ViewSonic NMP599-W-2 Quick Start Manual

CAUTION
Risk of explosion if the battery is replaced by an incorrect type
Wait one-half hour after switching off before handling parts.
- Replacement of a battery with an incorrect type that can be defeat a safeguard;
- Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a
battery, that can result in an explosion;
- Leaving a battery in an extremely high temperature surrounding environment that
can result in an explosion or the leakage of flammable liquid or gas;
- A battery subjected to extremely low air pressure that may result in an explosion or
the leakage of flammable liquid or gas.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
FCC Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure and Industry Canada
RSS-102 RF exposure limits set forth for an uncontrolled environment. This device and
its antenna must not be co-located or operating in conjunction with any other antenna
or transmitter. To comply with FCC RF exposure and Industry Canada RSS-102 RF
exposure compliance requirements, this grant is applicable to only Mobile Configura-
tions. The antennas used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
Cet equipement est conforme aux limites d'exposition aux rayonnements enoncees
pour un environnement non controle et respecte les regles d'exposition aux frequences
radioe lectriques (RF) CNR-102 de I'IC. Cet equipement doit etre installe et utilize en
gardant une distance de 20 cm ou plus entre le radiateur et le corps humain (a
I'exception des extremites : mains, poignets, pieds et chevilles).
NMP599-W-2_QSG_ENG_Rev.1a
NMP599-W-2
Quick Start Guide
This printed quick start guide provides a quick walk-through of the setup process. For complete
documentation, please visit http://www.viewsonic.com/us/support.

Box Content

Power adapter
Wi-Fi antenna
NMP599-W-2
Device
Velcro (2sets)
Power bracket and Device quick
micro-SD card bracket
guide
and screw*2
Mounting and Installation
(USB mouse required)
1. Attach the wireless antenna by screwing the antenna clockwise onto the post.
2. Mount the media player to the back of the monitor using the Velcro strips.
i. Separate the Velcro strip into singles.
ii. Attach one strip onto the bottom flat surface
of the media player.
3. Attach the other strip to the surface on the
back of the display.
4. Secure the media player to the display.
5. Connect the HDMI cable and AC adapter.

Port Connections

HDMI cable
Software quick 1. Kensington lock 5. HDMI out
guide
2. ADB 6. Power LED
3. Reset 7. USB port
4. Audio out 8. Micro SD

System Setup

1. Device Startup

Plug in the AC adapter to the media player
and it will power on automatically.
Once the user has exited the boot up screen,
users can go through system configurations
in both landscape and portrait orientations.
9. USB port 13. Wireless antenna port
10. Ethernet/PoE
11. DC in
12. Mounting hole (screw spec: M4)
