- Page 1 Healthy Home Sensor IAQ TBHV110-915 Reference Manual TBHV110-868 Model Name: TBHV110 DOC ver.: BQW_02_0005.003...
-
Page 2: Table Of Contents
Table of Contents 1. Description 1. Description 2. Specifications The Healthy Home Indoor Air Quality 2.1 Mechanical sensor utilizes LoRaWAN connectivity to 2.1.1 Sensor communicate the Temperature, Relative 2.2 Environmental 2.4 Certifications and Conformity Humidity, and Volatile Organic Compound 2.6 Battery Life levels of the surrounding environment. -
Page 3: Specifications
2. Specifications 2.1.1 Sensor 2.1 Mechanical Length x Width x Height 50mm x 20mm x 50mm Weight 30g without battery 40g with battery Sensor • Temperature & Relative Humidity • Indoor Air Quality 2.2 Environmental 2.3 Radio Temperature 0°C to +50°C Frequency •... -
Page 4: Operation
3. Operation 3.1 Transport Mode Sensors are shipped with a plastic battery insulating pull tab that must be removed before the operation. 3.2 Default Operation During default operation, the device will send an environmental status message to the network once there is a sufficient delta in the environmental conditions or 5 minutes of inactivity. The precise trigger values can be found in 4.1.1. -
Page 5: Payload (Continue)
4.1.2 Payload (continue) Status Sensors status Bits [0] 1 – Trigger Event, 0 – Keep-Alive Bits [2:1] 1 – Temperature and humidity s ensor, Bits[3] 0 – IAQ Sensor Bits[4] 1 - Temperature status is changed ( 2℃ delta) Bits[5] 1 - RH status is changed (5% RH deltas) Bits[6]... - Page 6 Breath VOC concentration estimate Bits [15:0] Conversion into breath-VOC equivalents in ppm concentration. The scaling is derived from lab tests with the b-VOC gas mixture described in Table 5. Ref: BME680 – Datasheet V1.3 Page 10 Table 5 (July 2019) Indoor-air-quality value as measured by the digital sensor Bit [15:0] unsigned value range 0 –...
-
Page 7: Battery
5. Battery 5.1 Replacement Use ER14250 or equivalent. Remove the upper cap and replace the battery. 5.2 Cautions CAUTION: Disposal of a battery (or battery pack) into a fire or a hot oven, or mechanically crushing or cutting of a battery (or battery pack) can result in an EXPLOSION! Leaving a battery (or battery pack) in an extremely high temperature surrounding environment can result in an EXPLOSION or leakage of flammable liquid or gas. -
Page 8: Label Format Information
6. Label format information 6.1 Round label 6.1.1 All QR code URN:LW:D0:58A0CB0000210000:E8E1E1000XXXXXXX:01630302 The total maximum resulting character sentence is 48 alphanumeric characters long. 6.1.2 Product Name PRODUCT:IAQ Sensor Fixed code, not including in QR code. 6.1.3 JoinEUI 900MHz: 58A0CB0000210000. (US/AU/AS923/BR) 800MHz: 58A0CB0001500000. -
Page 9: Profileid
VendorID is assigned by the LoRa Alliance. 6.1.5.2 VendorProfileID 900MHz: 0302 (US/AU/AS923/BR) 800MHz: 0A02 (EU/IN/RU) 6.1.6 Model Name MODEL:TBHV110. Fixed code, not including in QR code. 6.2 PE Bag & Back Label Barcode PE Bag Label Back Label Definition of Back Label and PE Bag Barcode Label: GS1 DataMatrix ●... -
Page 10: Important Product & Safety Instructions
7. Important Product & Safety Instructions For the most current and more detailed information about Tabs features and settings as well as safety instructions, please download the user manual for the products online at w ww.browan.com before the use of any Tabs products or services. Certain sensors contain magnets. -
Page 11: Warnings
8. Warnings ● Do not place naked flame sources, such as ● Observe the plus (+) and minus (-) marks lighted candles, on or near the equipment. on the battery and equipment and ensure ● The battery shall not be exposed to correct use. -
Page 12: Notices
9. Notices ● Avoid exposing your sensors or batteries to ● PROP 65 WARNING: This product contains very cold or very hot temperatures. Low or chemicals known to the State of California to high-temperature conditions may cause cancer and birth defects or other temporarily shorten the battery life or cause reproductive harm ●... -
Page 13: Regulatory
11. Regulatory Hereby, Browan Communications Inc. declares that the radio equipment for Tabs products is in compliance with Directive 2014/53/EU. This device complies with Part 15 of the FCC Rules and RSS Standards of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 14: Industry Canada Statement
The product complies with the US portable RF exposure limit set forth for an uncontrolled environment and is safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such a function is available.
