 6519 3/2, 5/2 or 5/3 way solenoid valve 3/2-, 5/2- bzw. 5/3-Wege-Magnetventil Électrovanne 3/2, 5/2 ou 5/3 voies Operating Instructions Bedienungsanleitung Manuel d‘utilisation...
-
Page 2: Intended Use
THE OPERATING INSTRUCTIONS INTENDED USE The operating instructions contain important information. Incorrect use of the solenoid valve Type 6516 – 6519 may be a hazard to people, nearby equipment and the surrounding area. ▶ Read the operating instructions carefully and follow the safety ▶... -
Page 3: Basic Safety Instructions
BASIC SAFETY INSTRUCTIONS Risk of injury due to malfunction of valves with alternating current (AC)! These safety instructions do not make allowance for any contin- Sticking core causes coil to overheat, resulting in a malfunction. gencies and events which may arise during assembly, operation and ▶... -
Page 4: Structure And Function
STRUCTURE AND FUNCTION 4.1.2 Type 6516 (3/2-way), Type 6517 (5/2-way) The valves can be mounted in blocks on the modular pneumatic base Cable plug Type 2506 rail Type MP07. Pilot valve Type 6106 4.1 Structure of the standard designs Indicator pin (see Chap."6.5") 4.1.1 Connections Control pressure port 14 All connections are identified by numbers on the valve surface. - Page 5 4.1.4 5/3-way function, 5/2-way function impulse 4.1.5 Type 6517 and 6519 with plastic body and NAMUR flange with adapter plate Pilot valve Type 6014 Cable plug Type 2508 3/2-way function Exhaust port 5 Pressure inlet port 1 5/2-way function Exhaust port 3 Pilot valve Type 6014 Cable plug Type 2508 Fig.
-
Page 6: Operating Principles
4.2 Operating principles 5/3-way valve Middle position all port connections closed, 3/2-way valve inlet port 1, outlet port 4 and 2, vent of outlet Normally inlet port 1 (P/NC) closed, outlet port 2 ports to 5 respectively 3. (A/OUT) conected with exhaust port 3 (R/NO). 5/3-way valve Middle postion pressure inlet port 1 (P) closed, 3/2-way valve for vacuum*, with auxiliary... -
Page 7: Technical Data
TECHNICAL DATA 5.4 Operating conditions Please observe the specifications on the data sheet and on the 5.1 Conformity type label. The solenoid valve Type 6516 – 6519 is compliant with EC directives as stated in the EC Declaration of Conformity. Types 6516 –... - Page 8 Important information for functional reliability during continuous Types 6516 – 6519 Type 6519 for extended operation! temperature range If the equipment is switched off for a long period, it is recom- Degree of IP65 as per DIN EN 60529 / IEC 60529 with mended to activate the valves at least 1-2 per day.
-
Page 9: Safety Instructions
ASSEMBLY Risk of injury from unintentional activation of the system and uncontrolled restart! 6.1 Safety instructions ▶ Secure system against unintentional activation. DANGER! ▶ Following assembly, ensure a controlled restart. Risk of injury from high pressure in the system! 6.2 Installation of the pilot valve ▶... - Page 10 6.2.1 Installation of the pilot valve Type 6106 (for 6.2.2 Installation of the pilot valve Type 6014 valve type 6516 / 6517) (for valve type 6518 / 6519) → → Installation always in the Screw the housing of the pilot position shown;...
-
Page 11: Pneumatic Connection
6.3 Pneumatic connection 6.4 Connection of cable plug to the power supply WARNING! WARNING Risk of injury from greatly accelerated device parts and uncon- nected whiplashing compressed air hoses! Risk of injury due to electrical shock! ▶ Before pressurizing the valve, check that all screw connections ▶... - Page 12 → Tighten cable plug (for authorized types see data sheet), observing Pesistor Test voltage Test current maximum torque (see "Tab. 1"). max. 0.1 Ω → 12 V Check that seal is fitted correctly. → Connect protective conductor and check electrical continuity Tab.
-
Page 13: Maintenance & Troubleshooting
DISASSEMBLY MAINTENANCE, TROUBLESHOOTING Disassembly is in reverse sequence to assembly. If the valve is used according to these operating instructions, the valve will operate maintenance-free. 8.1 Safety instructions WARNING! Risk of injury from improper maintenance! ▶ Maintenance may only be carried out by authorized technicians and with the appropriate tools! Risk of injury due to electrical shock! ▶... -
Page 14: Ordering Spare Parts
8.2 Malfunctions SPARE PARTS If malfunctions occur, check whether: CAUTION! • the device has been installed according to the instructions, Risk of injury and/or damage by the use of incorrect parts! • the electrical and pneumatic connections are correct, Incorrect accessories and unsuitable spare parts may cause injuries •... -
Page 15: Transportation, Storage, Disposal
9.2 Overview of spare part sets TRANSPORTATION, STORAGE, DISPOSAL Types 6518/6519 Types 6516/6517 NOTE! SET 1 SET 1 Transport damage! Coil set Pilot valve Inadequately protected devices may be damaged during transportation. ▶ Protect the device against moisture and dirt in shock-resistant packaging during transportation. - Page 16 Fax + 49 (0) 7940 - 10 91 448 E-mail: info@de.buerkert.com International address www.burkert.com Manuals and data sheets on the Internet: www.burkert.com Bedienungsanleitungen und Datenblätter im Internet: www.buerkert.de Manuels et fiches techniques sur Internet : www.buerkert.fr © 2014 – 2023 Bürkert Werke GmbH Operating Instructions 2310/18_EU-ML_00803287 / Original DE www.burkert.com...
